Integration of CLIC TBM in CLEX Electronics allocation and cables tracing Wilfrid Farabolini (CEA/IRFU) 16 October 2013

Cables and racks request TBM T 0@CLEX Cabling Summary System Racks for electronics Shielded bunker Sensor conditioning Pre 3 x 43 U (3 crates (19"x 3 U x racks) alignment 380 mm) RF BI Vacuum Magnet Cooling Cable Type CTF 3 gallery 1 rack 6 rows 2 x 43 U (2 racks) Quanti Ø (mm) ty Starting (S) and End (E) Points TBM Shielded bunker Outside Shelter Collected by Alexander Summarized by Dmitry A Rad-hard Muller MULRAD 2 MCA 8 NG 18 40 6 20 6 12 12 4 4 7. 7 16. 5 S S S E E E 640 x 96 x 1185. 8 x 355. 74 x 711. 48 x 3267 x LDF 2 -50 22 12 3168 x ethernet command for stepping motors 1 5 4 10 25 control and Limit switch 4 12 576 0 2 10 S E 0 NG 4 (4 conducteurs de 1 mm 2) TCA 3 (triaxial haute tension) DIODE: SVA 3 (triaxial haute tension + 2 conducteurs 0. 25 mm 2 basse tension) NEG: PH 3 SJ (3 x 1. 5 mm 2) 6 A/10 V max 2 8. 7 S E 2 7 S E 6 9. 7 6 12. 5 S E 0 0 0 400 0 200 x 0 151. 38 x 98 x 564. 54 x 937. 5 0 30 1 1 1 1 1 5 15 15 15 E E E S S S E E E 0 750 225 225 225 Temperature sensors Supply pipe - SAS#1 Supply pipe - SAS#2 Supply pipe - PETS Supply pipe - DBQ#1 Supply pipe - DBQ#2 Return pipe - SAS#1 Return pipe - SAS#2 Return pipe - PETS Return pipe - DBQ#1 Return pipe - DBQ#2 6 racks + 1 spare Cables separation due to EMC constraints 14640 mm 2 5 holes + 1 spare

1 st idea: additional drills on the ceiling S IFE L CA IC CL ule od M L TB Pros: Cons: - Minimum changes to the building - Delicate drilling (present cable tray and TBL line to be removed, dust inside) - Cables length > 20 m if to follow present cable trays - Problem to install new racks in the gallery - Staff in the gallery during operations

Shortest path from Module to Gallery Drill only on same rows as the present pits - building structure to be preserved – drilling the ceiling is problematic (GS/SE)

Problem to install the drilling machine Cable tray to be removed Protection from dust and water to be installed TBL equipments to be removed

Even more problems for cable path Cable trenches are full on this side Nothing authorized below air ducts level (transport vehicles) Any other path is very long (40 m for last installed RF cables)

Lack of space in the above gallery Pits positions 2. 5 crates available in the vacuum alley (to be negotiated) 3 crates available in the signals acquisition alley (after some rearrangement)

2 nd solution: drill the wall towards CTF 2 S IFE L CA Cons: IC CL ule od M L TB Pros: Simple drilling (Clear area, enough space for dust confinement) Possibility to install racks where are the disused 30 GHz racks Operations from a safer gallery (but still close to the X-Box 1) Long cable length (>> 20 m, inside CLEX electronics required) Radioprotection of the CTF 2 area to be investigated

Cables path towards CTF 2 Possible drills More clearance but iron wall to be moved Possibility to add a cable tray under the ceiling but long path to reach the module (13 m to the wall) Only 3 crates available in the gallery above CTF 2 if disused 30 GHz electronics is removed

Best choice: dedicated shelter on the car park S IFE L CA er elt Sh 5 m 3 x Cons: IC CL ule od M L TB Pros: Easiest drilling solution (from outside, minimum dust, clear area inside) Shortest possible cables length (< 20 m) Sufficient place to host the new racks Safe and comfortable operations inside the shelter (outside of the controlled area) New construction (Algeco 1 k. CHF/m 2) with all services (air conditioning ? ) Radioprotection of the car park to be investigated by RP

From Module to car park wall Alternatively use of the ventilation window chicane instead of drilling new holes (to be investigated) - 0. 400 x 0. 180 m fully available trench - 3. 8 m to the wall (2. 8 m thick) - Easy drilling of 6 holes (diam. 160 mm) with slope for RP - Still 2 m of trench to be cut to reach the wall

A shelter on car park side 5 x 3 m available Ventilation window Example of a present shelter (high voltage electronics for TL 2 tail clipper)

Possible shelter arrangements Dmitry Gudkov 4 x 3 m shelter

Conclusion The shelter on car park solution allows: - Minimal cable length and easy cables pulling (also a cost issue for “good” RF cables) - Easy crates installation and safe operations (outside controlled area) - Easy drilling of the holes (less building structure concern, drill from outside) - Alternatively possible use of the ventilation window (under investigation by Y. Body – EN-CV) - Possibility to displace some electronics cabinet inside for Rad. Hard tests - Requires cable trench extension (feasibility checked with (GS/SE) ) - RP to give the green light (G. Dumont contacted) - Decision to be taken by March 2014
