GONDOR The Poly Performance Adjuvant Cereal herbicides CEREAL

GONDOR The Poly Performance Adjuvant – Cereal herbicides

CEREAL HERBICIDES Main Markets • Cereal herbicides • Maize herbicides • Sugar beet herbicides • Glyphosate treatments

CEREAL HERBICIDES The global cereal production is estimated to be 2597 million tons in 2017. Source: http: //www. fao. org/worldfoodsitu ation/csdb/en ©Shutterstock for De Sangosse Herbicides are an essential tool to control weeds in cereals to protect yield and quality. Controlling weeds in winter cereals often requires a herbicide program with several treatments.

SPECIAL CHALLENGES OF CEREAL HERBICIDES *Most cereal herbicides require the addition of an adjuvant to improve retention and uptake. Weed control with herbicides in cereals *Poorly wettable weeds e. g. blackgrass drastically need a powerfull wetting agent to allow the droplet to stay on their leaves *Resistant weeds, e. g. common windgrass (Apera spica-venti) or blackgrass (Alopecurus myosuroides) are a growing problem in some regions.

IMPROVING THE EFFICACY OF HERBICIDES IN CEREALS A poly performance adjuvant which gives you a maximum of functionalities to increase the efficacy of your herbicides and/or PGRs Improves Ø PENETRATION and TRANSLOCATION Gives Ø DRIFT CONTROL Increases Ø SPREADING Improves Ø RETENTION Enhances Ø COMPATIBILITY

GONDOR: CHARACTERISTICS Composition 100 % concentrated product: MSO, non ionic wetter and lecithin Use rate 0. 2 to 0. 5 l/ha of the spray volume Formulation EC Formulation GONDOR should be added to the tank first. Product use

GONDOR: USE RECOMMENDATIONS Product type Recommended rate of GONDOR SU’s against broadleaf weeds metsulfuron, thifensulfuron, tribenuron 0. 25 l/ha SU’s against grass 0. 25 l/ha up to 150 l/ha iodosulfuron, mesosulfuron , pyroxsulam over 150 0. 4 l/ha Fops, Dims 0. 25 l/ha up to 150 l/ha over 150 0. 4 l/ha

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against ryegrass (Lolium multiflorum) in winter wheat (T+61) Efficacy [%] 100 90 80 70 56 60 47 50 40 30 30 20 Ref. A 300 g/ha + MSO 1 l/ha Ref. A: 5. 6 g/kg iodosulfuron + 29. 2 g/kg mesosulfuron Treatment: 24 March Water volume: 200 l/ha Assessment: 24 May 2012, 35 plants /m² Source: Champagne Céréales, La Chapelle Monthodon 02, France + GONDOR 0. 25 % 8. November 2012 8

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against ryegrass (Lolium multiflorum) in winter wheat (T+61) Efficacy [%] 100 90 80 70 70 63 60 60 50 40 30 20 Ref. D 3 l/ha Ref. D 2. 5 l/ha + GONDOR 0. 25 % Ref. D: 800 g/l prosulfocarbe + 10 g/l clodinafop + 2. 5 g/l cloquintocet-mexyl Treatment: 29 November Water volume: 150 l/ha Assessment: 31 May, 517 plants /m² 8. November 2012 Source: BIOTEK, Epieds 49260, France 8. November 2012 9

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against ryegrass (Lolium multiflorum) in winter wheat (T+119) Efficacy [%] 100 90 79 80 70 70 70 64 60 50 40 30 REF. D 3 l/ha REF. D 2. 5 l/ha + MSO 1 l/ha Ref. D: 800 g/l prosulfocarbe + 10 g/l clodinafop + 2. 5 g/l cloquintocet-mexyl Treatment: 10 February (BBCH 23) Water volume: 150 l/ha Assessment: 9 June (BBCH 71), 50 plants /m² 8. November 2012 Source: UCATA, Presly 18, France 8. November 2012 REF. D 2. 5 l/ha + GONDOR 0. 25 % 10

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against soft brome (Bromus hordeaceus) in wheat Efficacy [%] 100 90 80 75 70 65 60 50 40 40 30 REF. O 0. 250 kg/ha + MSO 1 l/ha + GONDOR 0. 25 % Ref. O: 68. 3 g/kg cloquintocet-mexyl + 22. 8 g/kg florasulam + 68. 3 g/kg pyroxsulam Treatment: 30 March Water volume: 100 l/ha Assessment: 25 May, 450 plants /m² 8. November 2012 Source: SC 2 , DOUSSAY 86, France 8. November 2012 11

