Ecology of Transgenic Crops Ayo Ecology of Transgenic

  • Slides: 27
Download presentation
Ecology of Transgenic Crops 鄭先祐 生態主張者:Ayo 作室 Ecology of Transgenic Crops

Ecology of Transgenic Crops 鄭先祐 生態主張者:Ayo 作室 Ecology of Transgenic Crops

Ecology of Transgenic Crops n n 2 Genetically engineered plants might generate weed problems

Ecology of Transgenic Crops n n 2 Genetically engineered plants might generate weed problems and affect nontarget organisms, but measuring the risk is difficult. 資料取自: Marvier, M. (2001) Ecology of transgenic crops. American Scientist 89(2): 160 -167. Ecology of Transgenic Crops

基因轉植的問題 n n 3 On May 20, 1999, a short article in Nature called

基因轉植的問題 n n 3 On May 20, 1999, a short article in Nature called attention to a potential ecological problem with a genetically engineered, or transgenic, crop. Losey and his colleagues at Cornell Univ. reported that a variety of transgenic corn could kill the larvae of monarch butterflies. Ecology of Transgenic Crops

Losey and his colleagues found that only 56% of the monarch larvae survived when

Losey and his colleagues found that only 56% of the monarch larvae survived when fed milkweed plants coated with transgenic corn pollen, whereas 100% of larvae survived when the plants were coated with non -transgenic corn pollen. Fig. 1. Monarch caterpillars feed on a milkweed leaf dusted with pollen from corn that was genetically engineered to resist pest. Plant breeders can transfer a gene from a bacterium called Bacillus thuringiensis into corn, which causes it to produce an insecticidal compound, commonly called Bt toxin. 4 Ecology of Transgenic Crops

反對者 vs. 贊成者 n n 5 Opponents of transgenic crops help up the report

反對者 vs. 贊成者 n n 5 Opponents of transgenic crops help up the report as evidence of the potentially devastating environmental impact. Proponents largely dismissed this laboratory-based research as unrepresentative of conditions on real farms. Ecology of Transgenic Crops

基因轉植的威力 n n 6 Genetic engineering makes it possible to transfer genes from virtually

基因轉植的威力 n n 6 Genetic engineering makes it possible to transfer genes from virtually any species – animal, bacteria, plant or virus – into almost any other species, no matter how unrelated the two species might be. 如此可以創造出 將水母的發光基因轉植入 植物,有各種顏色的草(Monsanto 公司)。 Ecology of Transgenic Crops

基因轉植的農作物:激增! n n n 8 In 1996,商業栽植基因轉植的農作物的農 地面積有430萬公頃。 In 1998,農地面積激增至 6, 950萬公頃。 With such

基因轉植的農作物:激增! n n n 8 In 1996,商業栽植基因轉植的農作物的農 地面積有430萬公頃。 In 1998,農地面積激增至 6, 950萬公頃。 With such rapidly in creasing use of transgenic crops, scientists and society must weigh whether the potential benefits outweigh the potential risks. Ecology of Transgenic Crops

基因轉植,more than 育種? n n n 9 Do transgenic crops pose different risks from

基因轉植,more than 育種? n n n 9 Do transgenic crops pose different risks from those common to crops created through traditional methods of plant breeding? Genetic engineering can create many more combinations of genes and new traits than can traditional breeding. This greatly enhanced novelty diminishes anyone’s ability to predict the safety of a transgenic organism on the basis of past experience. Ecology of Transgenic Crops

DDT的案例 n n 10 Scientists and manufactures considered DDT totally risk-free when first marketed

DDT的案例 n n 10 Scientists and manufactures considered DDT totally risk-free when first marketed in the late 1940 s, and data that documented ill effects took nearly 20 years to surface. Similarly, major problems might result from transgenic crops over time. Ecology of Transgenic Crops

Fig. 2. DDT gets praise from an advertisement in the June 30, 1947, issue

Fig. 2. DDT gets praise from an advertisement in the June 30, 1947, issue of Time. 11 Ecology of Transgenic Crops

Insect-resistant transgenic crops n n n 12 Creating new weeds Troubles for non-targets What

Insect-resistant transgenic crops n n n 12 Creating new weeds Troubles for non-targets What is significantly safe? Setting standards for sampling Dealing with uncertainty Ecology of Transgenic Crops

Creating new weeds n n 13 The release of organisms with novel phenotypes bears

Creating new weeds n n 13 The release of organisms with novel phenotypes bears similarities to the introduction of nonnative species. 許多的證據顯示,許多外來種,可能如同雜草 (weeds),造成對環境和經濟的傷害。 抗蟲的植物,可能會有較強的擴散能力,如同雜草。 Hybridization between a transgenic crop and a related non-crop plant can spread novel traits to additional species. Ecology of Transgenic Crops

Fig. 3. Purple loosestrife ranks as one of the most economically costly and environmentally

