K 12 A Active FullRange Coaxial Speaker www

K 12 A Active Full-Range Coaxial Speaker www. next-proaudio. com Specifications MODEL K 12 A Speaker Type: Active Coaxial Reflex Speaker Frequency Response (-6 d. B): 53 Hz - 18. 000 Hz Low Frequency Extension (-10 d. B): 44 Hz Calculated Max. SPL (Cont/Peak): 124 d. B/127 d. B (Full-Space) Coverage Angle -6 d. B (Hx. V): 80º Conical Low Frequency: 1 x 12" (300 mm)/3" (76 mm) VC, B&C Custom Speaker High Frequency: 1 x 1. 4" (36 mm) exit/3" (75 mm) VC, B&C Custom Compression Driver Connectors: Signal: 2 x XLR; Power: 2 x Power. CON Amplifier Technology: 2 Channel Switched Mode Class D with DSP Section Power (RMS/Program/Peak) LF: Section Power (RMS/Program/Peak) HF: 400 W/540 W/1080 W 100 W/135 W/270 W Controller: PC Controlled Networkable DSP 24 bit/48 k. Hz System Presets: 6 Factory and 2 User, Selectable via Software or Rear Panel Switch PC Control: Via RS 485 and Suplied Software "SOUNDWARE" DSP Adjustable Parameters: 6 PEQ, Delay, HPF, LPF, Polarity, Bass Enhancer, Level, Mute AC Operating Voltage: 90 V - 245 VAC Nominal Power Consumption: 550 W Dimensions (Wx. Hx. D): 448 x 354 x 361 mm (17. 64 x 13. 94 x 14. 21 in) Net Weight: 17. 2 kg (37. 92 lb)