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against field pansy (Viola arvensis) in winter wheat Efficacy [%] 99 100 94 95 90 85 99 87 82 81 80 75 70 65 60 100 g/ha Ref. C + GONDOR 60 g/ha Ref. P + GONDOR 40 g/ha Ref. G Ref. C: 38. 4 g/kg metsulfuron + 384. 5 g/kg thifensulfuron Ref. P: 482. 3 g/kg tribenuron Ref. G: 192. 65 g/kg metsulfuron Treatment: 27 March (BBCH 25) Water volume: 200 l/ha Assessment: 20 June (BBCH 75), Field pansy: 13 % coverage Source: Agrartest, Sommerschenburg, Germany (2012) + GONDOR

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against red poppy (Papaver rhoeas) in winter wheat Efficacy [%] 100 97 99 99 99 95 88 90 87 85 80 75 70 65 60 100 g/ha Concert SX + GONDOR 0, 25% 60 g/ha Pointer SX + GONDOR 0, 25% 40 g/ha Gropper SX Ref. C: 38. 4 g/kg metsulfuron + 384. 5 g/kg thifensulfuron Ref. P: 482. 3 g/kg tribenuron Ref. G: 192. 65 g/kg metsulfuron Treatment: 27 March (BBCH 25) Water volume: 200 l/ha Assessment: 20 June (BBCH 75), Poppy: 11% coverage Source: Agrartest, Sommerschenburg, Germany (2012) + GONDOR 0, 25%

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against different weeds in winter wheat (T+29) Efficacy [%] 100 90 Ref. P 0. 2 l/ha 91 83 88 + GONDOR (0. 25%) 96 98 93 94 91 94 84 80 70 60 50 42 40 33 25 27 30 20 Poppy Chickweed Fumitory Canola Forget-me-not Cleavers Field Pansy Ref. P: tribenuron 482. 3 g/kg Treatment: 25 March (Winter wheat BBCH 29) Water volume: 200 l/ha Assessment: 23 April; crop coverage [%]: Field Pansy (Viola arvensis): 13; Cleavers (Galium aparine): 15; Forget-me-not (Mysotis arvensis): 10; Canola (Brassica napus) 3; Fumitory (Fumaria officinalis ): 15; Chickweed (Stellaria media): 9; Poppy (Papaver rhoeas): 32 Source: Agrartest, Großholbach, Germany (2014)

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against different weeds in winter wheat (T+29) Efficacy [%] 100 90 90 Ref. C 100 g/ha 95 96 98 + GONDOR (0. 25%) 98 98 93 96 96 83 79 80 92 75 71 70 60 50 40 30 20 Poppy Chickweed Fumitory Canola Forget-me-not Cleavers Field Pansy Ref. C: 38 g/ha metsulfuron + 384 g/ha thifensulfuron Treatment: 25 March (Winter wheat BBCH 29) Water volume: 200 l/ha Assessment: 23 April; crop coverage [%]: Field Pansy (Viola arvensis): 13; Cleavers (Galium aparine): 15; Forget-me-not (Mysotis arvensis): 10; Canola (Brassica napus) 3; Fumitory (Fumaria officinalis ): 15; Chickweed (Stellaria media): 9; Poppy (Papaver rhoeas): 32 Source: Agrartest, Großholbach, Germany (2014)

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against different weeds in winter wheat (T+29) Efficacy [%] Ref. H 150 g/ha 100 60 95 91 82 80 80 70 90 87 90 + GONDOR (0. 25%) 87 92 72 60 50 40 40 30 23 22 27 20 Poppy Chickweed Fumitory Canola Forget-me-not Cleavers Field Pansy Ref. H: 125 g/kg amidosulfuron + 12. 5 g/kg iododosulfuron + 125 g/kg mefenpyr-diethyl Treatment: 25 March (Winter wheat BBCH 29) Water volume: 200 l/ha Assessment: 23 April; crop coverage [%]: Field Pansy (Viola arvensis): 15; Cleavers (Galium aparine): 17; Forget-me-not (Mysotis arvensis): 9; Canola (Brassica napus) 3; Fumitory (Fumaria officinalis ): 16; Chickweed (Stellaria media): 8; Poppy (Papaver rhoeas): 29 Source: Agrartest, Großholbach, Germany (2014)

150 g/ha Ref. H (125 g/kg amidosulfuron + 11. 6 g/kg iodosulfuron) Source: Agrartest, Großholbach, Germany

