Intro to Sangoma Webinar Konrad Hammel Field Applications

Intro to Sangoma Webinar Konrad Hammel Field Applications Engineer

Outline • • Who is Sangoma’s AFT Series Sangoma Cards A to B Intro to Asterisk Architecture Installing/Configuring Sangoma Cards Asterisk Distros Sangoma Cheat Sheet Q&A (please save all questions for this period) Intro To Sangoma Technologies 2

Who is Sangoma? • Founded in 1984 by David Mandelstam (CEO) • Located in Markham (Greater Toronto Area), Ontario, Canada and Montreal, Quebec, Canada • Linux based routing in early/mid 90 s • Asterisk started out on a Sangoma Frame Relay card…but the project needed quality interface cards • Design and build, telco grade, telephony interface cards • Develop software to integrate the cards with your IVR, PBX or router Intro To Sangoma Technologies 3

SANGOMA’S AFT SERIES Intro To Sangoma Technologies 4

AFT Series • Modularity, Inheritance, Abstraction: – Split the host interface, telephone interface, and DSPs • Common PCI and PCIe interface for all cards – All cards use one core driver to interface with PC • Telephony interfaces are designed to scale • Expensive DSP modules are optional but don’t require different host or telephony interfaces Intro To Sangoma Technologies 5

AFT Series Intro To Sangoma Technologies 6

AFT Series Intro To Sangoma Technologies 7

AFT Series • Does this design cost more then Dedicated designs…. YES – Extra circuit boards – Extra connectors – Extra pieces – Intelligent assembly required – FPGAs need security Intro To Sangoma Technologies 8

AFT Series • BUT… – Lower support costs • One PCI or PCIe interface for 30+ cards • Modularity makes troubleshooting easier – Lower maintenance costs • If 1 section breaks, the other sections are re-usable – Lower cost of stocking cards • Shared circuit boards = more boards per manufacturing run Intro To Sangoma Technologies 9

AFT Series • Octasic – We were first to use their technology – Telco grade echo cancellers – 128 ms tail…anything more and you are having a conversation with your echo – Fully Independent…no playing around, it just works. – Fax/Modem Detection – DTMF Detection and Generation Intro To Sangoma Technologies 10

AFT Series • Remora Expansion System – Simple method to have more ports without using more PCI/PCIe slots – Remora Daughter cards – 2, 3, 4, and 6 port back planes – Lowest numbered connector in the back plane is port 1 Intro To Sangoma Technologies 11

AFT Series • Field Upgradable Firmware – New features can be added in the field – No ones perfect…fixes bugs too • Crash Proof Firmware – Primary and Backup firmware – Select via only jumper on card • Insert Jumper, start computer, flash firmware, remove jumper, restart computer…you just saved a “bricked” card Intro To Sangoma Technologies 12

AFT Series • Clock Sync – – Synchronise the clock from another card Essential for Faxing…finally, reliable faxing Uses the only jumpers on cards Requires only a cable to connect the 2 or more cards Intro To Sangoma Technologies 13

SANGOMA HARDWARE PRODUCTS Intro To Sangoma Technologies 14

A 200 • • • 2 -4 port Analog Card PCI 2. 2(5 V and 3. 3 V) and PCIe(E) 2 U Form Factor, 140 mm x 55 mm Uses standard FXO/FXS modules 4 x RJ 11 (4 P 4 C) Expands up to 24 via Remora System Optional hardware Echo canceller (D) Fax Sync Compatible Requires external power source for FXS and Remora Daughter cards Lifetime Warranty Intro To Sangoma Technologies 15

A 400 • • • 2 -12 port Analog Card PCI 2. 2(5 V and 3. 3 V) and PCIe(E) Uses standard FXO/FXS modules Standard DB-25 connector Expands up to 24 via Remora System Optional hardware Echo canceller (D) Fax Sync Compatible Requires external power source for FXS and Remora Daughter cards Lifetime Warranty Intro To Sangoma Technologies 16

Analog Modules FXS Module FXO Module • Used to connect phones, fax machines, modems, etc • Adds 2 lines per module • Green…easy to identify • Universal interface, works with all Sangoma analog cards • Used to connect to telco lines • Adds 2 lines per module • Red…easy to identify • Universal interface, works with all Sangoma analog cards Intro To Sangoma Technologies 17

B 600 • 4 port FXO + 1 port FXS • PCI 2. 2(5 V and 3. 3 V) and PCIe(E) • 2 U Form Factor, 140 mm x 55 mm • Standard RJ 14 (6 P 4 C), FXO has 2 lines per port • No external Power needed • Optional hardware Echo canceller (D) • 5 year Warranty Intro To Sangoma Technologies 18

