Fw. Caen and CAEN OPC Server UA Jonas Arroyo, BE-ICS-FD be-dep-ics. web. cern. ch JCOP Framework Working Group, 6 th February 2018
COMPATIBLE HW SY 1527 FAMILY SY 1527 SY 2527 SY 4527 LC SY 5527 LC EASY SYSTEM VME 8100 JCOP Framework Working Group, 6 th February 2018 SY 127 SY 403 SY 527 Jonas Arroyo
OPC UA VALIDATION • Reviewed namespace • Small lab setup with real hardware • Fw. Caen (definitions and models), needed help from LHC Experiments • Removed signals from OPC DA • Current issues reported about OPC UA • Data format: signed / unsigned, OPCCAEN-136 • Missing signals: OPCCAEN-142 • OPC items with spaces: OPCCAEN-140 • Engineering units: OPCCAEN-135 • Connection status: OPCCAEN-137 will be fixed on Fw. Caen component JCOP Framework Working Group, 6 th February 2018 Jonas Arroyo
MIGRATION PANEL JCOP Framework Working Group, 6 th February 2018 Jonas Arroyo
MIGRATION PANEL • • ASCII export (addressing) of selected devices Connection config Driver and simulator creation and internal DPs Addressing migration: • Remove not supported OPC items • crate. Communication. Conn. Status (string, old) crate. Communication. Connection. Status (bool, new) • Migrate address from DA -> UA • Create required subscriptions • ASCII export (addressing) of the selected devices • Log per migration: /data/Caen. Opc. Migration_[date_time] JCOP Framework Working Group, 6 th February 2018 Jonas Arroyo
COMPONENT MIGRATION • Review panels to include new DPE • Improve panels to configure CAEN OPC Server UA if runs on the same host • Migrate device definitions, device models • Documentation JCOP Framework Working Group, 6 th February 2018 Jonas Arroyo
Thank you for your time ! JCOP Framework Working Group, 6 th February 2018 Jonas Arroyo
