Graduate Program in Business Information Systems Decision Analysis Part 1 Aslı Sencer

Analytical Decision Making o Can Help Managers to: n Gain deeper insight into the nature of business relationships n Find better ways to assess values in such relationships; and n See a way of reducing, or at least understanding, uncertainty that surrounds business plans and actions 2

Steps to Analytical DM o o o o Define problem and influencing factors Establish decision criteria Select decision-making tool (model) Identify and evaluate alternatives using decision-making tool (model) Select best alternative Implement decision Evaluate the outcome 3

Models o Are less expensive and disruptive than experimenting with the real world system o Allow operations managers to ask “What if” types of questions o Are built for management problems and encourage management input o Force a consistent and systematic approach to the analysis of problems o Require managers to be specific about constraints and goals relating to a problem o Help reduce the time needed in decision making 4

Limitations of the Models o They may be expensive and timeconsuming to develop and test o Often misused and misunderstood (and feared) because of their mathematical and logical complexity o Tend to downplay the role and value of nonquantifiable information o Often have assumptions that oversimplify the variables of the real world 5

The Decision-Making Process Quantitative Analysis Problem Logic Historical Data Marketing Research Scientific Analysis Modeling Decision Qualitative Analysis Emotions Intuition Personal Experience and Motivation Rumors 6

Displaying a Decision Problem o Decision trees o Decision tables Outcomes States of Nature Alternatives Decision Problem 7

Types of Decision Models o Decision making under uncertainty o Decision making under risk o Decision making under certainty 8

Fundamentals of Decision Theory Terms: o Alternative: course of action or choice o State of nature: an occurrence over which the decision maker has no control Symbols used in a decision tree: o A decision node from which one of several alternatives may be selected o A state of nature node out of which one state of nature will occur 9

Decision Table States of Nature Alternatives State 1 State 2 Alternative 1 Outcome 2 Alternative 2 Outcome 3 Outcome 4 10

Getz Products Decision Tree A state of nature node A decision node 1 c u r st n Co arge t l ant Construct pl 2 small Do plant no th ing Favorable market Unfavorable market 11

Decision Making under Uncertainty o Maximax - Choose the alternative that maximizes the maximum outcome for every alternative (Optimistic criterion) o Maximin - Choose the alternative that maximizes the minimum outcome for every alternative (Pessimistic criterion) o Equally likely - chose the alternative with the highest average outcome. 12

Example: States of Nature Alternatives. Favorable. Unfavorable. Maximum Minimum Row Market in Row Average $200, 000 -$180, 000$200, 000 -$180, 000 $10, 000 Construct large plant Construct $100, 000 small plant Do nothing $0 -$20, 000 $100, 000 -$20, 000 $40, 000 $0 Maxima x $0 Maximin $0 $0 Equally likely 13

Decision criteria o The maximax choice is to construct a large plant. This is the maximum of the maximum number within each row or alternative. o The maximin choice is to do nothing. This is the maximum of the minimum number within each row or alternative. o The equally likely choice is to construct a small plant. This is the maximum of the average outcomes of each alternative. This approach assumes that all outcomes for any alternative are equally likely. 14

Decision Making under Risk o Probabilistic decision situation o States of nature have probabilities of occurrence o Maximum Likelihood Criterion o Maximize Expected Monitary Value (Bayes Decision Rule) 15

Maximum Likelihood Criteria § Maximum Likelihood: Identify most likely event, ignore others, and pick act with greatest payoff. § Personal decisions are often made that way. § § Collectively, other events may be more likely. Ignores lots of information. 16

Bayes Decision Rule § It is not a perfect criterion because it can lead to the less preferred choice. § Consider the Far-Fetched Lottery decision: EVENTS Head Tail Probability . 5. 5 ACTS Gamble Don’t Gamble +$10, 000 -5, 000 $0 0 Would you gamble? 17

The Far-Fetched Lottery Decision ACTS Gamble Don’t Gamble EVENTS Probability Payoff × Prob Head . 5 +$5, 000 $0 Tail . 5 -2, 500 0 $2, 500 $0 Expected Payoff: Most people prefer not to gamble! § § That violates the Bayes decision rule. But the rule often indicates preferred choices even though it is not perfect. 18

