EMC Data Domain: Leadership and Innovation A history of industry firsts 2003 2004 2005 First deduplication NAS First deduplication volume replication 2006 2007 First deduplication virtual tape library 2008 Largest deduplication array Fastest backup controller First deduplication directory replication First deduplication nearline storage © Copyright 2011 EMC Corporation. All rights reserved. 2009 Cascaded replication 2011 2010 First long-term retention system for backup and archive First distributed processing 2

Deduplication Dramatically Reduces Storage Capacity Requirements Deduplication 10– 30 times less data stored versus fulls + incrementals with typical retention policies Data Stored 30 20 10 0 1 5 10 15 20 Weeks in Use Deduplication storage Traditional storage © Copyright 2011 EMC Corporation. All rights reserved. 3

Backup Data Reduction/Deduplication Time Series of Large Enterprise Implementation 2 H '07 2 H '08 1 H '09 2 H '09 15% 24% 12% 27% 8% 40% 1 H '10 31% 16% 4% In Pilot/Evaluation 14% 7% In Near-term Plan 21% In last three years, in-use rates for backup with 26% deduplication 25% have risen from 15% to 48% 6% 48% 25% 28% 15% 46% 1 H '11 In Use Now 14% 22% 14% 16% In Long-term Plan 20% 17% 7% 18% 10% Past Long-term Plan 13% Not in Plan Source: Wave 15 Storage Study – Q 2 2011, published 5/16/11, large-enterprise sample; H ‘ 07, n=151; 2 H ‘ 08, n=127; 1 H ‘ 09, n=147; 2 H ‘ 09, n=182; 1 H ‘ 10, n=146; 1 H ‘ 11, n=31; The. Info. Pro (www. theinfopro. com) © Copyright 2011 EMC Corporation. All rights reserved. 4

Backup Data Reduction/Deduplication Large Enterprise EMC Competitor 1 The “in-use” rating for EMC is now over 3 x that of its nearest competitor Competitor 2 Competitor 3 Competitor 4 Competitor 5 Competitor 6 Competitor 7 0% In Use Now (Not Including Pilots) 10% 20% 30% In Pilot/Evaluation (Budget Has Already Been Allocated) 40% 50% Near-term Plan Long-term Plan 60% 70% Past Long-term Plan (> 18 Months Out) Source: Wave 15 Storage Study – Q 2 2011, published 5/16/11, large-enterprise sample, n=31, The. Info. Pro (www. theinfopro. com) © Copyright 2011 EMC Corporation. All rights reserved. 5

Purpose-Built Backup Appliances Open Systems + Mainframe EMC IBM HP Oracle EMC: 64. 2% 2010 Total Market $1. 69 B Quantum Sepaton Falcon. Stor Dell Others Source: Worldwide Purpose-Built Backup Appliance 2011– 2015 Forecast and 2010 Vendor Shares , May 2011, IDC. Chart: Worldwide Supplier Revenue, Total PBBA Market © Copyright 2011 EMC Corporation. All rights reserved. 6

With Data Domain Deduplication Storage Systems, You Can… Retain longer Keep backups onsite longer with less disk for fast, reliable restores, and eliminate the use of tape for operational recovery Replicate smarter WAN Move only deduplicated data over existing networks with up to 99% bandwidth efficiency for cost-effective disaster recovery Recover reliably Continuous fault detection and self-healing ensure data recoverability to meet service level agreements © Copyright 2011 EMC Corporation. All rights reserved. 7

Deduplication Fundamentals © Copyright 2011 EMC Corporation. All rights reserved. 8

Data Domain Basics Easy integration with existing environment Control Tier Backup and Archive Applications Target Tier CIFS, NDMP, DD Boost Ethernet EMC Symantec Disaster Recovery Tier Replication Virtual Tape Library (VTL) over Fibre Channel Comm. Vault IBM HP Veeam Quest © Copyright 2011 EMC Corporation. All rights reserved. DD 890 appliance DD 890 appliance 2 U 2 to 14 ports 10 and 1 Gigabit Ethernet; 8 Gb/s Fibre Channel RAID 6 Up to 285 TB usable capacity with shelves 2 TB or 1 TB 7. 2 K rpm SATA HDD in shelf File system NVRAM N+1 fans and redundant, hot-plug power supplies 9

Data Deduplication: Technology Overview Store more backups in a smaller footprint Friday Full Backup A B C D Mon Incremental A E F A B H C Tues Incremental E Weds Incremental Thurs Incremental A B G Backup Data Estimated Reduction Logical Physical FRIDAY FULL 1 TB 2– 4 x 250 GB Monday Incremental 100 GB 7– 10 x 10 GB Tuesday Incremental 100 GB 7– 10 x 10 GB Wednesday Incremental 100 GB 7– 10 x 10 GB Thursday Incremental 100 GB 7– 10 x 10 GB Second FRIDAY FULL 1 TB 50– 60 x 18 GB 2. 4 TB 7. 8 x 308 GB I G J C K Second Friday Full Backup B C D E F L G H TOTAL A B C D E F G H I J K L © Copyright 2011 EMC Corporation. All rights reserved. 10

