Grid Communication Simulator Boro Jakimovski Marjan Gusev Institute of Informatics Faculty of Natural Sciences and Mathematics University of Sts. Cyril and Metodius Skopje, Macedonia

What is Grid? • Flexible, secure, coordinated resource sharing among dynamic collections of individuals, institutions, and resource From “The Anatomy of the Grid: Enabling Scalable Virtual Organizations” • Enable communities (“virtual organizations”) to share geographically distributed resources as they pursue common goals -- assuming the absence of… • • central location, central control, omniscience, existing trust relationships.

Performance Issues • Usage of TCP/IP as main transport protocol introduces lower performance • Wide Area Network performance compared to specialized Cluster Network performance • hence • The need for better performance

Collective Communications • MPICH-G 2 over vendor MPI • The advantage of Collective Communication – Topology aware collective communications • • • Broadcast Gather/Scatter Barrier Reduce …

Example 0 1 2 3 4 5 6 7

Example 0 1 4 7 2 5 6 3

Grid Communication Simulator • Implemented using Java 1. 4 • Purpose – Visual representation of communication patterns – Has implemented collective communications – In development

Grid Communication Simulator • The programs executed on the virtual processors are Java programs – Example: import java. util. *; import edu. ii. grid. simulator. *; public class Flat. Tree. Broadcast extends edu. ii. grid. simulator. Program { public void run(){ if (processor. get. ID() == 0){ for (int i = 1; i < Processor. get. Count(); i++){ Integer[] data = {new Integer(1)}; processor. send( new Packet( data, new GRIDAddress(i) ) ); } } else { Packet p = null; p = processor. recieve(); } } }

Grid Communication Simulator • Grid simulator main window

Grid Communication Simulator • Grid simulator usage

Grid Communication Simulator

Grid Communication Simulator for (int i = 0; i < matrice. A. length; i++) for (int j = 0; j < matrice. A[i]. length; j++) matrice. A[i][j] = new Integer((int)(Math. random()*100)); row = Collective. Communication. flat. Tree. Scatter(processor, matrice. A);

Grid Communication Simulator
