How Ecosystems Work Energy Flow in Ecosystems Ecological

How Ecosystems Work Energy Flow in Ecosystems

Ecological Pyramids

Ecological Pyramids Show relative amounts of energy or matter within trophic levels of food chains and food webs

Energy Pyramids • shows amount of available energy at each level • most energy is consumed at each level for biological processes or lost as heat • only about 10% of energy is transferred to next level 0. 01% 0. 1% 1% 100%

• Each time energy is transferred, some of the energy is lost as heat • Therefore, less energy is available to organisms at higher trophic levels. • One way to visualize this is with an energy pyramid Trophic Levels

0. 01% 0. 1% 1% 100%

Heat Autotrophs 100% Heat Consumed Herbivores Consumed 10% Carnivores 1% Consumed

Biomass Pyramid • represents available food (organic matter)

Pyramids of Numbers • represents the number of individuals at each trophic level

Energy Loss Affects Ecosystems • Decreasing amounts of energy at each trophic level affects the organization of an ecosystem. • Energy loss affects the number of organisms at each level. • Energy loss limits the number of trophic levels in an ecosystem.

1. 2. 3. 4. 5. 6. 7. 8. 9. How does energy flow through an ecosystem? Draw a food chain with at least 3 consumers. What do the arrows indicate? To show all of the feeding relationships in an ecosystems, biologist use a/(an) __ __. How much energy is transferred from one organism to the other? What happens to the energy that is not transferred? Review What is biomass? What information is found in a biomass pyramid? What is represented by a pyramid of numbers?

The End
