ICEM CFD 5 1 New Features Workshop 15

ICEM CFD 5. 1 New Features Workshop 15 Hybrid meshing of a simple HVAC assembly

ANSYS ICEM CFD v 5. 1 Create a Project Workshop Choose “Open Project“ Icon Browse to the desired working directory Enter the project name Type in the File name as: HVAC_Hybrid. prj Tips: The pull down next to the file name can be used to quickly locate recently used projects. In Windows, The File browser is a standard Windows file browser offering all the functionality of windows explorer. In Unix or Linux, similar functionality is also available. The Project file contains information about project settings, the working folder and file associations. Once the geometry, mesh, boundary conditions, parameter files etc. are saved with the project file, simply loading the project file will also load these associated files. © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -2

ANSYS ICEM CFD v 5. 1 Open Geometry Workshop Open The Geometry: File -> Geometry -> Open Geometry Or use the “Open Geometry” ICON Select: Hybrid_HVAC. tin using File Browser Display: activate Surfaces by left mouse click on icon Display Tree Display: Solid & Wire mode thru right mouse click on Surfaces in Display Tree Display: Transparent mode thru right mouse click on Surfaces in Display Tree HVAC © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -3

ANSYS ICEM CFD v 5. 1 Manage Parts Workshop Managing the Model tree will be very important for this tutorial. For your convenience, the two primary halves of the model, the Hex_Part and the Tetra_Part, have been placed in separate assemblies. The surface between the Hexa and Tetra volumes has been placed in the Interface part To turn a part or assembly on or off, click on the glasses ICON. We will start by turning the Tetra assembly OFF Hexa Interface Tetra © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -4

ANSYS ICEM CFD v 5. 1 Hexa Meshing Workshop #1 Turn off the Tetra Assembly so only the Hexa Assembly and interface Surface are active. Its time to Hex Mesh this half of the assembly. Hex meshing is not the focus of this tutorial, so we can skip the details of this step and load the blocking file I have provided Compute Pre -Mesh Load Blocking: – File => Blocking => Open Blocking Or use the Open Blocking utility icon – Open: HVACPipe. Blocking. blk Generate Mesh: – Expand the Blocking branch of the model tree – Activate the Pre-mesh and Recompute – RMB on Pre-mesh and select Convert to Unstruct Mesh – Save the project © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -5

ANSYS ICEM CFD v 5. 1 Build Topology Workshop #1 #2 Now lets switch to the tetra portion. Turn off the Hex_Part assembly and turn on the Tetra_Part assembly. #3 BUILD TOPOLOGY: #4 – – – Geometry -> Repair Geometry -> Build Diagnostic Topology Default: Tolerance is auto-calculated as 0. 1 Filter by angle: Turn on Filter points and Filter curves Default: New Part Name is set to Inherited Turn on: Only active parts • This will prevent build topology from filtering out the curves on the Hex_Part Accept other defaults and press Apply #5 Many curves are filtered out #6 #7 © 2004 ANSYS, Inc. Only essential feature curves remain October 1, 2004 Inventory #002157 WS 15 -6

ANSYS ICEM CFD v 5. 1 Set Mesh Sizes Workshop #1 #3 #2 #4 Assign Element Size: – Mesh -> Set Surface Mesh Params – Select all the surfaces with the “a” hotkey. – Set: Maximum element size to 4. – Defaults: other settings should remain 0. – press Apply. Display Element Sizes: #5 Control Display through RMB – RMB on surfaces – Select Tetra Sizes the pull-down from Tetra icons indicate tetra mesh sizes set on each surface © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -7

ANSYS ICEM CFD v 5. 1 Control Display Workshop #1 This next part is very important. We are going to mesh only the visible tetra_part of this HVAC assembly. We need to make sure that all the correct components are visible. Display: – Expand the Geometry Branch and activate all the sub branches. – Make sure the Fluid and Interface part, as well as the Tetra_Part assembly are active. – Make sure the Hex_Part assembly is inactive Save Project: – We will not be able to tetra mesh in batch mode without first saving the project © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -8