Fig. 3. Purple loosestrife ranks as one of the most economically costly and environmentally destructive examples of non-native species. 14 Ecology of Transgenic Crops

Fig. 4. Invertebrate herbivores can limit plant reproduction. This graph represents the pooled results

Fig. 4. Invertebrate herbivores can limit plant reproduction. This graph represents the pooled results from many experiment on the impacts of invertebrate herbivores on plant-reproductive performance. 有蟲和無蟲,production of flowerers, fruits or seeds 的 量,相差可高達 25倍。 15 Ecology of Transgenic Crops

Troubles for non-targets 案例: n a plant that is toxic to Colorado potato beetles

Troubles for non-targets 案例: n a plant that is toxic to Colorado potato beetles could conceivably also be toxic to non-pest beetles or to beetles that actually benefit farmers, including ladybird beetles. n Losey and his colleagues studied the effects of pollen produced by transgenic corn that resists lepodopteran pests. 16 Ecology of Transgenic Crops

17 ↑Bt corn 的蛀蟲↑ Ecology of Transgenic Crops

17 ↑Bt corn 的蛀蟲↑ Ecology of Transgenic Crops

Fig. 5. This corn releases an insecticidal compound (red) through its roots into the

Fig. 5. This corn releases an insecticidal compound (red) through its roots into the soil. That compound can remain insecticidal for 230 days or more and could impact populations of soil organisms. In addition, pollen from Bt corn (blue) can travel as far as 60 meters, where it coats the surface of non-crop plants. Non-target insects, including monarch butterfly larvae, consume some of the 18 Ecology of Transgenic Crops windblown corn pollen.

What is significantly safe? n n n 19 Transgenic crops that produce insect toxins

What is significantly safe? n n n 19 Transgenic crops that produce insect toxins must undergo two separate reviews of environmental safety before they can be sold commercially in the U. S. 1. EPA reviews laboratory studies assessing a crop’s effects on particular non-target organisms, including pollinators, predatory insects and, often, soil invertebrates. 2. Sufficient field data regarding a crop’s performance and safety. Ecology of Transgenic Crops

樣品數極少! 申請通過的案例: n 編號:#97 -012 -01 p n 內容:A variety of Bt cotton n

樣品數極少! 申請通過的案例: n 編號:#97 -012 -01 p n 內容:A variety of Bt cotton n In experiments designed to test this transgenic crop’s impact on soil invertebrates, investigators placed four replicate batches of earthworms– with 10 worms per batch– in soil that included ground leaves from either transgenic or nontransgenic cotton. n 測試: 14天。 21 Ecology of Transgenic Crops

 • 兩者間平均差距有 29. 5%,但是統計的結 果是差異不顯著。 • 這明顯的是因為樣品 數過少所造成的結果。 • 另外,實驗的時間只 有14天,這也明顯的太 短。 Fig.

• 兩者間平均差距有 29. 5%,但是統計的結 果是差異不顯著。 • 這明顯的是因為樣品 數過少所造成的結果。 • 另外,實驗的時間只 有14天,這也明顯的太 短。 Fig. 6. The batches of earthworms exposed to Bt cotton increased in weight on average by 49% (↑). The earthworms exposed to nontransgenic cotton increased in weight on average by 22 78. 5% (→). Ecology of Transgenic Crops

案例: n The Swiss Federal Research Station found that green lacewings, which are beneficial

案例: n The Swiss Federal Research Station found that green lacewings, which are beneficial predatory insects, experienced 62% mortality when fed a diet of pests reared on Bt corn, but only 37% mortality when fed pests reared on nontransgenic corn. n 樣品數: 200個體 per treatment. n 而且認為應該要進行 over the entire life span的 測試。 24 Ecology of Transgenic Crops

A scientific advisory panel n n n 25 Met in December 1999 to review

A scientific advisory panel n n n 25 Met in December 1999 to review the EPA guidelines and recommended the following: The agency (EPA) should consider how the data will be used and establish an acceptable level of statistical power. Based on these decisions, appropriate tests and sample sizes can be determined. http: //www. epa. gov/scipoly/sap/1999/index. htm Ecology of Transgenic Crops

Dealing with uncertainty n n n 26 Risk analysis should reveal how the public

Dealing with uncertainty n n n 26 Risk analysis should reveal how the public good might suffer if new technologies backfire. We could assume that a transgenic product is unsafe until the manufacturer demonstrates its safety. Further exploration: http: // www. americanscientist. org/articles/01 articles/ marvier. html Ecology of Transgenic Crops

v 問題與討論! japalur@hotmail. com Ayo 清華站 http: //mx. nthu. edu. tw/~hycheng 27 Ecology of

v 問題與討論! japalur@hotmail. com Ayo 清華站 http: //mx. nthu. edu. tw/~hycheng 27 Ecology of Transgenic Crops
