IPC Accessories Installation Guide 2020 04 28 Dome

IPC Accessories Installation Guide 2020 -04 -28

Dome camera mount Dome Pendant Mount AE-TR-CM 24 -IN NPT ¾”Plastic Waterproof joint Junction box Optional IPC 323 X series AE-TR-A 01 IN AE-TR-JB 04 --IN Outdoor Wall mount (Junction box) AE-TR-JB 07+AE-TRWM 04 Indoor Wall mount Pole mount AE-TR-WM 04 In-ceiling mount AE-TR-FM 152 -A Electric-box Transfer plate AE-TR-SM 04 -IN AE-TR-UP 06 -IN

Dome camera mount Dome Pendant Mount AE-TR-CM 24 -IN NPT ¾”Plastic Waterproof joint Optional Junction box AE-TR-JB 03 -G-IN IPC 32 X S/E/L series IPC 31 X AE-TR-A 01 IN Outdoor Wall mount (Junction box) AE-TR-JB 07+AE-TR-WM 04 Indoor Wall mount Pole mount AE-TR-WM 03 -D Or AE-TR-WM 03 -B AE-TR-UP 06 -IN

Dome camera mount Dome Pendant Mount AE-TR-CM 24 -IN PRIME series IPC 363 X IPC 361 X S/E NPT ¾”Plastic Waterproof joint Junction box Optional AE-TR-JB 03 -H-IN AE-TR-A 01 -IN Mini PTZ series IPC 64 XX Wall mount (Junction box) AE-TR-JB 07+AE-TR-WM 04 Wall mount Pole mount AE-TR-WM 03 -B AE-TR-UP 06 IN

Fisheye camera mount Dome Pendant Mount AE-TR-CM 24 -IN Optional Junction box AE-TR-JB 04 -IN 868 fisheye TR-A 01 -IN NPT ¾”Plastic Waterproof joint AE-TR-WM 04 Junction box 815 fisheye AE-TR-JB 03 -H-IN Dome Pendant Mount Optional TR-A 01 -IN NPT ¾”Plastic Waterproof joint AE-TR-CM 24 -IN

Bullet camera mount Junction box AE-TR-JB 07 -IN IPC 23 XX series AE-TR-JB 06 IN IPC 222 X series 26 X series Pole mount AE-TR-UP 06 -A NPT ¾”Plastic Waterproof joint Outdoor Pole mount Optional TR-A 01 -IN Recommended side outlet for cable AE-TR-UP 06 -IN

Mini Bullet camera mount Pole mount AE-TR-UP 06 -A IPC 21 XX Junction box AE-TR-JB 05 -IN IPC 21 XX (Round mount) NPT ¾”Plastic Waterproof joint Junction box TR-A 01 -IN Optional AE-TR-JB 06 IN

Outdoor mini PTZ camera mount Junction box AE-TR-JB 07 -IN NPT ¾”Plastic Waterproof joint Optional AE-TR-A 01 -IN Pole mount IPC 672 Series Recommended side outlet for cable AE-TR-UP 06 -IN

PTZ camera mount Pendent mount (500 mm) Pendent mount (200 mm) (support side cabling) AE-TR-SE 45 -A AE-TR-CE 45 IPC 62 xx Series IPC 63 xx Series AE-TR-SE 45 Pendent mount (200 mm) Pole mount Wall mount (Shorter bracket) Steel：AE-TR-UP 08 -A AE-TR-WE 45 Wall mount (Longer bracket) AE-TR-JB 12 -IN AE-TR-WE-45 -A Wall mount (Swan neck bracket) AE-TR-WE-45 -B Corner mount Steel ：AE-TR-UC 08 -A

PTZ camera mount Pendent mount (500 mm) AE-TR-SE 45 -A IPC 68 x Series AE-TR-CE 45 Pendent mount (200 mm) (support side cabling) AE-TR-SE 45 Pendent mount (200 mm) Pole mount Steel：AE-TR-UP 08 -A AE-TR-JB 12 -IN Wall mount (Longer bracket) Corner mount AE-TR-WE 45 -A Wall mount (Swan neck bracket) AE-TR-WE 45 -B Steel ：AE-TR-UC 08 -A

Indoor PTZ camera mount In-ceiling mount AE-TR-FM 200 -IN IPC 6222 EI-X 22 UP-C

Indoor PTZ camera mount Junction Box (Optional) AE-TR-JB 07 -IN IPC 8542 ER 5 -DUG Wall Mount Pole mount Adapter AE-TR-UP 06 -IN

Positioning system mount IPC 7622 Series Pedestal installation No accessory It is necessary to ensure that the mounting base is firm enough