Retain: Store More for Longer with Less Over one year of retention in 3 U of Data Domain deduplication storage Backup Data Cumulative Logical First Full 1 TB 4 x 250 GB Week 1 April 7 2. 4 TB 8 x 308 GB Week 2 April 14 3. 8 TB 10 x 366 GB Week 3 April 21 5. 2 TB 12 x 424 GB Month 1 April 28 6. 6 TB 14 x 482 GB Month 2 May 31 12. 2 TB 17 x 714 GB Month 3 June 30 17. 8 TB 19 x 946 GB Month 4 July 31 23. 4 TB 20 x 1, 178 GB TOTAL 23. 4 TB 20 x 1, 178 GB © Copyright 2011 EMC Corporation. All rights reserved. Estimated Reduction Physical 11

Data Integrity: Data Invulnerability Architecture End-to-end data verification Checksum Deduplication, write to disk Verify Self-healing file system Cleaning Expired data Defrag Verify Generate Checksum Verify Data File System Deduplication Local Compression RAID Verify the file system metadata integrity Verify user data integrity Verify stripe integrity Other RAID 6 NVRAM Snapshots © Copyright 2011 EMC Corporation. All rights reserved. End-to-end data verification 12

Network-Efficient Replication for True Disaster Recovery Lowers WAN costs; improves service level agreements 1– 5% DB Flexible replication One-to-many Many-to-one Bi-directional System-to-system Cascaded Data Domain system Archive data Home WAN Backup data Domain system 1– 5% Home Data Domain system Data Domain Global Deduplication Array Source: Remote sites 95– 99% cross-site bandwidth reduction © Copyright 2011 EMC Corporation. All rights reserved. Destination: Data Center Hub Supports hundreds of remote sites 13

DD Boost Software • Distributes parts of deduplication process to backup server or application clients – Licensable software works across Data Domain portfolio DD Boost • Supports majority of backup software market – EMC Avamar and Net. Worker – Symantec Net. Backup and Backup Exec • Speeds backups by up to 50 percent • Process more backups with existing resources – 20– 40% less overall impact to backup server – 80– 99% less LAN bandwidth • Enables Data Domain replication management from the backup application © Copyright 2011 EMC Corporation. All rights reserved. 14

Additional Data Domain Software Options Data Domain Virtual Tape Library Data Domain Replicator • Easily integrates with Fibre Channel • Network-efficient and encrypted • Emulates multiple tape libraries • Transfers only compressed, deduplicated data over the WAN • Supports open systems and IBM i operating environments • Consolidate up to 270 remote sites into a single system Data Domain Retention Lock Data Domain Encryption • File locking to satisfy IT governance and compliance policies • Inline encryption of data at rest • Electronic data shredding • Satisfies internal governance rules and compliance regulations • Protects against theft or loss of a physical system © Copyright 2011 EMC Corporation. All rights reserved. 15

DD Archiver Overview Cost-optimized, long-term retention • Data Domain system for backup and archive – Active tier: short-term data protection; less than 90 days – Archive tier: scalable long-term retention; multiple years • High-throughput deduplication storage – Up to 9. 8 TB/hr • Cost optimized for long-term retention – Up to 570 TB usable, 28. 5 PB logical capacity – Low cost per gigabyte while maintaining high throughput – Fault isolation of archive units for long-term recoverability • Leverage existing Data Domain system advantages – Supports DD Replicator and DD Retention Lock software options – Data Domain Data Invulnerability Architecture to ensure data integrity © Copyright 2011 EMC Corporation. All rights reserved. 16

Industry’s Most Scalable Inline Deduplication Systems Global Deduplication Array DD Archiver DD 800 Appliance Series DD 600 Appliance Series Software options: DD Boost, DD Virtual Tape Library, DD Replicator, DD Retention Lock, and DD Encryption DD 160 Appliance DD 160 DD 620 DD 640 DD 670 DD 860 DD 890 Global Deduplication Array DD Archiver Speed (DD Boost) 1. 1 TB/hr 2. 4 TB/hr 3. 4 TB/hr 5. 4 TB/hr 9. 8 TB/hr 14. 7 TB/hr 26. 3 TB/hr 9. 8 TB/hr Speed (other) 667 GB/hr 1. 1 TB/hr 2. 3 TB/hr 3. 6 TB/hr 5. 1 TB/hr 8. 1 TB/hr 10. 7 TB/hr 4. 3 TB/hr Logical capacity 40– 195 TB 83– 415 TB 0. 32– 1. 6 PB 0. 6– 2. 7 PB 1. 4– 7. 1 PB 2. 9– 14. 2 PB 5. 7– 28. 5 PB Usable capacity Up to 3. 98 TB Up to 8. 3 TB Up to 32. 2 TB Up to 55. 9 TB Up to 142 TB Up to 285 TB Up to 570 TB © Copyright 2011 EMC Corporation. All rights reserved. 17