ANSYS ICEM CFD v 5. 1 Mesh Tetrahedral Workshop #1 #2 Mesh Tetrahedral: #3 – Mesh -> Mesh Tet -> From geometry – Activate: “Smooth transition” – Activate: “Run as batch process” – Activate: “Only visible geometry” – press Apply. #4 #5 #6 #7 © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -9

ANSYS ICEM CFD v 5. 1 Load Hex Mesh with Tetra Mesh Workshop #1 #2 #3 Load Hex Mesh: – File -> Mesh -> Open Mesh or use Open Mesh icon – A mesh is already loaded, how do you wish to proceed • Merge – Display all the shells and both part assemblies © 2004 ANSYS, Inc. This Merge simply concatenates the mesh files, the October 1, 2004 nodes. Inventory are not #002157 connected WS 15 -10

ANSYS ICEM CFD v 5. 1 Inspect Interface shells Workshop View the interface area: – Expand the mesh branch and the shells branch – Activate the shells branch – Turn off all the parts except interface – Turn off the geometry – Alternately display and blank the triangles and quads to see that both layers are at the interface and are non conformal Quads Triangles Overlapping Triangles and quads © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -11

ANSYS ICEM CFD v 5. 1 Inspect interface volume Display Mesh Cut Plane: – RMB on Mesh, select Cut Plane – The Define Cut Planes window appears Workshop – Display Mesh Volumes in the model tree – Zooming in reveals that the mesh needs to be merged – Change Method to Middle-X – Adjust Fraction value to 0. 65 © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -12

ANSYS ICEM CFD v 5. 1 Merge Mesh #1 Workshop #2 #3 #6 #4 #5 #7 Merge mesh: – Edit Mesh => Repair Mesh => Merge Meshes – Method: Merge volume meshes – Merge surface mesh parts and select the INTERFACE Part. – Accept and Apply Observe: Using the cut plane, observe that the mesh is now node for node conformal across the interface. © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -13

ANSYS ICEM CFD v 5. 1 Delete shells Workshop #1 #2 #3 The interface quads still remain #4 Delete the Interface shell mesh: – Edit Mesh => Delete Elements – Use the Select mesh elements tool bar to select items by part – select the INTERFACE part. – Accept #5 The interface surface mesh is removed opening up the part for flow. Save the Project © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -14

ANSYS ICEM CFD v 5. 1 Mesh Prism Workshop #1 #3 Add Prism Layers: #4 – Mesh => Mesh Prism – Name the New volume part “Prism” • #6 – #7 #5 #8 © 2004 ANSYS, Inc. #2 Normally, leave this blank and the prisms will inherit their volume part from the original volume Select parts to mesh • From the popup, select all the parts except the inlet, outlets and interface • Leave the other fields blank • Accept – Set: Initial height to 0. 6 – Default: Height ratio of 1. 2 – Set: Number of layers to 2 – Compute Params to calculate total height – Accept the other defaults – Apply – Load the Prism Mesh! October 1, 2004 Inventory #002157 WS 15 -15

ANSYS ICEM CFD v 5. 1 Display Hybrid Mesh Workshop Display: – – Using the Mesh Cut Plane and transparent surfaces, view the mesh • The Prism portion is currently an orange color, while the tetra and Hexa are blue and dark blue respectively. On the outer surface, the shells (tri or quad) take on the color of their respective surfaces • The Volume element types now list Prisms More/thicker layers are possible, but limited by the height of the first volumetric hexa • © 2004 ANSYS, Inc. Prism layers can also be split and redistributed from the Edit Mesh menu October 1, 2004 Inventory #002157 WS 15 -16

ANSYS ICEM CFD v 5. 1 Next steps Quads Workshop Tris Observe: – In the interface region, the prisms are uninterrupted Next Steps: Prisms Tetras Hexas – The elements may all need to be in one volume, use the model tree to add all three volume regions into one volume part. – Smoothing/Diagnostics/Repair – Use the Output tab to select a solver – Apply Parameters and boundary conditions if desired – Export to solver Pyramids © 2004 ANSYS, Inc. October 1, 2004 Inventory #002157 WS 15 -17
