IBM Systems Platformy serwerowe IBM Systems Jarosaw Jackowiak
IBM Systems Platformy serwerowe IBM Systems Jarosław Jackowiak Software IT Architect IBM Software Jaroslaw. Jackowiak@pl. ibm. com 9/9/2020 © 2007 IBM Corporation
IBM Systems System i 5 System p 5 System z 9 System x Solutions Performance 2 Clustering Scalability Availability 9/9/2020 © 2007 IBM Corporation
IBM Systems Nowe trendy technologiczne w serwerach § Procesory wielordzeniowe – Dwa rdzenie 2005 -06 – Cztery rdzenie 2007 -01 (Intel), 2007 -06 (AMD) – Nowe możliwości dla wymagających aplikacji § Wirtualizacja serwerów – Coraz częściej do wirtualizacji stosuje się serwery dwuprocesorowe – Wirtualizacja umożliwia obniżenie kosztów operacyjnych – Umożliwia pełne wykorzystanie mocy serwerów § Zarządzanie mocą – Zasilanie i chłodzenie centrum przetwarzania danych stało się prawdziwym wyzwaniem (zasilacze 800 W w 2 -proc) – Aktywne zarządzanie zasilaniem będzie bardzo ważne w przyszłości 3 9/9/2020 © 2007 IBM Corporation
IBM Systems Architektura Intel vs. AMD Front-side Bus Architecture Core CPU Direct Connect Architecture 8 GB/S Core CPU SRQ Crossbar Mem. Ctrlr HT 8 GB/S I/O Hub Memory PCI-E Controller Bridge Hub PCI-E Bridge PCIc™ 8 GB/S PCIc™ Bridge 8 GB/S USB I/O Hub • All CPUs share common (or dual) FSB to memory and IO • FSB bus is proprietary • Memory is shared by all CPUs and cores 4 PCI • Each CPU socket has dedicated memory and controller • Peripherals connected via industrystandard Hyper. Transport Bus • CPUs communicate via coherent Hyper. Transport Bus 9/9/2020 © 2007 IBM Corporation
IBM Systems Architektura AMD - cztery rdzenie Native Dual-Core SRQ Crossbar Mem. Ctrlr HT Native Dual-Core 8 GB/S SRQ Crossbar Mem. Ctrlr HT 8 GB/S PCI-E Bridge 8 GB/S USB I/O Hub PCI 5 9/9/2020 © 2007 IBM Corporation
IBM Systems IBM System x – nowa struktura nazw IBM Blade. Center IBM Intelli. Station IBM Cluster 1350 6 (5) or 0) Int el ® (0) r( we To 2 nd # 3 rd # AM D (5) ac k or r ść cjo na lno 1 st # Fu nk x 3400 x 3550 x 3650 x 3455 x 3950 E x 3850 x 3800 x 3650 T 86 x 226 x 236 x 346 e 326 x 460(MXE) x 366 x 260 x 343 § Pełna nazwa = IBM System x#### § Nazwa skrócona = x#### =x 2006 Q 3 “ 3 ” 2006 Q 1 4 th # IBM Blade. Center IBM Intelli. Station IBM Cluster 1350 9/9/2020 © 2007 IBM Corporation
IBM Systems Portfolio serwerów IBM System x Scale up / SMP computing Large symmetrical multiprocessing (SMP) Clusters and virtualization High density x 3950 Cluster 1350 x 3850 x 3655 x 3800 x 3650 x 3755 LS 41 Blades x 3550 x 3455 x 3100 x 3200 x 3400 x 3500 x 3250 HS 21 LS 21 Blade. Center H Scale out / distributed computing Source: IDC 7 tended Design Architecture 9/9/2020 © 2007 IBM Corporation
IBM Systems Procesory AMD Opteron 8000 Series w Serwerach x x 3755 – Niskie koszty, duża pamięć HPC węzeł LS 41 – Skalowany enterprise blade serwer x 3455 – Węzeł obliczeniowy o wysokiej wydajności x 3655 – Wydajny serwer biznesowy LS 21 Wysokiej wydajności blade serwer 8 9/9/2020 © 2007 IBM Corporation
