Institute of Renewable Energy of National Academy of Sciences of Ukraine Yuriy Favorskyy www. ive. org. ua info@ive. org. ua +38 044 537 -26 -57 Kyiv, Ukraine

Department of Complex energy systems Department of wind power Department of solar energy Structure of Institute of renewable energy of Ukraine Department of organic energy sources Windpower Center of Ukraine Department of hydro energetic Department of geothermal energy Department of implementation Crimea technical and science center of energy saving and renewable energy

The multipurpose integrated hybrid wind/PV energy system with control and converting unit (CCU) for autonomous & grid reserve energy supply

Wind energy conversion system (WECS) • with the aeromechanical pitch regulation system • with low-speed synchronous generators with permanent magnets (PMG) • including hybrid wind/PV control and converting unit (CCU).

Structure diagram Technology description CPU – processor; I 1 – wind turbine generator curren sensor; I 2 – inverter and charging unit current sensor; U – battery voltage sensor; Bat - battery; F – fan; W – wind turbine; WCC – wind turbine generator current controller; LCD – liquid crystal display; S – sound; I/CU – unit that works in inverter o charging unit modes; Output 220 V – output outlet; CP – control panel; R 1 – relay that connects output 220 V to the inverter or to the grid; Input 220 V – outlet for connection to the grid 220 V; T 1 – battery temperature sensor; T 2 – radiator temperature sensor; GCU – grid control unit;

The aeromechanical pitch regulation system The blades are turned around their axles by the stabilizers which are placed behind trailing edges of the blades. This system was proposed by professor G. Sabinin in the fifties. We improved this system by changing the method of stabilizer deflection. Our aeromechanical pitch regulation system ensures reliable and effective Wind turbine operation at the wind speed from 2. 5 to 55 m/s even when wind is gusty. Low rated wind speed Our wind turbines have rated wind speed about 7. 5 – 9 m/s. It is lower than rated wind speed of the most similar wind turbines of the other manufacturers. Technology description

The comparison of VEU-075 with two other windmills. VEU-075 has higher power in the most widespread range of wind speed (from 3 to 7 m/s). So , it produces more energy per month at the same average wind speed. WEU-075 Instantaneous power dependence on the wind speed Power output dependence on the average wind speed (per month) The differences and advantages

Price and price per k. W of the most similar Wind turbine of other manufacturers Name Inclin 600 Rutland FM 1803 Espada VEU-075 Country Rated Power, P, k. W Price, Є Spain 0, 6 1975* Germany 0, 7 Netherlands 0, 75 Ukraine 0, 75 Price per k. W, Є/Kw Wind speed Cut-in Rated Cut-out 3292 3, 5 11 13 1809** 2584 3 15 - 2750*** 3666 3 14 - 700 933 850* 1130 2, 5 7, 5 - 900** 1200 950**** 1260 Whishep H 40 USA 0, 9 2636 2929 3, 4 12, 5 - Whishep H 80 USA 1 4187 3, 1 10, 5 - Netherlands 1, 4 3807 2719**** 2, 5 14, 0 - Passaat *- Incl. 7 m. Mast ** - Incl. Batt. Charge. Control *** - Incl. 6 m. Mast **** - Incl. 12 m. Mast Wind Energy 2003 - Steinbacher Druck Gmb. H, Osnabruck, Germany The differences and advantages

The CCU differences and advantages Technologies Strengths 1. multipurpose integrated Our hybrid control and technology Weaknesses converting unit 2. temperature compensation 3. special regime`grid energy saving We need to increase numbers of the additional functions, for example: parallel works with diesel and gas generators; using of several types of storage batteries. Southwest Windpower, USA 1. SRC-based shunt –type controller 2. Compatibily with any inverter 1. Not multipurpose control and converting 2. Not integrated hybrid unit. Green power, Germany 1. multipurpose (water) integrated hybrid control and converting unit 1. Not ‘sinus’ output AC.

Market opportunity § 1. 6 bill of people haven’t § electricity § 0. 5 bill have interrupted § 0. 5 bill can sale to grid § BUT IT’S ONLY INDIVIDUALS

CCU applications Wind for growing systems market Hybrid wind/PV autonomous systems Hybrid wind/PV/hydro with diesel/gas generators autonomous systems Hybrid systems with grid reserve for uninterrupted energy supply for saving money Hybrid systems with grid connected for making money (green tariffs)

Є Value present market Wind Є 0. 5 b Hybrid wind/PV Є1 b Hybrid wind/PV/hydro with diesel/gas generators Є2 b Hybrid systems with grid reserve for uninterrupted energy supply Є1 b Hybrid systems with grid connected Є 1. 5 b

key strategic partners wind/PV/hydro venders and installers diesel/gas venders and installers Average CCU world price 1200 Є per k. W for autonomous systems OUR price Є 800 AII DATES FOR AVERAGE 1 k. W system 9/13/2021 13

Our market strategy § create local marketing trade centers with demonstration any type samples; § OEM Providing system integrated solution with increasing product line

We look for: • technological improvement for work with an type energy in any regime (from stand alone to grid solution); • OEM ; • marketing and sales via strategic partners Є 0. 5 Mil for expansion of marketing and sales programs, Є 2 Mil for R&D Є 1 Mil for production scale up

Yuriy Favorskyy www. ive. org. ua info@ive. org. ua +38 044 537 -26 -57 Institute of Renewable Energy of National Academy of Sciences of UKRAINE Kyiv
