Human Anatomy and Physiology General Histology Slide Set
- Slides: 43
Human Anatomy and Physiology General Histology Slide Set 1 Bio 348 Lapsansky - 2007
(1) Squamous cells (buccal smear) Nuclei of squamous cells Bio 348 Lapsansky - 2007 Nuclei of WBCs
(2) Simple squamous ( lining Bowman’s capsule) Glomerular capillaries Bio 348 Lapsansky - 2007
(3) Simple squamous (mesothelium) Cell margins nuclei Bio 348 Lapsansky - 2007
(4) Simple squamous (endothelium) Smooth muscle lumen Connective tissue Bio 348 Lapsansky - 2007
(6) Stratified squamous--lower strata (skin) Nuclei Basement membrane Epidermis Bio 348 Lapsansky - 2007 Dermis
(7) Simple cuboidal epithelium (kidney tubule, l. s. , arrow points to a nucleus) lumen Bio 348 Lapsansky - 2007
(8) Simple cuboidal (kidney tubule, x. s. ) nuclei lumen Bio 348 Lapsansky - 2007
(9) Simple columnar epithelium (salivary gland duct) lumen adipocyte Acinar cells (filled with enzymes) Bio 348 Lapsansky - 2007
Baement mem Goblet cell microvilli lumen (10) Simple columnar epithelium Bio 348 Lapsansky - 2007 (small intestine, w/microvilli and goblet cells)
(11) Microvilli (TEM--transmission electron micrograph) Name the type of intercellular junction lumen mitochondria Bio 348 Lapsansky - 2007
(12) Pseudostratified ciliated columnar epithelium (trachea) cilia goblet cell Connective tissue nuclei Bio 348 Lapsansky - 2007
(13) Transitional epithelium (urinary bladder) Dome-shaped cells Basement membrane Connective tissue Bio 348 Lapsansky - 2007
lumen epithelium (14) Hyaline cartilage (trachea, low magnification) Bio 348 Lapsansky - 2007
(14) Hyaline cartilage (trachea, high magnification) chondrocytes matrix Bio 348 Lapsansky - 2007
(15) Elastic cartilage (stained to demonstrate fibers in matrix) Bio 348 Lapsansky - 2007
(16) White fibrous connective tissue (tendon, low power) nuclei collagen fiber Bio 348 Lapsansky - 2007
(16) Tendon--Dense regular connective tissue (white fibrous connective tissue) Bio 348 Lapsansky - 2007
(17) Adipose tissue (arrow points to a peripherally located nucleus) Bio 348 Lapsansky - 2007
(18) Areolar connective tissue (hypodermis) collagen fiber nuclei elastic fiber Bio 348 Lapsansky - 2007
(19) Ground compact bone osteon central canal osteocytes Bio 348 Lapsansky - 2007
(20) Human blood smear platelets eosinophil lymphocyte neutrophil Bio 348 Lapsansky - 2007 RBCs
Human blood smear platelets lymphocyte neutrophil RBCs Bio 348 Lapsansky - 2007
(21) Skeletal muscle (l. s. ) striations Muscle cell nuclei Bio 348 Lapsansky - 2007
Skeletal muscle shown in longitudinal section Bio 348 Lapsansky - 2007
Skeletal muscle shown in cross section (x. s. ) endomysium nuclei muscle cell Bio 348 Lapsansky - 2007
lumen Outer longitudinal layer inner circular layer (22) Smooth muscle (intestine, x. s. ) Bio 348 Lapsansky - 2007
Smooth muscle (l. s. ) Bio 348 Lapsansky - 2007
(23) Smooth muscle (teased apart to demonstrate spindle shape) nuclei Bio 348 Lapsansky - 2007
(24) Cardiac muscle (arrow showing intercalated disk) Bio 348 Lapsansky - 2007
(25) Multipolar neuron (spinal cord smear) low power, with several scatttered neuroglia neurons Bio 348 Lapsansky - 2007
(26) Multipolar neuron (high power) neuroglia nucleus nucleolus Bio 348 Lapsansky - 2007
adipose tissue epineurium perineurium fascicle Where is the endoneurium? (27) Nerve (x. s. , in neurovascular bundle) Bio 348 Lapsansky - 2007
Nerve in cross section Bio 348 Lapsansky - 2007
epidermis melanin (gold pigment) dermis (28) Cutaneous membrane Bio 348 Lapsansky - 2007
stratum basale stratum spinosum stratum granulosum stratum lucidum stratum corneum (29) Thick skin Bio 348 Lapsansky - 2007
epidermis sebaceous gland (30) Epidermis with hair shaft (arrow) in hair follicle Bio 348 Lapsansky - 2007
(31) Integument (melanocytes, at arrow) Bio 348 Lapsansky - 2007
(32) Pacinian corpuscle (l. s. ) Bio 348 Lapsansky - 2007
Pacinian corpuscle (x. s. ) Bio 348 Lapsansky - 2007
(33) Artery and vein (x. s. ) artery (lumen) vein (lumen) Bio 348 Lapsansky - 2007
synaptic terminals (34) Neuromuscular junction axon collaterals Bio 348 Lapsansky - 2007
Neuromuscular junction (motor end plate) Bio 348 Lapsansky - 2007