IBM Systems LS 41 Blade Server LS 41 with 2 P Easy upgrade from 2 P to 4 P Features – Double width blade form factor – Processors: up to four Next-Generation Dual-Core AMD Opteron™ 8000 series processors (68 watt or 95 watt – 95 watt requires BCH chassis) – Memory: 8 DIMM slots per processor; 64 GB DDR 2 667 MHz max LS 41 with 4 P – Internal Storage: two cabled SAS hard drives – I/O: two dual Gigabit Ethernet plus two daughtercard slots (infiniband HCA, FC HBA, E-Net) – Systems Management: Via Blade. Center chassis Industry’s first snap-in scalable blade. Singlewidth 2 P LS 41 can be upgraded to a 4 P via an expansion unit that snaps in place in minutes. 9 9/9/2020 © 2007 IBM Corporation
IBM Systems LS 21 and LS 41 internal photos Connectors for MEU LS 41 “Multiprocessor Expansion Unit” LS 41 base board LS 21 Adds 2 more 8000 series Opterons to LS 41 base board, uses additional slot 2 P using 8000 series 2 P (max) using 2000 Opterons series Opterons No connectors for MEU 11 9/9/2020 © 2007 IBM Corporation
IBM Systems IBM System p 5 9/9/2020 © 2007 IBM Corporation
IBM Systems IBM liderem sprzedaży UNIXów w Polsce. . . Jedyna platforma z tendencją wzrostową według raprotu IDC! Sprzedaż serwerów UNIXowych w Polsce – drugi kwartał 2006 *IDC Worldwide Quarterly Server Tracker, 02/06 13 9/9/2020 © 2007 IBM Corporation
IBM Systems Wirtualizacja / Mikropartycjonowanie systemów p 5 DO 80 PARTYCJI • partycje mogą pracować pod różnymi systemami operacyjnymi (AIX, Linux, i 5/OS) Aplikacja 1 Apl 2 Apl 3 Aplikacja 4 AIX 5 i 5/0 S • dowolne alokowanie zasobów między partycjami (min. kwant 1/10 cpu) 6 7 8 LINUX A A L L DISK D D DISK • pełna izolacja między partycjami MEM • zasoby mogą być dynamicznie przydzielane i zwalniane • implementacja Virtual I/O, Virtual Ethernet 5 M M MEM • HMC/IVM – centralny punkt do zarządzania 4 CPU 2 CPU ½ CPU C C HYPERVISOR STACJA ZARZĄDZAJĄCA 14 SERWER (8 CPU) 9/9/2020 © 2007 IBM Corporation
IBM Systems Procesor – od serwera do Play. Station Technologiczna roadmap’a Serwery kasetowe Elektronika użytkowa POWER 3™ POWER 2 Power. PC 603 e Power. PC 750 Power. PC 401 POWER 4+™ POWER 4™ Power. PC 750 CXe Power. PC 750 GX Power. PC 405 POWER 5+ POWER 5 Power. PC 970 FX Power. PC 970 MP Cell Power. PC 440 Source: http: //www. ibm. com/chips/power/aboutpower/ 15 9/9/2020 © 2007 IBM Corporation
IBM Systems IBM System p 5 Express – więcej mocy w niższej cenie • Popularne , proste do zamówienia konfiguracje serwerów System p 5 po obniżonych cenach • Dostępne w edycji AIX 5 L z systemem AIX • Dostępne w edycji Open. Power z systemem Linux • Dają możliwość modyfikacji bazowych elementów zestawu w celu dopasowania do wymagań środowiska aplikacyjnego 16 9/9/2020 © 2007 IBM Corporation
IBM Systems 17 200 USD 7 000 USD Serwery Express 3 880 USD p 5 185 do 2 POWER PC 970 5 600 USD 4 570 USD p 5 505 do 2 POWER 5+ DCM do 4 POWER 5+ QCM p 5 510 do 2 POWER 5+ DCM do 4 POWER 5+ QCM inux , L AIX 5. 3 p 5 550 do 4 POWER 5+ DCM p 5 520 do 2 POWER 5+ DCM do 8 POWER 5+ QCM do 4 POWER 5+ QCM Red , 9 S E SL Procesor oparty o architekturę POWER Pamięć DDR 2* Gniazda PCI-X 2 zintegrowane porty 10/1000 Eth Procesor serwisowy Obudowa wolnostojąca lub rackowalna (możliwa konwersja)** Hat 4 Wirtualizacja & mikropartycjonowanie jako opcja* Partition Load Manager* Integrated Virtual Manager * Trzyletnia gwarancja w zakresie 5/11 w cenie sprzętu *Serwer p 5 185 wyposażony jest w pamięć DDR 1, nie posiada także opcji wirtualizacji **Dotyczy modeli 185, 520 oraz 550 17 9/9/2020 © 2007 IBM Corporation