Expected Monetary Value N: Number of states of nature k: Number of alternative decisions Xij: Value of Payoff for alternative i in state of nature j, i=1, 2, . . . , k and j=1, 2, . . . , N. Pj: Probability of state of nature j 19

Example: States of Nature Alternatives Favorable Unfavorable Expected Construct large plant Construct small plant Do nothing Market P(0. 5) value P(0. 5) $200, 000 -$180, 000 $100, 000 $0 -$20, 000 $0 $40, 000 Best $0 choice 20

Decision Making under Certainty o What if Getz knows the state of the nature with certainty? o Then there is no risk for the state of the nature! o A marketing research company requests $65000 for this information 21

Questions: o Should Getz hire the firm to make this study? o How much does this information worth? o What is the value of perfect information? 22

Expected Value With Perfect Information (EVPI ) ( EVPI = Expected Payoff - Maximum expected payoff under Certainty with no information Let N: Number of states of nature and k: Number of actions, Expected Payoff under Ceratinty= Maximum expected payoff with no information=Max {EMVi; i=1, . . , k} u. EVPI places an upper bound on what one would pay for additional information 23

Example: Expected Value of Perfect Information Favorable Unfavorabl Market ($)e Market ($) Construct a large plant Construct a small plant Do nothing EMV -$180, 000 $100, 0 00 $0 $20, 00 0 $0 $40, 000 0. 50 200, 000 $0 24

Expected Value of Perfect Information Expected Value Under Certainty =($200, 000*0. 50 + 0*0. 50)= $100, 000 Max(EMV)= Max{10, 000, 40, 000, 0}=$40, 000 EVPI = Expected Value Under Certainty - Max(EMV) = $100, 000 - $40, 000 = $60, 000 So Getz should not be willing to pay more than $60, 000 25

Ex: Toy Manufacturer o How to choose among 4 types of tippi -toes? o Demand for tippi-toes is uncertain: Light demand: 25, 000 units (10%) Moderate demand: 100, 000 units (70%) Heavy demand: 150, 000 units (20%) 26

Payoff Table ACT (choice) Event (State of nature) Gears and Spring Action Probability levers Weights and pulleys Light 0. 10 $25, 000 -$10, 000 -$125, 000 Moderate 0. 70 400, 000 440, 000 400, 000 Heavy 0. 20 650, 000 740, 000 750, 000 27

Maximum Expected Payoff Criteria ACT (choice) Gears and levers Expected Payoff Spring Action $412, 500 $455, 500 Weights and pulleys $417, 000 Maximum expected payoff occurs at Spring Action! 28

Decision Trees o Graphical display of decision process, i. e. , alternatives, states of nature, probabilities, payoffs. o Decision tables are convenient for problems with one set of alternatives and states of nature. o With several sets of alternatives and states of nature (sequential decisions), decision trees are used! o EMV criterion is the most commonly used criterion in decision tree analysis. 29

Softwares for Decision Tree Analysis o DPL o Tree Plan o Supertree Analysis with less effort. Full color presentations for managers 30

Steps of Decision Tree Analysis Define the problem Structure or draw the decision tree Assign probabilities to the states of nature Estimate payoffs for each possible combination of alternatives and states of nature o Solve the problem by computing expected monetary values for each state-of-nature node o o 31

Decision Tree State 1 1 e iv at rn e t Al Alt ern a tive Decision Node 2 1 State 2 State 1 2 State 2 Outcome 1 Outcome 2 Outcome 3 Outcome 4 State of Nature Node 32

Ex 1: Getz Products Decision Tree EMV for node 1 = $10, 000 1 Favorable market (0. 5) c Unfavorable market u r t s n e o (0. 5) C arg Favorable market l t t an (0. 5) Construct pl 2 small Unfavorable market Do plant no (0. 5)2 = $40, 000 EMV for node th ing Payoffs $200, 00 0 $180, 00 0 $100, 00 0 -20, 000 33

