Institute of Seismology, National Academy of Sciences, Kyrgyz Republic Managing Data from Seismic Networks & IRIS International Development Seismology September 9 -15 , 2015, Hanoi, Vietnam

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Seismic monitoring Geographically Kyrgyzstan is located in the limits of the Tien-Shan orogen, the modern tectonic activity of which defines a high seismicity of this territory. Very strong earthquakes with magnitude up to 8 and a lot of weaker events occur here. In average we process about seven thousand earthquakes per year. That is why a seismic monitoring was and remains one of the most actual problems for our republic. Map of seismicity of Kyrgyz territory for 2014 (M ≥ 0. 5, N=7931)

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Developmental stages of Kyrgyz System of Seismic Monitoring § The instrumental seismic observations in Kyrgyzstan have begun since 1927 on the base of analogue stations that essentially influenced on the network efficiency. § In October, 1990 the first digital broad-band seismic station AAK 10 has been installed on the Kyrgyz territory as observation point of Global Seismographic Network IRIS/IDA. This seismic station is included into IMS CTBTO as a 3 C auxiliary station AS 060. § Since 1991 the telemetry network KNET consisting of 10 stations, equipped with broadband high-sensitive devices has begun its operation here. § In 2007, within the frame of CTBT capacity building, NORSAR, with support from the Ministry of Foreign Affairs of Norway, provided the Kyrgyz Institute of Seismology with 10 digital broad-band stations, most of which have been installed in the south of Kyrgyzstan characterized by the high level of seismic activity. § In 2009 the new seismic network has been registered in FDSN as KRNET (Kyrgyz Republic Digital Network). At present it consists of 16 broad-band stations located on all territory of Kyrgyzstan. Moreover under IRIS support the real time data of 13 KRNET stations are openly accessible at the IRIS–DMC website. § Nowadays the Kyrgyz system of seismic monitoring includes 10 KNET stations and 16 KRNET stations, otherwise 26 seismic stations.

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Kyrgyz system of seismic monitoring - KNET stations - KRNET stations (IS NAS KR)

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Kyrgyz system of seismic monitoring # Station Name Code Lat Coordinates Lon Н (m) Network Country 1. Ananievo ANVS 42. 78611 77. 66722 1864 KRNET Kyrgyzstan 2. Aral ARLS 41. 85444 74. 32889 1526 KRNET Kyrgyzstan 3. Arkit ARK 41. 80000 71. 96667 1420 KRNET Kyrgyzstan 4. Arslanbob ARSB 41. 33 72. 97 1378 KRNET Kyrgyzstan 70. 81805 980 KRNET Kyrgyzstan 42. 83333 74. 61667 929 KRNET Kyrgyzstan 7. Boom BOOM 42. 49222 75. 94222 1737 KRNET Kyrgyzstan 8. Kadji-Say KDJ 42. 12722 77. 19444 1830 KRNET Kyrgyzstan 9. Karakol PRZ 42. 50000 78. 40000 1835 KRNET Kyrgyzstan 10. Karamyk DRK 39. 48333 71. 80444 2627 KRNET Kyrgyzstan 11. Naryn NRN 41. 42222 75. 97000 2120 KRNET Kyrgyzstan 12. Osh OHH 40. 5244 72. 7847 1001 KRNET Kyrgyzstan 13. Talas MNAS 42. 48944 72. 50667 1465 CAREMON Kyrgyzstan 14. Terek-Say TRKS 41. 46250 71. 17333 1670 KRNET Kyrgyzstan 15. Toktogul TOKL 41. 98333 72. 86806 1097 KRNET Kyrgyzstan 16. Salom-Alik SALK 40. 88333 73. 82083 1672 KRNET Kyrgyzstan 17. Sufi-Kurgan SFK 40. 01667 73. 50250 2080 CAREMON Kyrgyzstan 18. Alma-Ashu AML 42. 1310 73. 6940 3400 KNET Kyrgyzstan 19. Ala-Archa AAK 42. 6375 74. 4943 1648 KNET Kyrgyzstan 20. Chumysh CHM 42. 9985 74. 7511 655 KNET Kazakhstan 21. Erkin-Say EKS 2 42. 6615 73. 7772 1360 KNET Kyrgyzstan 22. Karagay-Bulak KBK 42. 6563 74. 9477 1760 KNET Kyrgyzstan 23. Kyzart KZA 42. 0777 75. 2495 3520 KNET Kyrgyzstan 24. Tokmok TKM 2 42. 9207 75. 5965 2020 KNET Kazakhstan 25. Uchtor UCH 42. 2275 74. 5133 3850 KNET Kyrgyzstan 26. Ulahol ULHL 42. 2455 76. 2417 2040 KNET Kyrgyzstan 27. Uspenovka USP 43. 2668 74. 4997 740 KNET Kyrgyzstan 40. 05750 FRU 1 Central Asia BTK Bishkek Batken 6. 5. Region