IBM Systems Dziękuję za uwagę! Kontakt w sprawie serwerów x: Piotr Nowik Piotr. Nowik@pl. ibm. com Jarosław Jackowiak Software IT Architect IBM Software Jaroslaw. Jackowiak@pl. ibm. com 9/9/2020 © 2007 IBM Corporation
IBM Systems 1, 2, & 4 Socket Tower Servers x 3105 x 3200 x 3400 x 3500 x 3800 Ideal Small Business Server Affordable Enterprise Class Availability Affordable Performance for Growing Business Stable Business Critical Application Server High Performance All -in-One Server Tower, 1 Socket 5 U, 2 Socket 7 U, 4 Socket Proc: Opteron Proc: Xeon UP Proc: Xeon 5130 Proc: Xeon 5160 Proc: Xeon MP Mem: 4 DIMM / 8 GB Mem: 8 DIMM / 32 GB Mem: 12 DIMM / 48 GB Mem: 16 DIMM / 64 GB HDD: 2 HDD: 4 HDD: 8 HDD: 12 Przykład aplikacji Przykład aplikacji • File & Print • Branch Office • Security • Virtualization • Small business management • Security • Email / Collaboration • Web Serving • Database • Point-of-sale • File & Print • Virtualization • ERP/SCM/CRM/PLM HPC HPC HPC BPC BPC Bus. App. Infr. App. 19 x 3105 Infr. App. x 3200 Infr. App. x 3400 Bus. App. Infr. App. 9/9/2020 x 3500 Bus. App. x 3800 Infr. App. © 2007 IBM Corporation
IBM Systems 1 & 2 Socket System x Rack Servers x 3250 x 3455 x 3550 x 3655 Affordable, Easy-touse Server High Performance Compute Node Application Density for Power Managed Datacenters Stable Business Critical Application Server Business Performance Server 1 U, 1 Socket 1 U, 2 Socket 2 U, 2 Socket Proc: Xeon UP Proc: Opteron Proc: Xeon 5160 Proc: Opteron Mem: 4 DIMM / 8 GB Mem: 12 DIMM / 48 GB Mem: 8 DIMM / 32 GB Mem: 12 DIMM / 48 GB Mem: 16 DIMM / 64 GB HDD: 4 HDD: 2 HDD: 4 HDD: 8 Przykład aplikacji Przykład aplikacji • Branch Office • Cluster / HPC • Database • E-mail/Collaboration • Business Intelligence • Security • Modeling & Simulation • E-mail/Collaboration • Virtualization & SCON • Digital Media (IPTV/Vo. D) • Hosted Client • ERP/SCM/CRM/PLM • Web serving • File & Print • Research HPC BPC Bus. App. Infr. App. 20 x 3250 HPC HPC BPC BPC Bus. App. Infr. App. x 3455 x 3550 Bus. App. Infr. App. 9/9/2020 x 3655 Bus. App. Infr. App. © 2007 IBM Corporation
IBM Systems 4+ Socket System x Rack Servers x 3755 x 3850 x 3950 HPC Large Memory Compute Node Commercial Enterprise & Midmarket Server High Performance Scalable Datacenter Server 4 U, 4 Socket 3 U-24 U, 4 -32 Socket Proc: Opteron Proc: Xeon MP Mem: 32 DIMM / 128 GB Mem: 16 DIMM / 64 GB Mem: 16 DIMM/ 64 GB per HDD: 6 HDD: 4 HDD: 6 per Przykład aplikacji • Cluster / HPC • Database • Modeling & Simulation • ERP/SCM/CRM/PLM • Virtualization /SCON • Virtualization/SCON • Business Continuity • Research HPC BPC 21 x 3755 HPC BPC Bus. App. Infr. App. x 3850 Bus. App. x 3950 Infr. App. 9/9/2020 © 2007 IBM Corporation