A More Complex Decision Tree Let’s say Getz Products has two sequential decisions to make: o Conduct a survey for $10000? o Build a large or small plant or not build? 34

Ex 1: Getz Products Decision Tree No su rve y $106, 40 0 2 e Larg $63, 600 t S plan mall plant 3 No pla nt $87, 400 $2, 400 y $49, 200 Surv e 1 r. Su s. Po 5) (. 4 Su Ne r. Re s g. (. 5. 5) $40, 000 $49, 200 s. e R $106, 400 2 nd decision point 1 st decision point 4 e Larg $2, 400 t plan. Small No plant 5 pla nt $10, 000 6 ge $40, 000 Lar t S m n all pla 7 No plant pla nt Fav. Mkt (0. 78) $190, 000 Unfav. Mkt (0. 22) $190, 000 Fav. Mkt (0. 78) Unfav. Mkt (0. 22) $90, 000 -$30, 000 Fav. Mkt (0. 27) Unfav. Mkt (0. 73) -$10, 000 $190, 000 $90, 000 -$30, 000 Fav. Mkt (0. 5) Unfav. Mkt (0. 5) -$10, 000 $200, 000 Fav. Mkt (0. 5) $180, 000 Unfav. Mkt (0. 5) $100, 000 -$20, 000 $0 35

Resulting Decision o EMV of conducting the survey=$49, 200 o EMV of not conducting the survey=$40, 000 So Getz should conduct the survey! If the survey results are favourable, build large plant. If the survey results are infavourable, build small plant. 36

Ex 2: Ponderosa Record Company o Decide whether or not to market the recordings of a rock group. o Alternative 1: test market 5000 units and if favorable, market 45000 units nationally o Alternative 2: Market 50000 units nationally o Outcome is a complete success (all are sold) or failure 37

Ex 2: Ponderosa-costs, prices o o Fixed payment to group: $5000 Production cost: $5000 and $0. 75/cd Handling, distribution: $0. 25/cd Price of a cd: $2/cd Cost of producing 5, 000 cd’s =5, 000+(0. 25+0. 75)5, 000=$15, 000 Cost of producing 45, 000 cd’s =0+5, 000+(0. 25+0. 75)45, 000=$50, 000 Cost of producing 50, 000 cd’s =5, 000+(0. 25+0. 75)50, 000=$60, 000 38

Ex 2: Ponderosa-Event Probabilities o Without testing P(success)=P(failure)=0. 5 o With testing P(success|test result is favorable)=0. 8 P(failure|test result is favorable)=0. 2 P(success|test result is unfavorable)=0. 2 P(failure|test result is unfavorable)=0. 8 39

Decision Tree for Ponderosa Record Company 40

Backward Approach 41

Optimal Decision Policy o Precision Tree provides excell add-ins. o Optimal decision is: Test market n If the market is favorable, market nationally n Else, abort o Risk Profile Possible outcomes for the opt. soln. $35, 000 with probability 0. 4 -$55, 000 with probability 0. 1 -$15, 000 with probability 0. 5 42

Risk Profile for Ponderosa Record Co. 43

Sensitivity Analysis The optimal solution depends on many factors. Is the optimal policy robust? Question: -How does $1000 payoff change with respect to a change in n success probability (0. 8 currently)? earnings of success ($90, 000 currently)? test marketing cost ($15, 000 currently)? 44

Application Areas of Decision Theory Investments in research and development plant and equipment new buildings and structures Production and Inventory control Aggregate Planning Maintenance Scheduling, etc. 45

References o Lapin L. L. , Whisler W. D. , Quantitative Decision Making, 7 e, 2002. o Heizer J. , Render, B. , Operations Management, 7 e, 2004. o Render, B. , Stair R. M. , Quantitative Analysis for Management, 8 e, 2003. o Anderson, D. R. , Sweeney D. J, Williams T. A. , Statistics for Business and Economics, 8 e, 2002. o Taha, H. , Operations Research, 1997. 46
