Introduction to FPGA Devices Tools ECE 545 Introduction

Introduction to FPGA Devices & Tools ECE 545 – Introduction to VHDL George Mason University

FPGA Devices ECE 545 – Introduction to VHDL George Mason University

World of Integrated Circuits Full-Custom ASICs Semi-Custom ASICs PLD PAL PLA ECE 545 – Introduction to VHDL User Programmable FPGA PML LUT (Look-Up Table) MUX Gates 3

Two competing implementation approaches ASIC Application Specific Integrated Circuit • designs must be sent for expensive and time consuming fabrication in semiconductor foundry • designed all the way from behavioral description to physical layout ECE 545 – Introduction to VHDL FPGA Field Programmable Gate Array • bought off the shelf and reconfigured by designers themselves • no physical layout design; design ends with a bitstream used to configure a device 4

What is an FPGA? Configurable Logic Blocks Block RAMs I/O Blocks Block RAMs ECE 545 – Introduction to VHDL 5

Which Way to Go? ASICs High performance FPGAs Off-the-shelf Low development cost Low power Short time to market Low cost in high volumes ECE 545 – Introduction to VHDL Reconfigurability 6

Other FPGA Advantages • Manufacturing cycle for ASIC is very costly, lengthy and engages lots of manpower • Mistakes not detected at design time have large impact on development time and cost • FPGAs are perfect for rapid prototyping of digital circuits • Easy upgrades like in case of software • Unique applications • reconfigurable computing ECE 545 – Introduction to VHDL 7

Major FPGA Vendors SRAM-based FPGAs • Xilinx, Inc. • Altera Corp. • Atmel • Lattice Semiconductor Flash & antifuse FPGAs • Actel Corp. • Quick Logic Corp. ECE 545 – Introduction to VHDL 8

Xilinx u Primary products: FPGAs and the associated CAD software Programmable Logic Devices u u ISE Alliance and Foundation Series Design Software Main headquarters in San Jose, CA Fabless* Semiconductor and Software Company u u u UMC (Taiwan) {*Xilinx acquired an equity stake in UMC in 1996} Seiko Epson (Japan) TSMC (Taiwan) ECE 545 – Introduction to VHDL 9

Xilinx FPGA Families • Old families • XC 3000, XC 4000, XC 5200 • Old 0. 5µm, 0. 35µm and 0. 25µm technology. Not recommended for modern designs. • High-performance families • Virtex (0. 22µm) • Virtex-E, Virtex-EM (0. 18µm) • Virtex-II, Virtex-II PRO (0. 13µm) • Low Cost Family • • Spartan/XL – derived from XC 4000 Spartan-II – derived from Virtex Spartan-IIE – derived from Virtex-E Spartan-3 ECE 545 – Introduction to VHDL 10

ECE 545 – Introduction to VHDL 11

Basic Spartan-II FPGA Block Diagram ECE 545 – Introduction to VHDL 12

CLB Structure COUT G 4 G 3 G 2 G 1 Look-Up Table O Carry & Control Logic COUT YB Y D S Q CK EC Look-Up Table O R F 5 IN BY SR F 4 F 3 F 2 F 1 G 4 G 3 G 2 G 1 Carry & Control Logic YB Y D S Q CK EC R F 5 IN BY SR Look-Up Table O Carry & Control Logic XB X CIN CLK CE D S Q CK EC F 4 F 3 F 2 F 1 R SLICE CIN CLK CE Look-Up Table O Carry & Control Logic XB X D S Q CK EC R SLICE • Each slice has 2 LUT-FF pairs with associated carry logic • Two 3 -state buffers (BUFT) associated with each CLB, accessible by all CLB outputs ECE 545 – Introduction to VHDL 13

CLB Slice Structure • Each slice contains two sets of the following: • Four-input LUT • Any 4 -input logic function, • or 16 -bit x 1 sync RAM • or 16 -bit shift register • Carry & Control • Fast arithmetic logic • Multiplier logic • Multiplexer logic • Storage element • • Latch or flip-flop Set and reset True or inverted inputs Sync. or async. control ECE 545 – Introduction to VHDL 14

LUT (Look-Up Table) Functionality • Look-Up tables are primary elements for logic implementation • Each LUT can implement any function of 4 inputs ECE 545 – Introduction to VHDL 15

