ES4000 Mail Server Appliance Example Definition Combine RS3000

ES-4000 Mail Server Appliance

Example Definition Combine RS-3000 and ES-4000 to setup mail server with Mail Security feature. RS-3000 – WAN IP: 60. 250. 158. 64 LAN IP: 192. 168. 1. 0 / 24 DMZ IP: 192. 168. 3. 0 / 24 ES-4000 – IP: 192. 168. 3. 254

Example - Application

Example Procedure 1. Apply and register a domain name with specific IP address 2. Configure RS-3000 WAN port with the registered IP address 3. Follow ES-4000 wizard to create mail server 4. Enable and Configure ES-4000 Anti-Virus function 5. Create RS-3000 Address to define mail server DMZ IP for Policy setting 6. Create RS-3000 Services to group the necessary services for Virtual server setting 7. Configure RS-3000 Outgoing and Incoming Policy 8. Setup RS-3000 Mail Security feature to define the relay permission for Internet user 9. Enable and configure RS-3000 Anti-Spam feature 10. Disable RS-3000 Anti-Virus feature 11. Verify the configuration result

Domain Registered

RS-3000 WAN 1 l Enter RS-3000 WAN 1 IP with 60. 250. 158. 64

ES-4000 Wizard l ES-4000 wizard step 1: Configure default language and character encoding

ES-4000 Wizard l ES-4000 wizard step 2: Enter mail server IP address

ES-4000 Wizard l ES-4000 wizard step 3: Configure the correct time zone and clock

ES-4000 Wizard l ES-4000 wizard step 4: Enter the Domain name

ES-4000 Wizard l ES-4000 wizard step 5: Enter the IP subnet that is allowed to relay mail

ES-4000 Wizard l ES-4000 wizard step 6: Select the DNS setting. In this example, the step can be ignored

ES-4000 Wizard l ES-4000 wizard step 7: Import the existed account or select to create new account

ES-4000 Wizard l ES-4000 wizard step 8: Import the existed account or select to create new account

ES-4000 Wizard l ES-4000 wizard step 9: Configure HA function if needed

ES-4000 Wizard l ES-4000 wizard step 10: Attention list for network administrator

ES-4000 Mail Security l Enable and configure ES-4000 Anti-Virus Setting

RS-3000 Address l Create RS-3000 address to define mail server IP for Policy setting

RS-3000 Service l Create RS-3000 service group for outgoing Policy

RS-3000 Service l Create RS-3000 service group for incoming Policy

RS-3000 Virtual Server l Create RS-3000 Virtual server 1 for WAN 1

RS-3000 Virtual Server l Create RS-3000 Virtual server 2 for WAN 2

RS-3000 WAN–DMZ Policy l Configure RS-3000 WAN to DMZ Policy for Virtual server 1

RS-3000 WAN–DMZ Policy l Configure RS-3000 WAN to DMZ Policy for Virtual server 2

RS-3000 WAN–DMZ Policy l Configure RS-3000 DMZ to WAN Policy

RS-3000 Mail Security l Define RS-3000 Mail Relay setting

RS-3000 Mail Security l Enable and configure RS-3000 Anti-Spam feature

RS-3000 Mail Security l Disable RS-3000 Anti-Virus feature
