IB Fertilization Pregnancy IB Assessment Statement Copyright 2005

IB Fertilization & Pregnancy

IB Assessment Statement Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilization • Fertilisation occurs in the oviducts (fallopian tubes) • p. H of vagina is acidic and p. H of semen is basic. Thus they neutralize each other.

Fertilization • Contraction of the uterus and oviducts help move the sperm into the oviducts. • One or more sperm will reach the oocyte in the oviduct. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • The oocyte is surrounded by a coat that consists of a glycoprotein called a zona pellucida. • The zona pellucida must be crossed by the sperm. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • Contact between the zona pellucida and proteins in the sperm cells membrane

Fertilisation • The acrosome vesicle fuses with the sperm plasma membrane and releases enzymes that digest a path through the zona pellucida. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • Hydrolytic enzyme that are located in the sperm’s head, called acrosomes. • These acrosomes enzymes digest a pathway for the sperm to enter the oocyte. • This process is called capacitation.

Fertilisation • The membrane of the sperm cell and the ovum fuse together. • At the same time this results in a release of Ca 2+ from the endoplasmic reticulum. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • The cortical vesicle fuse with the plasma membrane of egg cell releasing enzymes that destroy the sperm binding proteins on the zona pellucida. • This prevents polyspermy. (more than one sperm from entering Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • The release of Ca 2+ also activate meiosis and prepare the oocyte cell for completion Meiosis II. Oocyte undergoes meiosis II. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • The head of the sperms contain its nucleus. • The sperms nucleus fuses with the oocyte nucleus for the final stage of fertilisation. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilisation • The new diploid nucleus undergoes mitosis • The division of cytoplasm occurs forming the first two cells of the embryo. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fertilization & Pregnancy • Fertilization and Implantation Copyright © 2005 Pearson Education, Inc. publishing

Early development of Zygote • Fertilization occurs in the oviduct Copyright © 2005 Pearson

Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB LEARNING OBJECTIVE • Outline early embryo development up to the implantation of the

Early development of Zygote • After fertilization, the zygote undergoes cleavage and develops into a blastocyst before implantation in the endometrium Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early development of Zygote • Zygote is transplant to the uterus by ciliary (small moving hair-like proteins) action in the oviduct • The fertilized egg undergoes cleavage. • Cleavage is the mitotic division of the zygote into a mass of daughter cells. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early development of Zygote • When the embryo reaches the uterus is has undergone both cleavage and has formed a blastocysts. • A blastocyst is a tiny solid ball of cells. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early development of Zygote • In humans, by 7 days the blastocysts consists of about 100 cells • It becomes imbedded in the endometrium, a process called implantation. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early development of Zygote • The inner cell mass of the blastocyst eventually becomes the fetus. • Once implanted the embryo starts to receive nutrients from the endometrium of the uterus wall. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB LEARNING QBJECTIVE • State that the fetus is supported and protected by the

Early development of Zygote • Pregnancy, or gestation, is the condition of carrying one

Gestation – zygote to embryo to fetus in human • Gestation – the period of development in the mother’s body, lasting from conception to birth. • First 2 months of gestation the developing baby is referred as an embryo. • The embryo is protected in amniotic fluid and amniotic sac. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early Development Amniotic sac • A fluid-filled amniotic sac, which cushions and protects the developing embryo. Placenta Umbilical cord Uterus Amnion Fetus Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Early Development –Amniotic Fluid Amniotic sac • The fetus floats in the amniotic fluid. Placenta Umbilical cord • This fluid acts as a shock absorber. Uterus Amnion Fetus Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB LEARNING OBJECTIVE • State that materials are exchanged between the maternal and fetal

• During its first 2 to 4 weeks, the embryo obtains nutrients directly from the endometrium • Meanwhile, the outer layer of the blastocyst mingles with the endometrium and eventually forms the placenta • Blood from the embryo travels to the placenta through arteries of the umbilical cord and returns via the umbilical vein

• The outer layer of the embryo gives rise to the placenta & the maternal endometrium • It is a disc shaped structure that allows for an exchange of material between fetus and mother

The outer layer of the embryo gives rise to the placenta & the maternal endometrium It is a disc shaped structure that allows for an exchange of material between fetus and mother Maternal arteries Maternal veins Placenta Maternal portion of placenta Umbilical cord Chorionic villus containing fetal capillaries Fetal portion of placenta (chorion) Maternal blood pools Uterus Fetal arteriole Fetal venule Umbilical cord Umbilical arteries Umbilical vein