IBM Systems System x 3455 Next-Generation high performance node Features – 1 U rack optimized form factor – Processors: up to two Next-Generation Dual. Core AMD Opteron™ 2000 series processors – Memory: 6 DIMM slots per processor; 48 GB DDR 2 667 MHz max – Internal Storage: Up to two cabled SATA hard drives (cabled SAS option) – I/O: Two PCI Express x 16 or one PCI Express x 16 and one HTX – Systems Management: Baseboard management controller with IPMI 2. 0 – Network Interface: Dual Gigabit Ethernet (TOE) 22 9/9/2020 © 2007 IBM Corporation
IBM Systems System x 3655 Versatile data center server Features – 2 U rack optimized form factor – Processors: up to two Next-Generation Dual-Core AMD Opteron™ 2000 series processors – Memory: 8 DIMM slots per processor; 64 GB DDR 2 667 MHz max – Internal Storage: Up to six HP SAS 3. 5” hard drives or up to eight HP SAS 2. 5” hard drives – I/O: Three PCI Express x 16 or two PCI Express x 16 and one HTX – Availability: Redundant power, redundant HS fans, HS hard drives – Systems Management: BMC with IPMI 2. 0 optional slotless IBM RSA card for out of band management – Slotless RAID controller – Network Interface: Dual Gigabit Ethernet (TOE) 23 9/9/2020 © 2007 IBM Corporation
IBM Systems System x 3755 Powerful virtualization and ERP Features – 4 U rack optimized form factor – Processors: up to four Next-Generation Dual. Core AMD Opteron™ 8000 series processors – Memory: 8 DIMM slots per processor; 128 GB DDR 2 667 MHz max – Internal Storage: Up to four HP SAS hard drives – I/O: Four PCI Express, two PCI-X and one HTX – Availability: Redundant power, redundant HS fans, HS hard drives – Systems Management: Baseboard management controller with IPMI 2. 0 optional out of band slotless RSA card – Slotless RAID controller – Network Interface: Dual Gigabit Ethernet 24 9/9/2020 © 2007 IBM Corporation
IBM Systems LS 21 Blade Server Powerful 2 P blade solution for mission critical use Features – Single width blade form factor – Processors: up to two Next-Generation Dual-Core AMD Opteron™ 2000 series processors (68 watt or 95 watt – 95 watt requires BCH chassis) – Memory: 4 DIMM slots per processor; 32 GB DDR 2 667 MHz max – Internal Storage: one cabled SAS hard drive – I/O: dual Gigabit Ethernet plus daughtercard slot (infiniband HCA, FC HBA, E-Net) – Systems Management: Via Blade. Center chassis 25 9/9/2020 © 2007 IBM Corporation
IBM Systems System x 3105 1 P Tower Server Features – Pedestal Tower Form Factor – Processors: One next-generation 1000 series Opteron processor OR one Athlon 3500+ single core processor – Memory: 4 DIMM slots; 16 GB DDR 2 667 MHz max – Internal Storage: two cabled SATA Hard Drives (1 TB max) – I/O: 2 PCIe (8 x, 8 x), 2 PCI-X – Other Bays: (2) 5. 25” bays (CDRW/DVD combo + Optical Drive or Tape. (1) 3. 5” bay for optional diskette drive. – Network Interface: one integrated Gb Ethernet – Ports: 2 USB in front; 4 USB in rear, plus one ethernet, parallel and serial in rear. 26 9/9/2020 © 2007 IBM Corporation
