Domino 10 新功能介� 付季冬 | NotesDomino 技�支持�� November 21, 2018 Copyright © 2018 HCL

Domino V 10发布 � Domino V 10下载链接： https: //www. ibm. com/software/passportadvantage Copyright © 2018

Domino V 10系统需求 � IBM Domino V 10主要支持三种操作系统：Windows、Linux和AIX Copyright © 2018 HCL Technologies Limited

文档删除日志 � 当文档从一个数据库被删除时，信息条目会被加入到当前的IBM_TECHNICAL_SUPPORT路径下的删除日志中，类似如下文件: delete_<servername>_yyyy_mm_dd@hh_mm_ss. log 例如: delete_Server 1Acme_2018_12_15@06_28_45. log 7 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

文档删除日志 Deletion log中的信息包含以下内容： 8 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

文档删除日志 � 举例: 管理�想�服�器 mail路径下的用��箱�启用文档�除日志，并且希望包含如下的条目 : Send. To (recipient) From (sender) Posted. Date (date created) Delivered. Date (date delivered) $TITLE (title of a view or folder design document) � 命令如下: load compact mail -dl on "Send. To, From, Posted. Date, Delivered. Date, $TITLE" 9 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

文档删除日志 � 当有删除动作发生时，deletion log中会产生如下信息: delete_server 1. acme. com_2018_11_15@20_54_32. log "20181115 T 205926, 50+08", "mailadmin. nsf", "48258325: 0051 FC 53", "nserver", "CN=admin/O=acme", "SOFT", "0001", "765 CD 1 C 5: 10 C 1 E 41348258328: 002 D 4987", "Send. To", "20", "CN=admin/O=acme@acme", "From", "15", "CN=admin/O=acme", "Posted. Date", " 19", "2018/10/20 11: 27: 06", "Delivered. Date", "19", "2018/10/16 16: 14: 52” "20181115 T 205926, 50+08", "mailadmin. nsf", "48258325: 0051 FC 53", "nserver", "CN=admin/O=acme", "SOFT", "0001", "91371068: 5 F 3206 A 94825832 C: 0012 F 5 FA", "Send. To", "20", "CN=admin/O=acme@acme", "From", "15", "CN=admin/O=acme", "Posted. Date", " 19", "2018/10/20 11: 27: 06", "Delivered. Date", "19", "2018/10/20 11: 27: 06" 包含UNDO条目的�除日志信息如下 : 10/27/2018 07: 01: 23 PM, test 2. nsf, 85258235: 0055585 A, UNDO, HARD, A 1 B 532 C 2: FCC 5623965457228: 1680 D 2 BC � 如果想要禁用deletion logging: load compact <database path> -dl off 10 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

高使用视图的动态索引 � Domino提供show stat命令来监控高使用视图和索引更新状态： Copyright © 2018 HCL Technologies Limited | www. hcltech. com

数据库格式升级到ODS 53 � 希望每次Notes客户机都能升级到最新的ODS版本，则可在Desktop Setting中的Mail标签中的Client settings: ，启动“Enable upgrade of all loca NSFs to the latest ODS version: ”选项，如下图 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

q 邮件的新功能: 1. 邮件定时发送 2. 死信自��理 Copyright © 2018 HCL Technologies Limited | www.

邮件定时发送 � 服务器相关配置: Copyright © 2018 HCL Technologies Limited | www. hcltech. com

邮件定时发送 � 策略生效后，用户可以在Notes客户端发送邮件时， delivery option 中看到Delay delivery until 来选择一个日期和时间来发送邮件 Copyright © 2018 HCL Technologies

管理mail. box中的定时邮件 � 打开 mail. box: ▪ 可以看到�件的 Scheduled Time，如果打开消息，可以��定的投��行��。 Copyright © 2018 HCL

监控定时邮件 – tell router list �个命令会列出消息�列中的每一个消息，�在会包括 scheduled状�的消息： Mbx Note. ID ID State Size 1 00001466 006 A 6 C 68 Pending 765 2 000012 D 2 006 A 8 AB 3 Pending 765 3 00001002 006 A 8 F 3 F Pending 765 3 00001006 006 B 3 E 8 C Scheduled 926 1 0000146 E 006 B 584 A Scheduled 926 1 00001452 005 E 6 CC 3 DEAD 2292 1 0000145 A 005 E 75 A 7 DEAD 2292 3 00000 FE 6 005 E 6 B 15 DEAD 2292 2 000012 C 2 005 E 6 DDF DEAD 2292 3 00000 FFE 00651 D 48 DEAD 2292 -------------------Total messages Active: 10 Total messages Pending Delete: 0 Copyright © 2018 HCL Technologies Limited | www. hcltech. com Pri Count Scheduled. Date N 1 N 1 09/16/2018 03: 37: 00 PM N 1 09/16/2018 03: 40: 00 PM 1 1 1 From Admin Auto. Msg/Auto. Msg No. Such. Sender@dommsg. com

