EARTHQUAKE RESILIENT CITY BEING PLANNED FOR TOKYO A BACKUP IN CASE OF DISASTER Walter Hays Global Alliance For Disaster Reduction

REGIONAL MAP

LOCATION OF TOKAI

TOKYO: A MEGACITY AT RISK FROM EARTHQUAKES

CAN TOKYO BE EARTHQUAKE RESILIENT? ALTHOUGH VERY VULNERABLE, TOKYO WANTS TO BECOME RESILIENT AS QUICKLY AS POSSIBLE

RISK ASSESSMENT • HAZARD MAPS • INVENTORY • VULNERABILITY • LOCATION DATA BASES AND INFORMATION ACCEPTABLE RISK UNACCEPTABLE RISK TOKYO—THE CAPITAL CITY EARTHQUAKE RESILIENCE POLICY OPTIONS HAZARDS: GROUND SHAKING GROUND FAILURE SURFACE FAULTING TECTONIC DEFORMATION TSUNAMI RUN UP AFTERSHOCKS • PREPAREDNESS • PROTECTION • EMERGENCY RESPONSE • RECOVERY

FAULT RUPTURE DAMAGE/LOSS EARTHQUAKE GROUND SHAKING DAMAGE/LOSS TSUNAMI DAMAGE/ LOSS TECTONIC DEFORMATION DAMAGE/ LOSS FOUNDATION FAILURE DAMAGE/ LOSS SITE AMPLIFICATION DAMAGE/ LOSS LIQUEFACTION DAMAGE/ LOSS LANDSLIDES DAMAGE/ LOSS AFTERSHOCKS DAMAGE/ LOSS FIRES DAMAGE/ LOSS

A VIEW OF TOKYO FROM TOKYO SKY TREE TOWER: NOVEMBER 2, 2011

The catastrophe caused by the M 9. 0 Tohoku earthquake and tsunami on March 11, 2011 and concern about inevitable earthquake disasters in the future served as a catalyst for planning a backup city for Tokyo

ITRBBC: A CONCEPT $180, 000 BEING REQUESTED FOR A FEASIBILITY STUDY TO START THE PROCESS

The plan, URBAN PLAN B, calls for construction of a NEW CITY to be called IRTBBC (Integrated Resort, Tourism, Business, and Backup City) or NEMIC (National Emergency Management International City) on the site currently occupied by the Osaka International Airport at Itami

OSAKA INTERNATIONAL AIRPORT

ITRBBC’s FUNCTIONS • ITRBBC would take on all the functions of Tokyo, the capital, in the event of a catastrophe.

ITRBBC’s CENTERPIECE • The centerpiece, a 650 m-hightower, would house 50, 000 residents and accommodate a work-day force of 200, 000 people from the Osaka region.

WHAT COULD BE THE NEXT EARTHQUAKE DISASTER FOR JAPAN • A difficult question, but -- • It is the question that was being asked long before the March 11, 2011 TOHOKU earthquake catastrophe.

TOKAI EARTHQUAKE • Before the March 11, 2011 Tohoku earthquake, the Government of Japan expected its next great earthquake to be “the Tokai Earthquake. ”

EARTHQUAKE SCENARIO TOKAI, JAPAN EARTHQUAKE ZONE AN IMPENDING DISASTER

PGA MAP: JAPAN (GSHAP)

TOKAI EARTHQUAKE TECTONICS • The Nankai trough marks the boundary where the Philippines tectonic plate is subducting beneath Japan (a part of the Eurasian plate).

TOKAI EARTHQUAKE TECTONICS • At present, the land near Shizuoka is sinking toward the Nankai trough at about 5 mm/yr. • Japan’s Earthquake Research Institute is on record that the Tokai earthquake is eminent.

TOKAI EARTHQUAKE • The precise area along the Pacific coast-- about 160 km (100 mi) southwest of Tokyo-- that is expected to be affected has been delineated by scientific studies, and, by law, is the focus of intensive preparations.

TOKAI EARTHQUAKE • Estimated deaths — between 7, 900 and 9, 200 depending on the amount of advance warning people have, the time of day when it occurs, and the tsunami, and Estimated property damage –- as much as $310 billion.

TOKAI EARTHQUAKE • Landslides -- 6, 449 specific locations • Structures susceptible to quake -related fires – 58, 402 specific houses

TOKAI EARTHQUAKE • The Government of Japan is currently deploying strain meters throughout the Tokai area to record the slip and then provide as much advance warning as possible.