The placenta Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

The Placenta • A disc shaped structure composed of maternal endometrial and fetal membrane. • Exchange in the placenta – is by diffusion and active transport, and involve: – Respiratory gases – Oxygen and carbon dioxide – Water – Excretory products (urea) – Antibodies ( immunity from diseases) Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Maternal, foetal exchanges across placenta The foetus develops and grows using materials obtained by exchange across the placental wall from mother to child. Excretory products are exchanged in the opposite direction from child to mother. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB Learning Objective • Explain how the structure and functions of the placenta, including its hormonal role in secretion of estrogen and progesterone, maintain pregnancy. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta • The female blood supply which supplies the foetus with oxygen and nutrient. • It will also remove waste from the foetal blood and excrete this through the maternal systems. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta a. Umbilical cord connects the fetus to the placenta b. There are two umbilical arteries that carry the deoxygenated fetal blood to the placenta. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta c. The single umbilical vein returns the oxygenated blood to the rest of the foetal circulation. d. The placenta is normally about 190 mm wide and 20 mm deep. The human placenta is more deeply integrated into the maternal tissue than any other animal. • Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta e) The myometrium is composed on smooth muscle in the uterus that produces the contraction in labor. f. The endometrium which is maintained through out pregnancy by progesterone. Initially from the corpus luteum and later from the placenta itself. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta g) The female blood supply which supplies the foetus with oxygen and nutrient. It will also remove waste from the foetal blood and excrete this through the maternal systems. h) Open ended blood arterioles and capillaries that produce the intervillous 'blood lakes’. i) Inter-villus spaces filled with maternal blood. These surround the placental villi and allow for very efficient exchange. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta • Open ended blood arterioles and capillaries that produce the inter-villous 'blood lakes'. • . Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta • Inter-villus spaces filled with maternal blood. These surround the placental villi and allow for very efficient exchange. • Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Structure and function of placenta • g) Placental-Villi with large surface area for the

Structure and function of placenta • Placental-Villi with large surface area for the exchange

Structures that allow the Exchange of Material Across the Placenta Copyright © 2005 Pearson

IB Learning Objective • Explain the oxygen dissociation curves of adult hemoglobin, fetal hemoglobin

Fetal Haemoglobin • This means that the fetal haemoglobin will combine more readily oxygen than the mother’s haemoglobin at the same partial pressure. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Fetal Haemoglobin • Why is the case? – If the mother’s haemoglobin had a stronger affinity for oxygen than the fetus’s haemoglobin, then the oxygen would pass from the fetus to the mother. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB Learning Objective Outline the role of HCG in early pregnancy. . Copyright ©

The placenta as an endocrine gland • The placenta secretes the hormone, human chorionic gonadotrophin (HCG) • HCG appears in the urine 3 days after conception. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

The placenta as an endocrine gland • HCG is first secreted by the blastocyst cell of the embryo. • HCG maintains the Corpus luteum ( a temporary gland) that secretes oestrogen and progesterone. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

HCG HORMONE & Pregnancy • The HCG targets the ovary and the corpus luteum. • The corpus luteum secretes progesterone and oestrogen at high levels. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

HCG HORMONE & Pregnancy • The oestrogen and progesterone continue to inhibit FSH and LH secretion from the pituitary. • The progesterone's prevent the breakdown of the endometrium and so the embryo can continue its development into a foetus Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

IB Learning Objective • Outline the process of birth and its hormonal control, including the changes in progesterone and oxytocin levels and positive feedback Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Hormone control & the process of giving Birth • Before birth, the level of progesterone declines sharply • This decline causes contraction of the muscles of the uterine lining. Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Hormone control & the process of giving Birth • At the same time, the pituitary gland releases the hormone oxytocin. – This hormone relaxes the elastic fibers of the bones to the pelvic girdle, and dilates the cervix. – Uterine contractions separate the placenta from the endometrium, Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Positive Feedback between oxytocin & Uterine contraction • In this system the stimuli to the brain increases the oxytocin production • In turn the oxytocin stimulate uterine contraction • Uterine contractions further stimulates the pituitary of the mother to release more oxytocin Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Positive Feedback between oxytocin & Uterine contraction • The strength and frequency of the uterine contractions is further increased. • In turn this further stimulates more oxytocin production • The process builds with stronger and stronger contractions Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

Positive Feedback between oxytocin & Uterine contraction • Finally the child passes though the cervix and vagina to be born • Contractions continue for a further period until the placenta is delivered (after birth). Copyright © 2005 Pearson Education, Inc. publishing as Benjamin Cummings

LE 46 -18 from ovaries Oxytocin from fetus and mother’s posterior pituitary Induces oxytocin receptors on uterus Stimulates uterus to contract Stimulates placenta to make Progesterone Stimulate more contractions of uterus Positive feedback Estrogen

LE 46 -19 Placenta Umbilical cord Uterus Placenta (detaching) Uterus Cervix Umbilical cord Dilation of the cervix Expulsion: delivery of the infant Delivery of the placenta

LE 46 -21 Head Body
