Integrating Wind Energy into the Electric Grid Wind Power Forum October 26, 2011 Brian Conroy, Electric System Engineering Central Maine Power Company 1
Integrating Wind Energy into the Electric Grid Presentation Outline • The Electric Grid • The Grid Control Center • Attributes of Wind Generation • New England Wind Resources 2
The Electric Grid
The Grid Control Center
Attributes of Wind Generation • Variability – plant output fluctuates • Uncertainty – output and timing are less predictable than ‘conventional’ generation • Remote locations from network “backbone” • Distributed control systems Electric utilities and control centers take all these factors into account when planning, designing, and operating interconnections with wind generation. 5
New England Wind Resources Significant wind potential with varying characteristics exists throughout New England 1 meter per second roughly 2. 2 mph Legend MWH Class 7 >8. 8 (m/s) Class 6 8 -8. 8 (m/s) Class 5 7. 5 -8 (m/s) Class 4 Source: Levitan Phase II Wind 7 -7. 5 (m/s) Class 3 40 Miles 6. 4 -7 (m/s) Study for ISO New England 230 k. V 345 k. V 6 Spring 2009, ISO New England Inc. 6
New England Wind Resources Higher class Wind resource and 40 mile radius of Backbone transmission Base Case Results –Onshore Region MW Source: Levitan Phase II Wind Study for ISO New England Avg. Wind (m/s) CT 0 ME 7, 904 7. 79 MA 929 7. 65* NEMA 0 SEMA 765 7. 62 WCMA 164 7. 80 NH 3, 221 7. 96 RI 141 7. 74 VT 2, 830 7. 68 Total 15, 025 7. 80* 7
Thank You!