Distributed RAM 16 X 1 S • A LUT equals 16 x 1 RAM • Implements Single and Dual. Ports • Cascade LUTs to increase RAM size • Synchronous write • Synchronous/Asynchronous read • Accompanying flip-flops used for synchronous read ECE 545 – Introduction to VHDL = LUT • CLB LUT configurable as Distributed RAM D W EWCL K A 0 A 1 A 2 A 3 O RAM 32 X 1 S D WE WCLK A 0 A 1 A 2 A 3 A 4 LUT = LUT or O RAM 16 X 2 S D 0 D 1 WE WCLK O 0 A 0 O 1 A 2 A 3 or RAM 16 X 1 D D W EWCL K A 0 SPO A 1 A 2 A 3 DPRA DP 0 DPRA 1 O DPRA 2 DPRA 3 16

Shift Register LUT • Each LUT can be configured as shift register IN CE CLK • Serial in, serial out • Dynamically addressable delay up to 16 cycles • For programmable pipeline • Cascade for greater cycle delays • Use CLB flip-flops to add depth D Q CE LUT = D Q CE OUT D Q CE DEPTH[3: 0] ECE 545 – Introduction to VHDL 17

Shift Register 12 Cycles 64 Operation A 4 Cycles Operation B 8 Cycles 64 Operation C 3 Cycles • Register-rich FPGA 3 Cycles 9 -Cycle imbalance • Allows for addition of pipeline stages to increase throughput • Data paths must be balanced to keep desired functionality ECE 545 – Introduction to VHDL 18

Carry & Control Logic COUT YB G 4 G 3 G 2 G 1 Y Look-Up O Table D Carry & Control Logic S Q CK EC R F 5 IN BY SR XB F 4 F 3 F 2 F 1 CIN CLK CE ECE 545 – Introduction to VHDL X Look-Up Table O Carry & Control Logic S D Q CK EC R SLICE 19

Fast Carry Logic Each CLB contains separate logic and routing for the fast generation of sum & carry signals MSB • Increases efficiency and performance of adders, subtractors, accumulators, comparators, and counters u Carry logic is independent of normal logic and routing resources ECE 545 – Introduction to VHDL LSB Carry Logic Routing u 20

Accessing Carry Logic u All major synthesis tools can infer carry logic for arithmetic functions • • Addition (SUM <= A + B) Subtraction (DIFF <= A - B) Comparators (if A < B then…) Counters (count <= count +1) ECE 545 – Introduction to VHDL 21

Block RAM Port B Port A Spartan-II True Dual-Port Block RAM • Most efficient memory implementation • Dedicated blocks of memory • Ideal for most memory requirements • 4 to 14 memory blocks • 4096 bits per blocks • Use multiple blocks for larger memories • Builds both single and true dual-port RAMs ECE 545 – Introduction to VHDL 22

Spartan-II Block RAM Amounts ECE 545 – Introduction to VHDL 23

Block RAM Port Aspect Ratios 1 2 0 4 0 0 1 k x 4 2 k x 2 1023 4 k x 1 1047 8 0 512 x 8 511 16 0 4095 255 ECE 545 – Introduction to VHDL 256 x 16 24

Basic I/O Block Structure D Q EC Three-State FF Enable Clock SR Three-State Control Set/Reset D Q EC Output FF Enable SR Output Path Direct Input FF Enable Registered Input Q D EC Input Path SR ECE 545 – Introduction to VHDL 25

IOB Functionality • IOB provides interface between the package pins and CLBs • Each IOB can work as uni- or bi-directional I/O • Outputs can be forced into High Impedance • Inputs and outputs can be registered • advised for high-performance I/O • Inputs can be delayed ECE 545 – Introduction to VHDL 26

Routing Resources CLB CLB PSM CLB ECE 545 – Introduction to VHDL CLB Programmable Switch Matrix PSM CLB 27

Spartan-II FPGA Family Members ECE 545 – Introduction to VHDL 28

ECE 545 – Introduction to VHDL 29

Virtex-II 1. 5 V Architecture Multipliers 18 x 18 Block RAMs Multipliers 18 x 18 Configurable Logic Block RAMs 30 ECE 545 – Introduction to VHDL I/ O Block

