Home Automation Network Solution Home Automation Structure Application

Home Automation Network Solution

Home Automation Structure Application Cloud i. Home i. Power & Energy i. Building i. Environment 3 rd Party Software HTTP / CGI interface API e-Home Control Gateway e-Home Devices & Sensors Control Gateway Locks Sensors Control Pad Security & Alarm Door Phone Lighting Video Phone Smart meters Window control Platform 2

PLANET’s Home Automation Solution ü Home Security ü Energy Savings e-Home Control Gateway e-Home Control Pad Wall-mounted Po. E+ Switch HAC-1000 HTS-1000 P WGS-804 HPT IP Door Phone HDP-1100 PT HDP-5260 PT HDP-5240 PT Android Multimedia IP Phone Wi-Fi IP Camera ICF-1800 ICA-W 7100 3

PLANET’s Home Automation Solution ü Home Security PIR Sensor HZS-100 series ü Energy Savings Smoke Detector HZS-200 series Z-Wave Smart Energy Meter (ETSI-868. 42 MHz) - Germany plug HZS-532 E-DE 4 -in-1 Multi Sensor HZS-300 series Z-Wave Smart Energy Meter (FCC-908. 42 MHz) - US plug HZS-531 A-US 4

Home Automation Application 5

Features Control Gateway Z-Wave Home Automation Control Gateway u Home control and powerful Z-Wave in wall-mounted box u See and control your Home Automation from any smartphone or tablet from anywhere in the world u Controls over 900 smart Z-Wave products of all kinds u App and Control pad alerts for any situation u Hands-free voice control over your devices via Amazon Alexa u Extended range indoors and outdoors HAC-1000 6

Features Control Pad 10 -inch Touch Screen Home Automation Controller u SIP 2. 0 (RFC 3261) compliant u Android 10” touch panel control of your entire system u View all your cameras and control all your devices from Home Automation Control Gateway u IEEE 802. 3 af Po. E / 802. 11 n Wireless communications makes installation a breeze in any home u Easy, intuitive setup with wall-mounted u Adding devices later is easy too with preconfigured settings for most device HTS-1000 P 7

Features IP Intercoms SIP Single-unit Apartment Door Phone with Po. E u SIP 2. 0 (RFC 3261) compliant u HD camera with 112 degrees Wide Range Video View angle u H. 264 / MJPEG Video codec and SIP / RTSP protocol u IEEE 802. 3 af Po. E compliant HDP-1100 PT u Built-in one Call Button & Hardware Acoustic Echo Cancellation u Built-in One Relay output for door lock or lighting control u Built-in One DI port for Door sensor, PIR, Emergency button 8

Features IP Intercoms SIP Multi-unit Video Door Phone with Po. E u SIP 2. 0 (RFC 3261) compliant u HD camera with infrared light and night vision u HD voice using wideband G. 722 coding produces clearer sound u IP 65 classification with vandal and weather proof u Access Management via RF card and DTMF code and Password u Compliant with IEEE 802. 3 af Po. E, Acoustic Echo Cancellation u -20 to 60 degrees C operating temperature HDP-5240 PT 9

Features IP Intercoms SIP Multi-unit Apartment Door Phone with Po. E u SIP 2. 0 (RFC 3261) compliant u HD camera with infrared light and night vision u HD voice using wideband G. 722 coding produces clearer sound u Tamperproof protection for unauthorized changes u Access Management via RF card and DTMF code and Password u Compliant with IEEE 802. 3 af Po. E, Acoustic Echo Cancellation HDP-5260 PT 10

Features Multimedia Conference IP Phone HD Touch Screen Android Multimedia Conference IP Phone u 7” TFT 800 x 480 Capacitive Multi Touch Screen u Built-in Tiltable 2 Mega pixel CMOS camera u Built-in Android 4. 2 OS & SIP 2. 0 (RFC 3261) compliant u Supports 6 SIP servers and Backup SIP proxy servers u HD voice codec G. 722 for perfect voice quality u Capable of 10 -way conversation u IEEE 802. 3 af Power over Ethernet compliance u Built-in Dual Ethernet / HDMI / USB / micro SD slot u Supports third party communication APP ICF-1800 11

Features Wireless IR PT IP Camera u HD Real-time 720 P@30 fps u PAN (0~ 355 degrees), Tilt (0 ~ 190 degrees) u Built-in 11 IR illuminators, effective up to 10 meters u IEEE 802. 11 n wireless LAN capability u WEP / WPA 2 -PSK wireless security u ONVIF compliant for interoperability changes u Micro SD card local video recording supported u H. 264, and M-JPEG video compression simultaneously u Real-time image monitoring of Home Automation cameras ICA-W 7100 12

Wall-mounted Managed Gigabit Po. E+ Switch u Designed for Home / Building automation u Wall-mount, Magnetic wall-mount, DIN-rail type u 802. 3 af/at Po. E injector, 120 -watt Po. E budget u LED indicators for per port Po. E In-Use and Po. E Power Usage u Dual redundant power input: terminal block and DC jack u IP 30 Slime Case, -40 ~ 75 degrees C operating temperature u IPv 6/IPv 4 Web / Telnet / SNMP v 1, v 2 c / SSH / SSL Management u Po. E Schedule / Schedule Power Recycle / PD Alive Check WGS-804 HPT 13

Wall-mounted Po. E+ Switch Application 14

u View PLANET Home Automation solution online 15
