Huawei Switch & WLAN Interoperation Success Stories EN

Huawei Device Interoperate Successfully with ISE for Terminal Access in Spain's Santander Bank Background & Requirements: Ø Santander serves more than 100 million customers across Europe, Latin America, North America, and Asia. Ø This bank has more than 9, 800 employees in 650 branches. Ø Existing devices were end of support and the network needed to be upgraded and reconstructed. Solution: ISE Device Model: S 5720 LI, S 5700 LI, S 2700 EI Ø Provide Po. E and 802. 1 x authentication: meets requirements of Financial Supervision Authority Aggregation Switch Ø Power saving: uses EEE to effectively reduce TCO Ø Interoperation with ISE: supports the same services provided by the Cisco switch, including client provisioning, posture subscription, policy deployment, posture assessment and remediation, and dynamic authorization policy 2 Access Switch S 5720 LI Access Switch S 5700 LI Access Switch S 2700 EI

Huawei Switches Interoperate Successfully with Cisco ISE, Enabling Smooth Network Upgrade for Sberbank of Russia Background & Requirements: Ø Serbank is ranked in the world’s Top 100 largest banks, with more than 10, 000 branches. Ø Cisco devices and controllers were old and had insufficient network capacity and no support for new business architectures. Huawei Solution: Huawei switches interoperate successfully with the Cisco ISE authentication server through 802. 1 x authentication features to provide the DACL function. Customer Benefits: Retain the controller on the legacy network, ensuring smooth network upgrade while protecting customer investment. Device Model: Huawei: S 12700, S 7700, S 5720 EI, S 5720 SI Cisco: ISE 3 ISP 1 Internet ISP 2 Internet Private network Campus core: S 12700 cluster Cisco ISE Main campus Branch campus S 7700 S 5720 S 5700 S 5720

Huawei Switches Interoperate Successfully with Cisco ISE, Enabling Smooth Network Upgrade for STC in ME Background & Requirements: Ø STC is the largest mobile operator in the Middle East, serving more than 12 million mobile users and 4. 5 million fixed subscribers. Ø Huawei S 5720 SI replaces Cisco C 3750 as an egress gateway to provide 802. 1 x and MAC address authentication for fixed terminal users. Solution: Internet ISE 1. 2 Device Model: S 5720 SI Ø Terminal authentication: supports the standard RADIUS protocol, meeting the requirement of terminal authentication and Cisco IP phone connection Ø Protocol interoperation: uses the standard protocol OSPF to implement seamless interoperation 4 Log server NMS firewall switch

Huawei Switch and WLAN Devices Interoperate Successfully with Cisco ISE, Enabling Smooth Network Upgrade for University of Dammam Background & Requirements: Ø University of Dammam is one of the oldest universities in Saudi Arabia and one of the leading universities in the medical field. It aspires to become one of the best universities in the world. Ø Existing devices were end of service and needed to be replaced. Extranet security management & control Solution: Device Model: S 5720 SI, AP 5030 DN ISE authentication Extranet server Intranet Internet Agile firewall Ø Wireless user authentication: The ISE authentication server implements MAC-address-prioritized Portal authentication on User security management & control terminals through a Huawei device. Ø Policy delivery: The ISE authentication server delivers access policies through Huawei devices. AC switch AP Air interface security protection 5