Virtex-II 1. 5 V Device CLB Array Slices Maximum I/O Block. RAM (18 kb) Multiplier Blocks Distributed RAM bits XC 2 V 40 8 x 8 256 88 4 4 8, 192 XC 2 V 80 16 x 8 512 120 8 8 16, 384 XC 2 V 250 24 x 16 1, 536 200 24 24 49, 152 XC 2 V 500 32 x 24 3, 072 264 32 32 98, 304 XC 2 V 1000 40 x 32 5, 120 432 40 40 163, 840 XC 2 V 1500 48 x 40 7, 680 528 48 48 245, 760 XC 2 V 2000 56 x 48 10, 752 624 56 56 344, 064 XC 2 V 3000 64 x 56 14, 336 720 96 96 458, 752 XC 2 V 4000 80 x 72 23, 040 912 120 737, 280 XC 2 V 6000 96 x 88 33, 792 1, 104 144 1, 081, 344 XC 2 V 8000 112 x 104 46, 592 1, 108 168 1, 490, 944 ECE 545 – Introduction to VHDL 31

Virtex-II Block Select. RAM • Virtex-II BRAM is 18 kbits • Additional “parity” bits available in selected configurations Width Depth Address Data Parity 1 16, 386 [13: 0] [0] N/A 2 8, 192 [12: 0] [1: 0] N/A 4 4, 096 [11: 0] [3: 0] N/A 9 2, 048 [10: 0] [7: 0] [0] 18 1, 024 [9: 0] [15: 0] [1: 0] 36 512 [8: 0] [31: 0] [3: 0] ECE 545 – Introduction to VHDL 32

FPGA Nomenclature ECE 545 – Introduction to VHDL 33

FPGA Tools ECE 545 – Introduction to VHDL George Mason University

Design process (1) Design and implement a simple unit permitting to speed up encryption with RC 5 -similar cipher with fixed key set on 8031 microcontroller. Unlike in the experiment 5, this time your unit has to be able to perform an encryption algorithm by itself, executing 32 rounds…. . Specification (Lab Experiments) VHDL description (Your Source Files) Library IEEE; use ieee. std_logic_1164. all; use ieee. std_logic_unsigned. all; Functional simulation entity RC 5_core is port( clock, reset, encr_decr: in std_logic; data_input: in std_logic_vector(31 downto 0); data_output: out std_logic_vector(31 downto 0); out_full: in std_logic; key_input: in std_logic_vector(31 downto 0); key_read: out std_logic; ); end AES_core; Synthesis ECE 545 – Introduction to VHDL Post-synthesis simulation 35

Design process (2) Implementation Timing simulation Configuration On chip testing ECE 545 – Introduction to VHDL 36

Design Process control from Active-HDL ECE 545 – Introduction to VHDL 37

Simulation Tools Many others… ECE 545 – Introduction to VHDL 38

ECE 545 – Introduction to VHDL 39

ECE 545 – Introduction to VHDL 40

Synthesis Tools … and others ECE 545 – Introduction to VHDL 41

Logic Synthesis VHDL description Circuit netlist architecture MLU_DATAFLOW of MLU is signal A 1: STD_LOGIC; signal B 1: STD_LOGIC; signal Y 1: STD_LOGIC; signal MUX_0, MUX_1, MUX_2, MUX_3: STD_LOGIC; begin A 1<=A when (NEG_A='0') else not A; B 1<=B when (NEG_B='0') else not B; Y<=Y 1 when (NEG_Y='0') else not Y 1; MUX_0<=A 1 and B 1; MUX_1<=A 1 or B 1; MUX_2<=A 1 xor B 1; MUX_3<=A 1 xnor B 1; with (L 1 & L 0) select Y 1<=MUX_0 when "00", MUX_1 when "01", MUX_2 when "10", MUX_3 when others; end MLU_DATAFLOW; ECE 545 – Introduction to VHDL 42

Features of synthesis tools • Interpret RTL code • Produce synthesized circuit netlist in a standard EDIF format • Give preliminary performance estimates • Some can display circuit schematics corresponding to EDIF netlist ECE 545 – Introduction to VHDL 43

Implementation • After synthesis the entire implementation process is performed by FPGA vendor tools ECE 545 – Introduction to VHDL 44

