Huawei Big Data Storage N 9000 Jan Stibor

Huawei Big Data Storage N 9000 Jan Stibor Storage & Server Product Manager

1 Definition of Big Data 2 HUAWEI Big Data Storage Solution 3 Application Scenarios of HUAWEI Solution 2

Era of Big Data Is Coming 2. 9 million emails per second globally 250 million pictures per day Videos of 28, 800 hours per day 24 PB data processed per day 200 PB per safe city 6. 3 million orders per day 50 million messages per day More than 1 PB per 3 D movie By 2015, data amount will reach 8 ZB with the valued of $16. 9 billion. Page 3

What Is Big Data? Mass data Velocity Volume Exponential growth of unstructured data Quick data flow and dynamic data system Real-time analysis, not post analysis Various data types Veracity Variety Unstructured data such as files, emails, and videos accounting for 90% of the data amount generated in the next 10 years Veracity of Great data Prediction and analysis of the future and the behavior mode IDC: four characteristics of big data Page 4

Driving Force of Big Data 1 Collection • Storage — open architecture, gradual scale out, and integration of near-line systems and offline systems 2 • Storage Big Data Analysis — compound data, unified storage of multiple data sources, unified query, and sharing of storage resources 3 • Management Archiving — lifecycle management of mass data at a low cost and high energy efficiency 4 Analysis • Maintenance — easy to use Page 5

Contents 1 Definition of Big Data 2 HUAWEI Big Data Storage Solution 3 Application Scenarios of HUAWEI Solution 6

CSS/CSE HUAWEI Big Data Storage Solution High-performance solution Analysis Large-capacity solution Big Data Storage Archiving Mass data query and analysis solution Page 7

HUAWEI Ocean. Stor N 9000—X in 1 • Quick data import • Support for JDBC and ODBC • SQL 92/2003 • Data compression Scale-out NAS • Linear expansion from 3 to 288 nodes • More than 3, 000 OPS • Capacity up to 100 PB • NFS/CIFS interfaces • HDFS interface Scale-out DB Scale-out Backup Page 8 • Global online deduplication • Support for LTFS Page 8

HUAWEI Ocean. Stor N 9000 Architecture Application layer Media asset Internet HPC … Behavior prediction, real-time analysis, … Apple …… Unstructured data, object data, structured data NAS interface Object interface Big data sharing Archiving interface BI Database interface Big data analysis Map-reduce HDFS Unified management and namespace Lifecycle policy Index of quick file search Remote replication and Global deduplication snapshot Storage Analysis Storage Archiving 10 GE/Infiniband layer Node Page 9 Periodic data inspection Node Page 9

N 9000 Hardware Front view Rear view High-performance node： The scene of frequent read and write small files High-bandwidth node： The scene of large file sequential read and write Large-capacity node： Near-line storage Acceleration node Page 10 2 U high 25 disk slots 2 -channel hexa-core CPU 48 GB memory at least SSDs for storing metadata 4 U high 36 disk slots 2 -channel hexa-core CPU 48 GB memory at least 4 U high 36 disk slots 2 -channel quad-core CPU 16 GB memory at least 1 U high Page 10

N 9000 Software — Wise Series 1 Wushan. FS § § § Self-developed distributed file system Mandatory, one-off purchase Wise Data Protection (Wise. DP) 2 Wise. Link § § § Cluster load balancing software Support for multiple load balancing policies Optional, allowing for separate purchase 3 Wise. Quota § § Quota management software that sets space usage limits on directories or users. Optional, allowing for separate purchase § § § DST software Support for policy-based automatic migration Optional, allowing for separate purchase Wushan. FS: Wushan File System 4 Wise. Tier Page 11

Extensive Flexibility: Wise. DP +1 Number ODC RDC of Nodes 3 4 4 6 5 8 6 4 8 6 10 8 14 12 14 10 20 12 +2 ECC Switch +3 +4 ECC RDN 2 2 2 2 4 4 Max. No. of Utilization Allowed Faulty Disks Nodes 1 2 1 67% 1 2 1 75% 1 2 1 80% 2 2 2 67% 2 2 2 75% 2 2 2 80% 2 2 2 86% 4 4 4 71% 4 4 4 75% Original data counts (ODC) Redundant data counts (RDC) Redundant data nodes (RDN) N+1 to N+4 data protection File-level data protection 1 hr/TB data recovery Page 12

Outstanding Performance: Wise. Link . . . Automatic load balancing among existent and newly added nodes Single node expansion within 60 s Without human intervention and manual modifications Page 13

Outstanding Performance: Wise. Tier • Enables DST to work among diverse types of nodes. • Adopts tiering policies based on I/O access popularity. High-OPS nodes • Adopts hotspot anti-shake policy to prevent unnecessary data migration. • Seamlessly adapts to service changes without interrupting ongoing applications. Large-capacity nodes Hot data Cold data • Consolidates multiple storage systems into a single storage system, eliminating the possibilities of frequent data migration and simplifying management. Page 14

Simplified Management: Refined Space Management Wise. Quota: sets quotas for subdirectories to facilitate space management. 100 TB Fast automatic deployment Comprehensive performance monitoring Unified topology display 10 TB 20 TB User 30 TB User group 20 TB 10 TB User Centralized management of a single file system of 100 PB Page 15 40 TB Page 15

HUAWEI 9000 — Adapting to Changes and Converging for Easy Management Extensive Flexibility § Scaling from 3 to 288 nodes § Support up to 100 PB of capacity § Linear scaling of performance and capacity Outstanding Performance § World's leading file system access performance of more than 3 million OPS Optimal Integration Streamlined Management § Distributed scale -out architecture § Unified management of all nodes on a single interface § Integration of scale-out NAS, scale-out DB, and scale-out backup Page 16 § LCM Page 16

Contents 1 Definition of Big Data 2 HUAWEI Big Data Storage Solution 3 Application Scenarios of HUAWEI Solution 17

HUAWEI Ocean. Stor N 9000 Scenario— Media Asset Management Animation rendering Non-linear editing system … … … HD editing SD editing . . . Cataloging • Stable bit steams and low single-stream bandwidth, with a strong need for data sharing Animation rendering solution VOD system LAN VOD server cluster PC TV station non-linear editing system solution HPC N 9000 highperformance nodes TV set + set-top box Focusing on five aspects N 9000 highbandwidth nodes and large-capacity nodes • Frame image file storage, with a strong need for high performance in sequential read of small-sized I/Os VOD solution • Concurrent reads by multiple users, with a strong need for high bandwidth PC Smart phone Media asset management solution Post-production system Audio Editing Effect Media asset management system Query/Cataloging • Large capacity, high bandwidth, and data sharing Movie post-production solution … • Stable bid streams and high-bandwidth throughput, providing data sharing Page 18
