Hoisting AIMS Consolidate and update knowledge base on
Hoisting
AIMS Consolidate and update knowledge base on: Legislation relating to hoisting Hoists and slings available How to measure for a sling Issues to consider relating to hoisting PRACTICAL KNOWLEDGE: • Practice using selection of hoist related equipment available through DCC. • Share and improve practical knowledge and skills. • Develop confidence in techniques • Consider potential solutions / problem solving.
MOV 0909 Small 87 – 107 cm MOV 0680 Medium 97 – 117 cm MOV 0678 Large 112 – 132 cm
Oxford Advanced Liko 102 Invacare birdie Liko Sabina Oxford Midi
Glove Tux Deluxe • Safe Working Load – 200 kg • Measurements of person • Size 6: Height 145 – 170 cm Girth – 75 – 90 cm • Size 7: Height 155 – 180 cm Girth – 85 – 100 cm • Size 8: Height 160 – 190 cm Girth – 95 – 115 cm • Size 9: Height 160 – 190 cm Girth 105 – 130 cm Girth Measurements: For Women – measure around hips For Men – measure around chest, under arms For Children, measure around chest, under arms.
Silverlea Continental Low Convenience Sling Safe Working Load – 220 kg Measurements of person: Small: Height 133 – 146 cm Chest – 76 – 87 cm Medium: Height 146 – 160 cm Chest – 87 – 97 cm Large: Height 160 – 170 cm Chest – 97 – 112 cm
In-situ slings • Prism Comfort Recline Sling • Safe Working Load – 200 kg • Sling Sizing: • Small: 6 -10 stone, 38 – 64 kg Medium: 8 – 17 stone, 51 – 108 kg Large: 17 – 25 stone, 108 – 159 kg
Free Standing dimensions. Maximum height of frame (floor to top of the frame) 240 cm Maximum width of frame (inside of the frame) 300 cm Base of posts- 108 cm long Robin motor Floor to ceiling posts dimensions. Maximum height of frame (floor to top of the frame) 270 cm Maximum width of frame (inside of the frame) 290 cm
Non standard alternatives
ISSUES • When would you move from a stand assist to full hoisting? • When would you use a: – Midi or equivalent – Freestanding track – Track fixed to the ceiling – Robin motor • Managing change
Managing change What are the elements of change when moving to hoisting? How would you facilitate change? and who with? What legislation is relevant in this scenario? What are the areas of risk? Are there other factors to consider?
Elaboration Likelihood model. Explain pros and cons and how they may impact on client/carer. Use personally involving messages, which are immediate and direct. Be honest about benefits and consequences. Get their perspective. Determine their fears, and assumptions. Counter their concerns, allow them to feel part of the conversation. Validate and acknowledge their view point.
Nothing is impossible if you have the right equipment!!
