Engineer Training Pneumatic System Overview Confidential Engineer Training

Engineer Training Pneumatic System Overview Confidential

Engineer Training Working Concept Overview: The Pneumatic System is comprised of: q Y Pistons q Z Pistons q Ink Purge q Pneumatic Panel Confidential 2

Engineer Training Y Pressure Roller Pistons The pistons are controlled by the Pneumatic Panel. q They work with an air pressure of 2. 5 bar. q The pressure roller has a total of 3 -5 pistons depending on the machine. q The speed of this pistons can be regulated. Confidential 3

Engineer Training Z Shaft This shaft is controlled by two pistons, which hold the Z rubber Roller. q The Pressure used is 4. 5 Bar. q The speed of those pistons can also be controlled, and for safety reasons it should be very slow. q The Off position for this axis, is when the pistons are UP. If there is a loss of pressure, the roller has two springs, which lift or maintain the roller in the upward position. Confidential 4

Engineer Training Ink Purge We use air pressure of 0. 8 bar to clean the heads, and for this reason, there are two air valves for each color. Each air valve controls 4 heads, and the valve splits to two outputs, one for each partition of the secondary tank. Confidential 5

Engineer Training Pneumatic Panel q This Panel controls the Z pistons and Y pistons. It also regulates and displays the air pressure for the pistons as well as for the Ink Purge. q The Panel is also included in the safety system. If the Emergency Stop is pressed, all air supply to the system will be cut off. Confidential 6

Engineer Training Pneumatic Panel The Panel is comprised of the following: q On / Off Buttons q 3 Valves q 2 Filters q 2 timers q 3 Gauges q Pressure Regulators q Main switch Confidential 7

Engineer Training ON/OFF Buttons These 4 buttons control the Z and Y pistons in the following way. q On Y: when the Green Button is pressed, the pressure roller will go UP. The green button will light. q On Z: when The Green Button is pressed, the rubber shaft will go down. The green button will light. q Pressing the Red Buttons, will turn OFF each Shaft; Y will go down, Z will go UP. The red Button will Light. Confidential 8

Engineer Training TIMERS q There are 2 safety timers which control the delay of each shaft before it starts to move. After pressing any button, an alarm will go off, while the delay is present. q You can adjust this delay in the timers, by rotating the little dial in them, and setting the desired number. The units are in seconds, but that can be changed. Confidential 9

Engineer Training TIMERS (Cont. ) The timer has 4 dip switches. The first 2, define the time range and the last 2 the mode. The Correct setting, should be 1 up, and the rest down, so that the range is in seconds. Confidential 10

Engineer Training Regulators and Filters There are 2 water filters in the panel. The first one on the bottom, filters the whole system from water, and the second one is for the Ink purge, because it is more sensitive. There are 3 regulators, one for each function, Z, Y, and Ink Purge. It adjusts the pressure by turning the black top cap. Confidential 11

Engineer Training Gauges and Main Air Valve There are three gauges, one for each section. They display the current pressure applied. The first for Ink Purge (0. 6 bar), the second Y pistons (2. 5 Bar) and the third is Z pistons (4. 5 Bar). The main Ink Valve, open and closes the entrance of Air to the whole system. Confidential 12

Engineer Training VALVES There are 3 electronic valves in the panel. One is for the safety system, which cuts off all air entrances if the emergency button is pressed. And the other two are for the Y and Z piston control. Confidential 13

Engineer Training Confidential General Diagram 14

Engineer Training Confidential System Diagram 15
