E-ON RAMPION OFFSHORE WIND FARM

Contents • INTRODUCTION • TRACK RECORD • RAMPION SCOPE OF WORK • SUPPLY CHAIN OPPORTUNITIES

OUR PRODUCTS & SERVICES JDR PRODUCTS & SERVICES We design, engineer and manufacture world-class subsea products for major global energy companies and subsea service providers: – – – SUBSEA PRODUCTION UMBILICALS SUBSEA POWER CABLES IWOCS RENEWABLE ENERGY CABLES SUBSEA ENGINEERING EQUIPMENT – GLOBAL SERVICES ARE JDR’S AFTERMARKET DEPARTMENT – ALL JDR SUPPLIED PRODUCTS AND JDR CUSTOMERS WORLDWIDE – INSTALLATION SERVICES – REPAIR & MAINTENANCE – ENGINEERING SUPPORT – TOOLS & EQUIPMENT 3

Global Company 4

Hartlepool Factory 5

Hartlepool Factory 6

Hartlepool Factory 7

Outstanding track record Experience built in major project design, manufacture and delivery London Array Greater Gabbard • • • On construction largest ever offshore wind farm Over 200 km 33 k. V inter-array cables • UK’s first offshore wind farm outside territorial waters Over 200 km 33 k. V inter-array cables Meerwind Sud Ost Wavehub • • • Germany’s first privately-financed offshore wind farm Over 110 km inter-array cables & terminations World’s largest wave energy test centre Located offshore South-West UK 25 km 33 k. V 6 core export cable Zero cable failure rate in service 8

TRACK RECORD Experience built in major project design, manufacture and delivery Sandbank Dudgeon • • • 3 rd JDR’s German offshore wind farm New coilable 630 mm 2 copper core cable 105 km inter-array cable plus accessories New UK offshore wind farm; North Norfolk Will power over 410, 00 homes Rampion • • • UK’s first round 3 Offshore Wind Farm Over 140 km of inter-array cables Global Services Zero cable failure rate in service

E-ON RAMPION OFFSHORE WIND FARM SCOPE OF WORK FOR JDR GLOBAL ON RAMPION OWF DESIGN, ENGINEERING & MANUFACTURING • • • 140 KM+ INTER-ARRAY CABLES T-CONNECTOTS INNERCONE CONNECTORS TREFOIL CLEATS EARTH CABLE PROVIDE PRE-COMMISSIONING & TESTING SERVICES FOR THE JDR SUPPLIED INTER ARRAY CABLES • WTG & OSS OFFSHORE INSTALLATION • TWO STAGES - MAY 2016 & MARCH 2017 - 21 PERSONNEL PERMANENTLY

SUPPORT JDR REQUIRE FROM LOCAL BUSINESSES PRODUCT SUPPLY: • GSWA, • BITUMEN TAPES, • POLYPROYELNE ROPE FILLERS & STRING, • BITUMENISED HESSIAN TAPES SERVICE SUPPLY: • CREW TRANSFER VESSELS (CTV) • CTV DOCKING AND FUELLING • OFFSHORE WIND QUALIFIED & EXPERIENCED MANPOWER • TECHNICIANS ACCOMODATION • TECHNICIANS FOOD (DAYTIME & EVENING) • LAUNDRY • DAILY TRANSPORT OF TECHNICIANS • LOCAL STOCKISTS OF CONSUMABLES ie PPE – HARDWARE ITEMS – • MEDICAL FACILITIES / ASSISTANCE • OFFSHORE SCAFFOLDING • HV TESTING EQUIPMENT • OFFSHORE GENERATORS
