HYPACK SHELL 10232021 2006 HYPACK Training Seminar 1
- Slides: 20
HYPACK SHELL 10/23/2021 2006 HYPACK® Training Seminar 1
Menu Selection HYPACK® Shell Major Program Icons Upper Information Bar Data Files Map View Map Tool Bar Project Files Lower Information Bar 10/23/2021 2006 HYPACK® Training Seminar 2
Map Tools Zoom In/Out Zoom Window Pan Zoom Extents Rotate Counter-Clockwise Rotate Clockwise Enter Rotation Snap to Grid North S-57 Query Tool Normal Cursor Redraw Screen Return to Previous Zoom AVI Return to Editor Open Color Dialog 10/23/2021 2006 HYPACK® Training Seminar 3
Data and Project Files Data Files – Raw Data Files (SURVEY) – Edited Data Files (SBMAX) – Sorted Data Files Project Data Files – Advanced Channel Design (CHN) – Background Files (DXF, S-57, TIF…) – Border Files (BRD) – Channel Plan Files (PLN) – Kinematic Tidal Datum Files (KTD) – Matrix Files – Planned Line Files (LNW) – Plotting Sheet Files (PLT) – Sound Velocity Files (VEL) – Target Files (TGT) – Template Files (TPL) – Tide Files (TID) – Bucket Files (BKT) 10/23/2021 2006 HYPACK® Training Seminar 4
Data and Project File Status Red Page – Displayed on map White Page – Not Displayed Red ‘X’ – Can’t be found Been deleted No network access No network permission AVI 10/23/2021 2006 HYPACK® Training Seminar 5
Settings Window Control the Display of: – Soundings – Track Lines – Charts – Targets – Lat-Long Grid – Projection Grid – Planned Lines AVI 10/23/2021 2006 HYPACK® Training Seminar 6
Automatic Searching adds new files to the Data Files and Project Files listings after returning from other programs. We disable it when working with big files. 10/23/2021 2006 HYPACK® Training Seminar 7
Projects Each survey is stored as a separate ‘Project’. Local projects are stored on your own computer. Network projects can be accessed: – Other computers on the network – Another directory or drive on your computer. Office Data Server 10/23/2021 What’s in a Project Network Connection 2006 HYPACK® Training Seminar HYPACK Computer 8
Project Manager Open local or network projects. Make a local copy of a network project. Make a network copy of a local project Define the location of your ‘network’ projects. Delete (from the list) existing projects. AVI 10/23/2021 2006 HYPACK® Training Seminar 9
Network Project Location Specify: – Any local drive and directory. – Any drive and directory on a network accessible computer. Can be changed at any time. User must have read and write privileges on network computer. 10/23/2021 2006 HYPACK® Training Seminar 10
Delete Project ‘Delete project’ removes a project from the Project Manager listing. It does not delete the project from your hard drive. Deleted projects can be ‘Restored’ to list. To permanently delete projects, use Windows Explorer. 10/23/2021 2006 HYPACK® Training Seminar AVI 11
Directory Structure New Projects: – Local: Created under HYPACKProjects directory. – Network: Created under specified directory. RAW-EDIT-SORT subdirectories are auromatically created under the ‘Projectname’ directory. Don’t use illegal filename characters when naming a new project (|”’; : /@*…) 10/23/2021 2006 HYPACK® Training Seminar 12
Working with Projects Open Project: – Opens the selected project. – You can also just double-click on the project name from the project list. 10/23/2021 2006 HYPACK® Training Seminar 13
Working with Projects New Project: – Creates a new survey project. – Copies the geodesy, hardware and HYPACK® settings from your default settings. – Use when you are surveying an area for the first time. 10/23/2021 2006 HYPACK® Training Seminar 14
Creating a New Project Geodesy Planned Line Files (from current project) Raw Data (empty folder) (none) Boat Hardware (from current project) Background Files Edited Data (empty folder) (none) HYPACK® Display Settings Other Project Files (from default project) (none) Sorted Data (empty folder) Copied from current project Not copied from current project 10/23/2021 2006 HYPACK® Training Seminar 15
Working with Projects Copy Project: – Creates a copy of an existing survey project. – Copies: Geodesy Boat Hardware All Project Files – Does not copy: Data files from existing project. – Use when you are resurveying an area that you have already surveyed in HYPACK®. 10/23/2021 2006 HYPACK® Training Seminar 16
Copy Project Geodesy Planned Line Files (from current project) Raw Data (empty folder) (from current project) Boat Hardware (from current project) Background Files Edited Data (empty folder) (from current project) HYPACK® Display Settings Other Project Files (from default project) (from current project) Sorted Data (empty folder) Copied from current project Not copied from current project 10/23/2021 2006 HYPACK® Training Seminar 17
Project “Explorer Don’ts” Please…. Action Why? A Better Way Don’t copy a project from one directory to another in Explorer. It won’t find all of the necessary files, especially if you go from D: / to C: /. Use the ‘Make Local Copy’ or ‘Make Network Copy’ options. Don’t rename the RAW, EDIT or SORT directories. Some programs may crash if they can’t locate them. You can do it, as long as you make a new RAW, EDIT or SORT folder to replace the original. Don’t rename a project in Explorer. HYPACK won’t find it unless you also rename the Project’s *. INI file. I don’t know a good way to do this. 10/23/2021 2006 HYPACK® Training Seminar 18
Compressing a Project Creates a *. ZIP or *. EXE of your HYPACK® data. It’s now easier to make a copy of the project across the network, using the Project Manager window. 10/23/2021 AVI 2006 HYPACK® Training Seminar 19
SCHEMEBUILDER Controlling the Colors of Items in HYPACK® SCHEMEBUILDER has been updated in Version 6. 2. It now applies to: – SURVEY – HYPACK® Shell Schemes included upon installation: – – – Default Bright Day Dark Day Bright Night Dark Night Change the Scheme on the fly in SURVEY. 10/23/2021 2006 HYPACK® Training Seminar AVI 20