Deduplication Storage Evaluation Criteria © Copyright 2011 EMC Corporation. All rights reserved. 18

Methodology: Inline vs. Post-Process Deduplication INLINE POST-PROCESS Deduplication Before Storing Deduplication After Storing Deduplication Store Deduplication 3 x disk accesses to shared store Other activities unimpeded − Predictable − Simpler The more processes, the more resource contention − − Copy to tape: Too slow to stream tape Recovery: Service level agreement predictability Replication: Poor time-to-disaster-recovery Deduplication: If interleaved with backup or restore More administration to fight these issues © Copyright 2011 EMC Corporation. All rights reserved. 19

Performance: CPU-Centric vs. Spindle-Bound Data Domain Throughput MB/s 6, 000 Fibre Channel SATA Most deduplication vendors 50 50 100 150 200 Number of Disk Spindles © Copyright 2011 EMC Corporation. All rights reserved. 20

Data Domain Systems Trajectory Data Domain SISL Scaling Architecture: CPU-centric Improvement since 2004: Throughput: ~175 x Capacity: ~450 x Throughput GB/s 5 3 1. 5 0. 04 le g Sin DD 200 (2004) 2004 © Copyright 2011 EMC Corporation. All rights reserved. ler Array l o r nt tion o c ca al. Du dupli De l a b st o o Glo B DD ols c o rot p rd a d n sta , r le l o r nt -co 2010 2011 2014 (est. ) Future 21

Why Data Domain? Less disk to resource, less to manage • CPU-centric deduplication • Inline deduplication Simple, mature, and flexible • Simple, mature appliance • Any fabric, any software, backup or archive applications Resilience and disaster recovery • Storage of last resort • Fast time-to-disaster recovery (DR) readiness • Cross-site global compression – Data center or remote office © Copyright 2011 EMC Corporation. All rights reserved. 22

Data Domain Infrastructure and Ecosystem Supports a variety of workloads and data types Backup VMware Microsoft Share. Point Oracle SAP Archive NAS, SAN, DAS CA HP Vizioncore IBM i EMC Bus-Tech Primary storage Archive Applications Backup Applications EMC Symantec Comm. Vault Midrange and Mainframe EMC F 5 Networks Symantec Comm. Vault IBM Atempo Bak. Bone Disaster Recovery Network © Copyright 2011 EMC Corporation. All rights reserved. Replication over WAN 24

Enterprise Recoverability Readiness at Disaster Recovery Site Data Domain inline deduplicated replication DR-ready Replicate during backup “Adaptive” post-process deduplicated replication Backup to Cache “Scheduled” post-process deduplicated replication Backup to Cache Backup time 1. 7 -times longer than Data Domain DR-ready Deduplicate and replicate less than 50% ingest speed—two times longer if uncompressed at fixed bandwidth Backup time 1. 1 -times longer than Data Domain DR-ready Deduplicate and replicate less than 50% ingest speed—two times longer if uncompressed at fixed bandwidth Backup to VTL/tape/truck Recall tapes Copy to tape Truck to storage © Copyright 2011 EMC Corporation. All rights reserved. Truck from storage ? 25

EMC Global Services Strategize CONSULTING • Strategic Observation service establishes a roadmap/vision to meet your recovery objectives • Operational Readiness service recommends a Reference Architecture that leverages EMC deduplication technologies and optimizes your implementation Design TECHNOLOGY DEPLOYMENT • Best practice methodologies from architecture through integration • Assessment, Design/ Implementation, Operational Assurance, Health Check, Data Migration © Copyright 2011 EMC Corporation. All rights reserved. Implement MANAGED SERVICES • Residency Services provide onsite or remote skilled service professionals with proven best practices and technology expertise MAINTENANCE AND SUPPORT • 360° global, proactive, and preemptive procedures and solution support Manage EDUCATION • Open Storage Technology education, EMC technologyspecific learning paths, EMC Proven Professional Certification • Remote Managed Services provide costeffective, ITIL-based, 24 x 7 intelligent remote monitoring and operational infrastructure management 26

Why EMC Global Services ? Save money • Significantly lower implementation and operating expenditures • Fill internal resource gaps for less • Protect investments in EMC solutions Accelerate time to value • Reduce deployment time • Accelerate return on investment for new projects • Ease the burden of compliance while protecting critical business information Mitigate risk and get better results • Configure the solution to meet your requirements • Improve service levels; reduce management costs • EMC best practices and unmatched product expertise = superior customer experience • Reduce disruption while taking advantage of the features and benefits of the latest EMC products and solutions © Copyright 2011 EMC Corporation. All rights reserved. 27