ECE 545 – Introduction to VHDL 45

Translation Synthesis Circuit netlist Electronic Design Interchange Format EDIF Timing Constraints Constraint Editor Native Constraint File NCF User Constraint File Translation NGD ECE 545 – Introduction to VHDL Native Generic Database file 46

Sample UCF File • • • • • • # # Constraints generated by Synplify Pro 7. 3. 3, Build 039 R # # Period Constraints #Begin clock constraints #End clock constraints # Output Constraints # Input Constraints # Location Constraints # End of generated constraints NET "clock" LOC = "P 88"; NET "control(0)" LOC = "P 50"; NET "control(1)" LOC = "P 48"; NET "control(2)" LOC = "P 42"; NET "reset" LOC = "P 93"; NET "segments(0)" LOC = "P 67"; NET "segments(1)" LOC = "P 39"; NET "segments(2)" LOC = "P 62"; NET "segments(3)" LOC = "P 60"; NET "segments(4)" LOC = "P 46"; NET "segments(5)" LOC = "P 57"; NET "segments(6)" LOC = "P 49"; ECE 545 – Introduction to VHDL 47

Pin Assignment FPGA P 93 P 88 P 39 P 42 P 46 CLOCK CONTROL(0) CONTROL(1) CONTROL(2) RESET LAB 2 SEGMENTS(0) SEGMENTS(1) SEGMENTS(2) SEGMENTS(3) SEGMENTS(4) SEGMENTS(5) SEGMENTS(6) P 67 P 62 P 60 P 48 P 49 P 50 P 57 ECE 545 – Introduction to VHDL 48

Parallel Port Interface ECE 545 – Introduction to VHDL 49

Constraints Editor ECE 545 – Introduction to VHDL 50

Circuit netlist ECE 545 – Introduction to VHDL 51

Mapping LUT 4 LUT 1 FF 1 LUT 5 LUT 2 FF 2 LUT 3 ECE 545 – Introduction to VHDL 52

Placing FPGA CLB SLICES ECE 545 – Introduction to VHDL 53

Routing FPGA Programmable Connections ECE 545 – Introduction to VHDL 54

Static Timing Analyzer • Performs static analysis of the circuit performance • Reports critical paths with all sources of delays • Determines maximum clock frequency ECE 545 – Introduction to VHDL 55

Static Timing Analysis • Critical Path – The Longest Path From Outputs of Registers to Inputs of Registers t. P logic in D Q out clk t. Critical = t. P FF + t. P logic + t. S FF ECE 545 – Introduction to VHDL 56

Static Timing Analysis • Min. Clock Period = Length of The Critical Path • Max. Clock Frequency = 1 / Min. Clock Period ECE 545 – Introduction to VHDL 57

Configuration • Once a design is implemented, you must create a file that the FPGA can understand • This file is called a bit stream: a BIT file (. bit extension) • The BIT file can be downloaded directly to the FPGA, or can be converted into a PROM file which stores the programming information ECE 545 – Introduction to VHDL 58

Resources & Required Reading Spartan FPGA devices Xilinx Spartan-II 2. 5 V FPGA Family: Complete Data Sheet • Module 1: Introduction & Ordering Information • Module 2: Functional Description http: //direct. xilinx. com/bvdocs/publications/ds 001. pdf ECE 545 – Introduction to VHDL 59

Resources & Required Reading FPGA Tools Integrated Interfaces: Active-HDL with Synplify® http: //www. aldec. com/Previews/active_synplify. htm Integrated Synthesis and Implementation http: //www. aldec. com/Previews/synthesis_implementation. htm ECE 545 – Introduction to VHDL 60

Hands-on Session Enough Talking Let’s Get To It !!Brace Yourselves!! ECE 545 – Introduction to VHDL 61

MLU: Block Diagram ECE 545 – Introduction to VHDL 62

ALU Schematic A[3: 0] B[3: 0] arith [1: 0] A+B 0 A-B 1 A <<< 1 2 A >>> 1 3 logic [1: 0] 0 Y [3: 0] 1 A and B 0 A or B 1 A xor B 2 A xnor B 3 ECE 545 – Introduction to VHDL 0 ar_log 1 neg_Y 63

Questions? ECE 545 – Introduction to VHDL 64
