EV Tech Process 1. 2. 3. 4. 5. 6. Accumulator Electrical Inspection Vehicle Electrical Inspection Mechanical Inspection Tilt Test Rain Test Brake Test Process must be completed in order. SAE INTERNATIONAL Formula SAE Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 2

Accumulator Electrical Inspection • Located in the charging area in the Danley Building • Time: Tuesday, June 19 th 3 PM – 5 PM Wednesday, June 20 th 9 AM – 7 PM (no new accumulator after 6 PM) Thursday, June 21 st – Friday, June 22 nd 8 AM – 5 PM • Bring: • Accumulator (removed from the vehicle and on accumulator hand cart) • Safety equipment • Charging equipment • Tools to open accumulator • ESF and component datasheets • Printout of rules inquiries • EV tech sheet SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 3

Vehicle Electrical Inspection • Located in the Danley building. • Time: Wednesday, June 20 th 11: 30 AM – 7 PM (no new cars after 6 PM) Thursday, June 21 st – Friday, 22 nd 8 AM – 5 PM • Bring: • Vehicle with accumulator installed • Tools to open TS enclosures • Tools to remove wheels • Jack stand for vehicle • Systems for demonstrating BSPD • ESF and component datasheets • Printout of rules inquiries • EV Tech Sheet SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 4

Mechanical Inspection • Located in the Danley Building • Driver Gear check needs to be completed prior to entering Mechanical Technical Inspection • Times: Wednesday, June 20 th 1 PM – 7 PM (no new cars after 6 PM Thursday, June 21 st – Friday, June 22 nd 8 AM – 5 PM Friday after 2 PM by appt only • Bring: • Vehicle with accumulator installed • Printout of rule inquiries • IC Tech Sheet • Items outlined tech description SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 5

Tilt Test • Located east of Danley Building facing airport • Time: Thursday, June 21 st 9: 30 AM – 5 PM Friday, June 22 nd 8 AM – 5 PM • Bring: • Vehicle with accumulator installed. • Driver with complete driver gear. • IC Tech Sheet Must be completed before rain test! SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 6

Rain Test • Located outside Danley Building in front of Fire Station. • Time: Thursday, June 21 st Noon – 5 PM Friday, June 22 nd 8 AM – 5 PM • Bring: • Vehicle with accumulator installed • Jack stand • Tools to remove driver wheels • EV tech sheet SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 7

Brake Test • Located east of Danley Building facing airport • Time: Thursday, June 21 st 9: 30 AM – 5 PM Friday, June 22 nd 8 AM – 5 PM • Bring: • Vehicle with accumulator installed. • Driver with complete driver gear. • IC Tech Sheet SAE INTERNATIONAL Formula SAE Lincoln Dynamic Events Drivers PPT 2015 Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 8

QUESTIONS? Be sure to contact Kaley Zundel at kzundel@sae. org to reserve a spot for 1 hour Live Q&A with EV Tech Lead, Danny Bocci. Live Q&A will be Tuesday, June 12 th @ 3: 00 PM EST. SAE INTERNATIONAL Formula SAE Copyright © SAE International. Further use or distribution is not permitted without permission from SAE 9
