FM Transmitter FM Modulation using VCO fout 1
- Slides: 82
FM Transmitter
FM Modulation using VCO fout [1] Vin - Free Running Frequency of VCO Corresponding DC bias - Gain of VCO
Block Diagram Input DC Bias Vcc/2 VCO PA
Chipset • 4046 Phase-Locked Loop • LM 7171 Wide-Band Power Amplifier • 741 Op Amp
4046 PLL Only use the VCO
4046 VCO Characteristic C 1>=100 p. F
Schematic
PCB Layout Considerations • The signal traces should be short and wide to lower the impedance. • The width of the signal traces has to satisfy current driving capacity. • Any used board area should be shorted to ground to reduce AC noise. • Sockets and pads will induce extra capacitance, so components should be directly soldered to board. • Surface mount components are preferred over discrete ones for less lead inductance.
PCB Layout
Measured Results • Carrier Frequency: 15 MHz • Bandwidth: Controllable • Output Power: 500 m. W
FM Receiver
FM Demodulation using PLL [2] in PFD LF VCO Ve
Loop Filter Design [3]
VCO Design • VCO free running frequency = Carrier Frequency • VCO Frequency Range is no smaller than Bandwidth • Large VCO gain will increase PLL natural frequency n and thus improves PLL tracking capability
Block Diagram BPF LNA PFD LF VCO Amp
Chipset • 4046 PLL • CLC 425 Wide-band LNA
4046 PLL
Schematic
PCB Layout
Superheterodyne FM Receiver
Block Diagram Input Matching Mixer IF Amp + IF Filter LO FM Demodulator Amp
Chipset • TDA 7000 – FM Radio • LM 3875 – Audio Power Amplifier
TDA 7000 [4]
IF Filter
Quadrature Demodulator Vout fin
IF Harmonic Distortion IF=70 k. Hz
IF Distortion Suppression FLL
Correlator To suppress interstation noise • Not Modulated • Lightly Modulated • Heavily Modulated
Schematic
PCB Layout
Monolithic FSK Transmitter [5]
Block Diagram PLL Reference Frequency Dual Modulus Prescaler Digital Input Analog Input A/D Converter Shift Register Clock Data Sampling Rate Output
Inverter
NAND – 2 Input
NAND – 3 Input
NAND – 4 Input
NOR – 2 Input
XOR
Transmission Gate
Edge-Triggered D Flip-Flop
D Flip-Flop with ‘CLEAR’
Voltage Comparator
8 -to-3 Encoder
A/D Converter
Parallel-Serial Shift Register
Phase-Frequency Detector
VCO
Dual Modulus Prescaler [6]
Output Driver To drive capacitive load with minimum delay
Capacitor Driving Capability CL=100 p f=50 MHz
Synthesizer
Synthesizer Response
ADC and SR Response
Chip Layout
Digital Switching Noise [7]
Noise Mechanism • Digital switching injects current into substrate through various kinds of capacitance, which propagates through the substrate and affects analog circuits. • Digital switching draws current from power supply rail with impedance and thus creates voltage drop on power supply rail.
Digital Switching Noise in PLL • PLL is a typical mixed-signal integrated circuit PFD LF VCO Noise Coupling /N
Simulation Results Error Voltage VCO output
Noise Reducing Techniques • Use Differential Topology • Separate Power Supply Rails • Use guard rings • Multi-chip Module • Heterogeneous integration
Test Structure 1 PFD LF VCO /N All building blocks share power supply rails
Chip Layout 1
Test Structure 2 PFD LF VCO /N The counter uses separate power supply rails
Chip Layout 2
Test Structure 3 PFD LF VCO /N • The counter uses separate power supply rails • The PFD and VCO are shielded and ring guarded
Guard Ring p+ Sink the coupling P-type Substrate p+
On-Chip Shielding Metal 3 Via 2 Via 1 Contact Ohmic Contact ICs Radiation
Chip Layout 3
Test Structure 4 PFD LF VCO /N • The counter uses separate power supply rails • Use guard rings around PFD and VCO • Implement LC VCO
LC VCO Lower Phase Noise than Ring Oscillator
Oscillator Basics • Positive feedback of 2 n phase shift • Unity loop gain - Tank Loss • Phase noise is reverse proportional to Q [8]
Chip Layout
Electromagnetic Coupling
Microstrip Line Coupling 4 3 L W 1 S 2 [9]
Electric Field Distribution Even Mode Odd Mode
Impedance Matrix Zoe - even mode characteristic impedance Zoo - odd mode characteristic impedance - propagation constant
Different Configurations Low Pass Band Pass
Experiment Setup
Results The coupling depends on L, W, S, and
Integrated Inductor Coupling • Coupling between integrated spiral inductors • Coupling from spiral inductors to transistors [10]
2. 5 D Integrated Inductor [11]
Interference Effects on PLL Performance [12]
References 1. 2. 3. 4. 5. Jerry D. Gibson, Principles of Digital and Analog Communications Floyd M. Gardner, Phaselock Techniques Roland E. Best, Phase-Locked Loops – Theory, Design, and Applications W. H. A. Van Dooremolen and M. Hufschmidt, A complete FM radio on a chip R. Jacob Baker, Harry W. Li, David E. Boyce, CMOS Circuit Design, Layout, and Simulation 6. J. Navarro Soares and W. A. M. Van Noije, A 1. 6 -GHz Dual Modulus Prescaler Using the Extended True-Single-Phase-Clock CMOS Circuit Technique, IEEE Journal of SSCC, Vol. 34, No. 1, Jan 1999 7. Patrik Larsson, Measurements and Analysis of PLL Jitter Caused by Digital Switching Noise, IEEE Journal of SSCC, Vol. 36, No. 7, July 2001 8. Dan H. Wolaver, Phase-Locked Loop Circuit Design 9. E. M. T. Jones and J. T. Bolljahn, Coupled-Strip-Transmission-Line Filters and Directional Couplers, IRE Trans on Microwave Theory and Techniques, 1956 10. A. O. Adan, M. Fukumi, K. Higashi, T. Suyama, M. Miyamoto, M. Hayashi, Electromagnetic Coupling Effects in RFCOMS Circuits, 2002 IEEE MTT-S Digest 11. Jaime Aguilera and Joaquin De No, A Guide for On-Chip Inductor Design in a Conventional CMOS Process for RF Application 12. Murat F. Karsi, William C. Lindsey, Effects of CW Interference on Phase-Locked Loop Performance, IEEE Trans on Comm, Vol. 48, No. 5, May 2000