150 g/ha Ref. H (125 g/kg amidosulfuron + 11. 6 g/kg iodosulfuron) + GONDOR 0. 25 % Source: Agrartest, Großholbach, Germany

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against different weeds in winter wheat (T+29) Efficacy [%] 100 90 Ref. S 1 l/ha 92 92 + GONDOR (0. 25%) 95 97 95 85 90 94 94 97 80 70 60 50 40 30 23 32 28 37 20 Poppy Chickweed Fumitory Canola Forget-me-not Cleavers Field Pansy Ref. S: 100 g/l fluroxypyr, 2. 5 g/l florasulam Treatment: 25 March (Winter wheat BBCH 29) Water volume: 200 l/ha Assessment: 23 April; crop coverage [%]: Field Pansy (Viola arvensis): 15; Cleavers (Galium aparine): 17; Forget-me-not (Mysotis arvensis): 9; Canola (Brassica napus) 3; Fumitory (Fumaria officinalis ): 16; Chickweed (Stellaria media): 8; Poppy (Papaver rhoeas): 29 Source: Agrartest, Großholbach, Germany (2014)

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against different weeds in winter wheat Efficacy [%] 100 90 80 88 94 80 70 60 50 40 30 23 28 28 25 22 20 Blackgrass Ref. A 100 g/ha Forget-me-not + MSO 1 l/ha Field pansy + GONDOR (0. 25%) Ref. A: 700 g/kg propoxycarbazone Treatment: 20 March (Winter wheat BBCH 27) Water volume: 200 l/ha Assessment: 17 May (T+58; plants/m 2); blackgrass (Alopecurus myosuroides): 1072; Forget-me-not (Myosotis arvensis): 13; Field Pansy (Viola arvensis): 15 Source: Agrartest, Limbach, Germany (2014) 28

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against fumitory (Fumaria officinalis) Biomass Score (T+55) 9 8 7. 7 7 6 5 4 3 2 1 0 Ref. A 15 g/ha Ref. A: 60 % metsulfuron Treatment: 23 April Assessment: Fumaria officinalis in the control/m² : 40 Source: SACS + GONDOR

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against fumitory (Fumaria officinalis) and cleavers (Galium aparine) Biomass Score (T+55) 8 7 6 7. 0 6. 0 5 4 3 2. 0 2 1 0 Ref. Q 10 g/ha + GONDOR Cleavers Fumitory Ref. Q: 250 g/ha tribenuron + 250 g/ha thifensulfuron Treatment: 23 April Assessment: Fumaria officinalis in the control/m²: 40; Galium aparine in the control/m²: 12. 5 Source: SACS

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against cleavers (Galium aparine) Biomass Score (T+55) 7 6 6 6 5 4 3 2 2. 0 1 0 Ref. B 75 ml/ha + GONDOR T+15 T+62 Ref. B: 50 g/l florasulam Treatment: 15 April Assessment: Galium aparine in the control/m²: 12. 5 Source: SACS

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against cleavers (Galium aparine) Biomass Score (T+55) 7 6 6. 0 5 4 3 2 1 1. 0 0. 8 0 Ref. C 120 g/ha + GONDOR T+15 T+62 Ref. C: 12. 5 g/ha iodosulfuron + 125 g/ha amidosulfuron (+ mefenpyr safener) Treatment: 15 April Assessment: Galium aparine in the control/m²: 12. 5 8. November 2012 Source: SACS 24

TRIAL RESULTS: CEREAL HERBICIDES Efficacy against blackgrass and broadleaf weeds Efficacy [%] 100 86 90 83 80 65 70 60 45 50 40 30 20 Ref. A 250 g/ha Meziere + GONDOR Saint Germain Ref. S: 3 % mesosulfuron + 3 % iodosulfuron Treatment: 20 March (Meziere), 10 April (Saint Germain) Assessment: Blackgrass: 130 plants/m 2; Poppy (Papaver rhoeas): 125 plants/m 2; Ivyleaf speedwell (Veronica hederifolia): 37 plants/m 2 Source: Biotek, France

GONDOR: CONCLUSION ≡ Gondor significantly increases retention and penetration of most herbicide active ingredients ≡ Improved overall efficacy of the pesticide treatment ≡ Less drift – more droplets reach their intended target ≡ Reduced impact on the environment ≡ Higher efficiency of pesticides providing higher yield and profit ©Shutterstock for De Sangosse
