IDK Corporation 100 Giapponese IDK significa Iwasaki Denki

IDK Corporation: 100% Giapponese IDK significa Iwasaki Denki Kogyo ovvero Industria Elettronica Iwasaki

IDK Corporation: 100% Giapponese

IDK Corporation: 100% Giapponese 100% Made in Japan Customer oriented technology No OEM/ODM Design Review Quality Control

HDC Series EXTENDER HDBase. T series • • • 10 prodotti + 1 (Po. H ins. ) HDMI + LAN + RS 232 VGA + AA (HDC-TH 200) Modelli 2 K Modelli 4 K Gestione EDID Long Reach Mode Stand alone, rack mountable, wall mountable Extender point – point System extender daisy chain

HDBase. T

HDBase. T 1. 0: 5 Play Convergence on a Single Cable Uncompressed ultra-HD video Control signals (IR, CEC, RS 232) Audio Power over HDBase. T (up to 100 W) 100 Base. T Ethernet Transmission distance 100 m

HDBase. T 1. 0: VS 100 chipset usati da IDK • Versione robusta non critica adatta uso PRO • Performante: 4 K@60 + LAN + RS-232 + CEC • Supporta la modalità Long Reach Mode • Integrabile per usi avanzati daisy chain, splitter ecc.

HDBase. T 1. 0: Asymetric Full-Duplex Operation Main Link transmits at 250 M/500 M from Source to Sink over the 4 -pairs while at the same time the Aux Return Channel transmits at 12. 5 M from Sink to Source UTP Cables Up to 100 m Source So. C HDBase. T Src Phy Patch RJ 45 Wall mounted link segment Patch HDBase. T Sink Phy Wall plates Main Link 4 x 250 M/500 M PAM 16 Symbols/Sec Aux Return Channel 4 x 12. 5 M PAM 8 Symbols/Sec RJ 45 Sink Soc

HDBase. T uses PAM 16 symbols. Each symbol is transmitted using 1 of 16 discrete, differential voltage levels, each representing 4 bits of data. TX Diff Peak PAM 16 TX Eye Pattern One Symbol Period 4 bits Level 0000 : 15 0001 : 13 0011 : 11 0010 : 9 0110 : 7 0111 : 5 0101 : 3 0100 : 1 1100 : -1 1101 : -3 1111 : -5 1110 : -7 1010 : -9 1011 : -11 1001 : -13 1000 : -15 PAM 16 After 100 m Channel

HDC series

HDC series HDC-H 100 D • • HDMI 4 K@60 4: 2: 0 HDCP 2. 2 e CEC compliant LAN RS-232 Trasmissione HDBase. T 4 K a 100 m Trasmissione HDBase. T 2 K a 100 m o 150 m LRM Alimentazione locale 5 V • No Po. H • No HEC • No ARC

HDC series HDC-TH 200 • • • 2 Input HDMI + VGA con auto switching HDMI 2 K@60 4: 4: 4 HDCP 1. 4 e CEC compliant VGA (RGB -> comp. ) + AA LAN RS-232 Trasmissione HDBase. T 2 K a 100 m o 150 m LRM EDID emulator Alimentazione locale 12 V • No Po. H • No HEC • No ARC

HDBase. T transmission POINT to POINT HDBase. T

HDBase. T transmission POINT to MULTI POINT

HDC-UHD series • • • • 5 apparati 2 IN = HDMI + HDBase. T con auto switching Risoluzione max 4 K@60 4: 2: 0 HDCP 2. 2, CEC e HDR compliant Multi OUT HDMI + HDBase. T LAN RS-232 De-embedder audio Down converter HDMI 1 4 K -> 2 K EDID emulator Modalità daisy chain WEB server Trasmissione HDBase. T 4 K a 100 m Trasmissione HDBase. T 2 K a 100 m o 150 m LRM Fan less Alimentazione locale 12 V

HDC-UHD series HDC-TR 121 UHD HDC-TH 221 UHD HDC-RH 221 UHD HDC-TH 421 UHD HDC-RH 421 UHD

HDC-UHD series HDC-TR 121 UHD HDC-TH 221 UHD HDC-RH 221 UHD HDC-TH 421 UHD HDC-RH 421 UHD

HDC-TR 121 UHD

HDC-TH 421 UHD

HDC-RH 421 UHD

HDC-UHD series

HDC-UHD series

HDC-UHD series

HDC-UHD series

HDC-UHD series

CASE HISTORY MILANO P 0 IDK HDC TH 100 R Ricevitore HD Base. T LG 55 SE 3 KD-B Monitor LED 55" P 1 IDK HDC TH 100 R Ricevitore HD Base. T 6 1 IDK HDC-S 400 Distributore HDBase. T 1 x 4 LG 55 SE 3 KD-B Monitor LED 55" IDK HDC TH 100 R Ricevitore HD Base. T IDK HDC-S 200 Distributore HDBase. T 1 x 2 IDK HDC TH 100 R Ricevitore HD Base. T LEGACY PRODUCTS IDK HDC-S 400 Distributore HDBase. T 1 x 4 IDK HDC TH 100 R Ricevitore HD Base. T 2 LG 55 SE 3 KD-B Monitor LED 55" 4 LG 55 SE 3 KD-B Monitor LED 55" 5 LG 55 SE 3 KD-B Monitor LED 55" 7 IDK HDC TH 100 R Ricevitore HD Base. T LG 55 SE 3 KD-B Monitor LED 55" 8 3 LG 55 SE 3 KD-B Monitor LED 55" IDK HDC TH 100 R Ricevitore HD Base. T LG 55 SE 3 KD-B Monitor LED 55" 9

CASE HISTORY IDK HDC-RH 401 1 ROMA 2 3 4 IDK HDC-RH 201 IDK HDC-RH 401 LEGACY PRODUCTS TRANSLATION BOOTHS IDK HDC-RH 401 IDK HDC-RH 100 SPEAKERS TABLE
