European Cryogenics Days, academia meets industry on developments in cryogenics Visits Organisation ECD 10

European Cryogenics Days, academia meets industry on developments in cryogenics Visits Organisation ECD 10 June 2016

LHC P 18 CERN Magnet Factory CRYOLAB ECD 10 June 2016

LHC P 18 CERN Magnet Factory CRYOLAB ECD 10 June 2016

LHC Point 18. The cryogenic systems at LHC point 1. 8. The upper 18

LHC Point 18. The cryogenic systems at LHC point 1. 8. The upper 18 k. W cold-box, and its corresponding compressor station as well as two 125 m 3 liquid helium storage tanks will be visited; 1. LHC Cold box 2. LHC Compressor hall 2 ECD 1 3 3. LN 2 storage 4. LHe & Ghe storage 4 10 June 2016

CERN Magnet Factory The CERN Large Magnet Facility (building 180) where one can have

CERN Magnet Factory The CERN Large Magnet Facility (building 180) where one can have a look at the large magnet repair and construction facilities at CERN; 3. LHC magnet, Mo cup interconnections (bus-bars consolidation) 2. Winding area 1. Bus-bars fabrication 6. Pressure test bench ECD 10 June 2016 5. Final magnet assembly area 4. Press and welding magnet frets

CRYOLAB tour The Central Cryogenic Laboratory (building 165). During the visit one can have

CRYOLAB tour The Central Cryogenic Laboratory (building 165). During the visit one can have a look at normal helium, in a glass cryostat, being brought to its superfluid state. Several experiments with superfluid helium will be performed; ECD 10 June 2016

Hall 163 The Superconducting Cable Test Facility (building 163) will provide an introduction to

Hall 163 The Superconducting Cable Test Facility (building 163) will provide an introduction to the cryogenic superconducting wire and cable test facilities. SC Cable characterization FRESCA Cable Test Facility Nb. Ti and Nb 3 Sn strand characterization (up to 2 k. A, 12. 5 T and 1. 9 K). Measurements of critical current, contact resistance, RRR and magnetization. Measurements of SC cable at 1. 8 and 4. 5 K, with current up to 50 k. A and in field up to 10. 3 T. ECD 10 June 2016

VISIT START European Cryogenics Days, academia meets industry on developments in cryogenics Meeting point

VISIT START European Cryogenics Days, academia meets industry on developments in cryogenics Meeting point at 13: 45. Bus departure at 14: 00 sharp. ECD 10 June 2016

VISIT Arrival European Cryogenics Days, academia meets industry on developments in cryogenics Arrival point

VISIT Arrival European Cryogenics Days, academia meets industry on developments in cryogenics Arrival point at ~16: 40. ECD 10 June 2016

Recommendations…… 1) Closed shoes MANDATORY, flat or square heels. 2) Bring your ID (visit

Recommendations…… 1) Closed shoes MANDATORY, flat or square heels. 2) Bring your ID (visit take place in Switzerland & France). 3) No bus changes, respect colour code. 4) Please follow guide instruction during visit. PLEASE DO NOT TOUCH OR APPROACH TOO CLOSE THE LHC CRYOGENIC EQUIPMENTS DURING THE VISIT OF P 18 !! 5) Please be on time. ECD 10 June 2016

If you need any helps… Yours bus guides are: Olivier Pirotte: 0041754113270 Caroline Cazenoves:

If you need any helps… Yours bus guides are: Olivier Pirotte: 0041754113270 Caroline Cazenoves: 0041754119675 Marco Pezzetti: 0041754114121 In case of any problem contact: Johan Bremer at 0041754110553 ECD 10 June 2016
