First Edition CHAPTER 1 1 Statics and Mechanics Slides: 13 Download presentation First Edition CHAPTER 1 1 Statics and Mechanics of Materials Ferdinand P. Beer E. Russell Johnston, Jr. John T. De. Wolf 순수휨 David M. Mazurek © 2011 The Mc. Graw-Hill Companies, Inc. All rights reserved. First Edition Statics and Mechanics of Materials 순수휨: 같은 평면 내에서 크기가 같고 방향이 반대인 모멘트를 받는 일정단 면 부재는 순수휨을 받는다. © 2011 The Mc. Graw-Hill Companies, Inc. All rights reserved. 2 -3 First Edition Statics and Mechanics of Materials 휨으로 인한 변형도 길이가 L인 보요소를 고려한다. 변형한 후에도, 중립면의 길이는 L이다. 다른 면에서는, © 2011 The Mc. Graw-Hill Companies, Inc. All rights reserved. 2 -7 First Edition Statics and Mechanics of Materials 미국 표준 형강의 단면 성질 © 2011 The Mc. Graw-Hill Companies, Inc. All rights reserved. 2 - 10 Vector mechanics for engineers: statics 10th editionVector mechanics for engineers statics 10th editionVector mechanics for engineers statics 10th editionVector mechanics for engineers 10th editionForce system in engineering mechanicsStatics of rigid bodiesEngineering mechanics statics in si unitsWhat is line of actionMechanics of materials chapter 10Mechanics of materials chapter 7Mechanic of materialsMechanics of materials 6th edition beer solution chapter 5Mechanics of materialsBeer johnston
