Emission Control Devices for Diesel Fleets MECA Who

Emission Control Devices for Diesel Fleets

MECA – Who We Are • MECA represents the world’s leading manufacturers of emission control technology for mobile sources – – Catalyst manufacturers Substrate manufacturers Exhaust component manufacturers Exhaust system integrators • MECA members have extensive technical, manufacturing, and installation experience with the application of emission control technologies to a wide variety of on-road and off-road vehicles and equipment • MECA members have verified many of the on-road and off-road retrofit technologies listed by EPA, ARB, VERT (Switzerland) 2

Diesel Retrofit Technology Highlights • Many proven and commercial diesel retrofit technologies are available spanning a variety of applications – On-road vehicles (long-haul trucks, drayage trucks, school buses, transit buses, garbage trucks, emergency vehicles) – Off-road engines and equipment (construction equipment, port equipment, mining equipment, marine engines, locomotives, transport refrigeration units) – Stationary diesel engines • Larger variety of passive and active DPFs now available – Hybrid DPFs – DPFs for EGR engines • Retrofit technologies can help reduce global warming – Filter technologies provide reductions in black carbon • Retrofit technologies provide multi-pollutant co-benefits – Catalyzed devices reduce hazardous air pollutants (HAPs) • ULSD availability enables the lowest emissions and ensures reliability

Diesel Retrofit Technology Highlights • Funding for retrofits increasingly available at federal and state levels (DERA, CMAQ, SEPs, state incentives) – American Recovery and Reinvestment Act of 2009 • Cities/projects using “clean construction” requirements expanding • Regulations/programs stimulate technology advances and help define market opportunity – – EPA’s Voluntary Diesel Retrofit Program ARB’s Diesel Risk Reduction Program State retrofit programs Tighter emission standards on new engines worldwide • Verification process needs adequate technical resources – Demonstration programs/funding help fill the retrofit verification pipeline • EPA Emerging Technologies Program • ARB/SCAQMD Off-Road Showcase Program • Texas NTRD funding for NOx retrofits

Retrofit Products Level 1 Diesel Oxidation Catalyst(DOC) 20 - 40% particulate matter(PM) • • Maintenance Free Stainless steel OE muffler replica Level 2 None available Crankcase Ventilation System(CCV) 100% reduction engine emissions Level 3 Diesel Particulate Filter(DPF) 90%Particulate matter reduction 2 types of DPF’s • Passive filters- self regeneration • Active(Purifilter Plus)- plug in system

Purimuffler(DOC) vs. Purifilter(DPF)

Wall-Flow Diesel Particulate Filters Offer the Highest PM Reduction Efficiency • • • >85% PM reduction (ARB Level 3) Large reduction in toxics from catalyzed DPFs >250, 000 retrofits worldwide >6 million OE applications Same technology as on MY 2007 and newer OE trucks Data logging process 8

Backpressure Monitor/Logger (used with DPF’s only(Passive and Active) • Extended datalogging capability (up to 2 yrs) Dash board mounted • Measures back pressure • Exhaust Temperature • Regeneration frequency • Multi-light displays to indicate system faults, warnings and alarm conditions – Real time monitoring • Includes data analysis software Mounted in engine compartment

Cleaning Machine for a Diesel Particulate Filter(DPF) • • Combi. Clean™ Station Computer sensors Universal for all filters One machine does it all Heat Vacuum Air

Purifilter Highway Installations

Diesel Particulate Filters(DPF’s) in Non-road Applications

Active DPF “Purifilter Plus” Heater Elements • speed of regeneration • K Model = 8 hrs(240 sgle) • S = 120 min. (440, 3 ph) Silicon Carbide Substrate

Emeryville Installations- 2006 International DT 466 E w’EGR • Vehicle plugged in weekly • 2006 International DT 466 - 245 hp • 6 NVXH 0466 AEA • Purifilter Plus SCP 17 H

Emeryville Purifilter Plus Panel Installation Operating Instructions Panel Transformer

Emeryville Installations- 2006 International DT 466 E w’EGR • Vehicle plugged in bi-weekly • 2006 International DT 466 - 245 hp • 6 NVXH 0466 AEA • Purifilter Plus SCP 17 H

Crankcase Ventilation Filter System(CCV) Filter Change Indicator No Filter Change Indicator! (Optional dash Mounted indicator Available) Cover AND regulator are removed to access the element. Canister lowers with two easy latches. No hoses are attached to the canister. Large hoses are required to move during servicing. Change Filters every other oil change ! Change Filters every oil change ! Separate external Bypass - with no Indication when Bypass has occured Larger Size Smaller Size Other ECS CCV No bypass -A truly closed Crankcase !

CCV in Action

ECS Direct Fit Kit for International DT 444 engines

CCV Filter Cartridge Change Open Canister Remove filter, replace & close

Sales Process Contact an EPA or CARB verified vendor Discuss available funding Review products available to you • Choose a technology – Tailpipe: DOC, DPF(passive) or Purifilter Plus(active) – Engine: CCV • Dealer provides a quote for project(labor/materials) – Obtain fleet list • Submit grant application • Receive funding and begin project • Air regulations will increase over time. There will likely not be enough funding to cover the future demand. • Mandates cannot be funded!

Sample Fleet List

Dana Brewster Central Region Sales Manager Engine Control Systems dabr@enginecontrolsystems. com www. enginecontrolsystems. com (440)840 -2511