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC KRNET station equipment The DM 24 digitizer SEISMOMETER CMG-3 ESP

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC KNET equipment Secondary Broadband Sensor Streckeisen STS-2 Ref. Tek digitizer AAK tunnel

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC AAK (IRIS/IDA) station (AS 063 (IMS CTBTO)) Digitizer Quanterra Q 330 HR (High Resolution), 26 bit, 6 channel Secondary Broadband Sensor Streckeisen STS-2. 5

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Spectral density of seismic noise (night time). KRNET stations KNET stations

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Plan for KRNET development for next 3 years - KNET stations - KRNET stations (IS NAS KR) - proposed KRNET stations

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Data transmission and exchange § AAK (AS 060) waveforms in real time mode are sending to the IDC CTBTO. §KRNET waveforms in real time mode are sending to the IRIS/DMC. §Since 2011 both preliminary and final bulletins of KRNET data are sending to the ISC. § Seismic bulletins Xinjiang Uyghur Autonomous Region Earthquake Administration (China), Seismological Expedition of Kazakhstan, Institute of seismology of Uzbekistan, Geophysical Service of Russian Academy of sciences. §Seismic catalogue and waveforms under corresponding request KNDC (Kazakhstan), NORSAR (Norway), GFZ (Germany), Institute of seismology of Tajikistan, Institute of seismology of Uzbekistan.

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC Database of Kyrgyz Institute of seismology Ø Seismic catalogue since 250 BC till present time. It contains information about 138000 earthquakes. Ø Seismic bulletins since 1950. Ø Archive of analogue seismograms both of earthquakes and different type of explosions since 1927. Archive of scanned seismograms of nuclear explosions (some part of them were digitized). Ø Catalogue of chemical explosions since 1990 till present time. Ø Catalogue of geomagnetic data since 1989 till present time. Ø Catalogue of geochemical data since 1988 till present time. Ø Catalogue of microshocks since 1987 till present time. Ø Catalogue of focal plane solutions since 1946 till present time. Ø Catalogue of tilting and strain data since 1986 till 2003.

INSTITUTE OF SEISMOLOGY, NATIONAL ACADEMY OF SCIENCES, KYRGYZ REPUBLIC EXAMPLES OF SOME SCIENTIFIC PRODUCTS OF IS NAS KR Year Mon. Day Hour Min Sec Lat Long kt K Mpv Ms Vp/Vs Mw 2014 9 13 17 15 60, 0 42, 33 78, 35 2 9, 7 4, 2 3, 0 2014 9 13 19 37 5, 6 40, 90 77, 72 2 6, 1 2, 4 1, 2 1, 71 3, 9 2014 9 13 20 11 26, 0 39, 03 71, 03 4 6, 8 2, 7 1, 5 2014 9 13 20 18 18, 8 42, 32 78, 30 2 5, 1 2, 0 1, 4 2014 9 13 20 43 51, 0 42, 15 73, 53 2 4, 3 1, 9 0, 9 2014 9 13 20 49 53, 6 42, 95 77, 03 2 6, 5 2, 7 1, 3 2014 9 13 21 40 14, 3 42, 25 78, 48 2 4, 7 1, 9 2014 9 13 21 42 52, 8 42, 30 78, 53 2 4, 5 1, 9 0, 3 2014 9 13 22 1 31, 7 42, 35 78, 35 2 6, 9 3, 1 2, 0 1, 69 2014 9 13 22 4 1, 2 42, 30 78, 43 2 4, 3 1, 7 0, 7 1, 72 2014 9 13 22 56 2, 1 43, 32 75, 00 4 6, 0 2, 5 1, 3 1, 72 2014 9 14 19 20 57, 5 41, 07 74, 80 2 8, 9 3, 7 2, 6 2014 9 14 19 50 27, 7 40, 18 77, 42 5 5, 4 2, 3 1, 2 2014 9 14 20 5 39, 1 42, 20 79, 65 5 9, 4 4, 4 3, 2 1, 71 1, 73 3, 5