A 10 X Series (A 101, A 102, A 104, A 108) • • • 1 -8 port T 1/E 1/J 1 Channelized for data, voice or both Clock recovery (Normal) or Clock generation (Master) with Clock Reference PCI 2. 2(5 V and 3. 3 V) and PCIe(E) 2 U Form Factor, 140 mm x 55 mm Standard RJ-48 c connector Optional hardware EC (D) Up to 248 channels of hardware HDLC framing Fax source compatible Lifetime Warranty Intro To Sangoma Technologies 19

A 500 • • • 2 -6 port BRI Card Expands up to 24 via Remora System PCI 2. 2(5 V and 3. 3 V) and PCIe(E) 2 U Form Factor, 187 mm x 55 mm 2 BRI lines per RJ-45 port Capable of powering phones over line using standard power supply Requires power for Remora Daughter cards Optional hardware Echo canceller (D) Fax Sync and Source Compatible Lifetime Warranty Dip switches control termination resistance for BRI lines Intro To Sangoma Technologies 20

B 700 • 4 ports of BRI and 2 ports of FXO/FXS • BRI modules are reversible TE mode one side NT mode on the other side • Standard analog modules • PCI 2. 2(5 V and 3. 3 V) and PCIe(E) • 2 U Form Factor, 187 mm x 55 mm • 2 BRI lines per RJ-45 port, 1 RJ-11 (6 P 4 C) for analog • External power needed for FXS • Optional hardware Echo canceller (D) • Fax Sync and Source Compatible, but analog ports synced to BRI automatically • 5 year Warranty • Dip switches control termination resistance for BRI lines Intro To Sangoma Technologies 21

BRI Modules • BRI lines have a Network side (NT) and a Termination side (TE) • 1 module can do both, just flip it over • Red = TE mode • Green = NT mode • Allows for the connection of 2 BRI lines • Universal design works with all Sangoma BRI cards Intro To Sangoma Technologies 22

UT-100 USB-FXO • • 2 port analog USB 1. 0 interface Standard RJ 11 6 P 4 C Software EC and hardware EC • 5 year Warranty Intro To Sangoma Technologies 23

UT-50 Voicetime • Dahdi Timing Device • USB connector or 0. 1” pitch connector • 5 year Warranty Intro To Sangoma Technologies 24

INTRO TO ASTERISK ARCHITECTURE Intro To Sangoma Technologies 25

Asterisk Architecture Intro To Asterisk Architecture 26

Asterisk Architecture • A Basic Call – call goes from TDM hardware, through the drivers, abstraction API, and chan_zapata to Asterisk – Asterisk then routes the call to the dial plan where Asterisk is told which Application to use – Asterisk uses the Dial application to setup another channel using chan_sip. – Chan_sip then sends the call to a SIP phone Intro To Asterisk Architecture 27

INSTALLING AND CONFIGURING A SANGOMA CARD Intro To Sangoma Technologies 28

Installing and Configuring • Install the card into your system • Install Dahdi, signalling stack (Lib. PRI) and then Asterisk • Download the latest “feature frozen” driver – ftp: //ftp. sangoma. com/linux/current_wanpipe/current-stable. tgz • Start the installer script “Setup” – “. /Setup install” • Configure the card using “wancfg_dahdi” Intro To Sangoma Technologies 29

Installing Sangoma Cards • Installing an A 200 – http: //wiki. sangoma. com/files/Hardware. Installation. Manuals/A 200_Manual_Web. p df • Installing an A 400 – http: //wiki. sangoma. com/files/Hardware. Installation. Manuals/A 400_Manual_Web_r 2. pdf • Installing an A 500 – http: //wiki. sangoma. com/files/Hardware. Installation. Manuals/A 500_Manual_Web. p df • Installing a B 700 – http: //wiki. sangoma. com/files/Hardware. Installation. Manuals/B 700_Manual_Web. p df Intro To Sangoma Technologies 30

ASTERISK DISTROS Intro To Sangoma Technologies 31

Asterisk Distros • Trixbox Community Edition – RPMs available • Elastix – RPMs available • PBX in a Flash – Source install • Trixbox PRO / PBXtra – Supported by Fonality Intro To Sangoma Technologies 32

SANGOMA CHEAT SHEET Intro To Sangoma Technologies 33

Sangoma Cheat Sheet Intro To Sangoma Technologies 34

QUESTIONS? Intro To Sangoma Technologies 35

THANK YOU. Konrad Hammel Intro To Sangoma Technologies 36