监控定时邮件 – tell router show � tell router show Msgs State Via 1 Wait. Scheduled Destination Waiting for scheduled send time. Transfer Threads: Max = 25; Total = 1; Inactive = 0; Max Concurrent = 12 Delivery Threads: Max = 25; Total = 0; Inactive = 0 Dispatch Threads: Max = 4; Total = 2; Inactive = 2 Sweep Threads: Max = 4; Total = 2; Inactive = 2 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

监控定时邮件 – statistics � show stat Mail. Waiting. For. Schedule Ø Mail. Waiting. For. Schedule = 4 Ø 1 statistics found � show stat mail. totalscheduledreleased Ø Mail. Total. Scheduled. Released = 2 Ø 1 statistics found � show stat mail. waiting. Not. Scheduled Ø Mail. Waiting. Not. Scheduled = 0 Ø 1 statistics found Copyright © 2018 HCL Technologies Limited | www. hcltech. com

死信自动处理 � 配置设置: Copyright © 2018 HCL Technologies Limited | www. hcltech. com

死信自动处理 – 配置样例 � 配置样例: � 路由/SMTP --- 高级 --- 控制 Copyright © 2018

死信自动处理 – 统计 � 监控死信的统计信息: > show stat mail. dead* Mail. Dead = 0 Mail. Dead. Deleted. Count = 4 Mail. Dead. Retry. Count = 11 3 statistics found Copyright © 2018 HCL Technologies Limited | www. hcltech. com

死信自动处理–Debug参数 � 还可以在notes. ini中设置参数Debug. Router. Dead. Mail=3来帮助诊断和显示更多的详细信息。 � Notes. ini Debug. Router. Dead. Mail=3 (lower levels 1, and 2 less useful, just logging unexpected errors) Original message goes dead: 09/13/2018 10: 11: 17 AM SMTP Server: Message 004 DF 039 (Message. ID: <OF 8073 C 6 A 4. CCF 584 D 1 -ON 85258277. 004 F 157 F 85258277. 224 F 3 ECE@dommsg. com>) received from (127. 0. 0. 1) size 941 bytes 09/13/2018 10: 11: 17 AM Router: Unable to deliver message 004 DF 039, 004 F 157 F to No. Such. Intended@dommsg. com from No. Such. Sender@dommsg. com OF 2 AF 2879 E: 8 C 7 E 51 DD ON 85258307: 004 DF 039 09/13/2018 10: 11: 17 AM User No. Such. Intended@dommsg. com not listed in Domino Directory 09/13/2018 10: 11: 17 AM Router: Message 004 DF 03 F from No. Such. Sender@dommsg. com state changing to DEAD. Reason: User No. Such. Sender (No. Such. Sender@dommsg. com) not listed in Domino Directory 09/13/2018 10: 11: 17 AM Router: Unable to deliver message 004 DF 03 F, 004 F 157 F to No. Such. Sender@dommsg. com from No. Such. Sender@dommsg. com OF 9826 AC 3 A: FCAAE 126 ON 85258307: 004 DF 03 F 09/13/2018 10: 11: 17 AM Copyright © 2018 HCL Technologies Limited | www. hcltech. com User No. Such. Sender@dommsg. com not listed in Domino Directory

q 群集的新功能: 群集中数据库自动修复 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

修复用于维护指定目录的对称(symmetry) � 群集中任何服务器上的任何Notes数据库都确保存在于所有的服务器上 ▪ Domino服�器会�所有缺失的数据�自�恢复 Server A Server B Server C mail 1 | mail 2 | mail 3 | mail 4 REPAIR LIST MISSING Symmetric clusters enable several enhanced capabilities to improve resiliency…. Copyright © 2018 HCL Technologies Limited | www. hcltech. com Required files A∪ B∪C

如何启用修复功能 � 在Domino 10的群集中“所有”服务器的notes. ini中加入参数D 10_ENABLE_REPAIR=1 � Domino服务器“必须”加入到群集中 � 在names地址本中创建“cluster configuration” 文档 (需要是最新的Domino 10的模板) Copyright © 2018 HCL Technologies Limited | www. hcltech. com

选择需要配置修复功能的群集 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

Symmetry页签, 选择需要保持同步的目录 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

选择修复功能的具体动作 � 每 15分钟查找一次missing files，然后在缺少这些数据库的服务器上进行修复 � 必须将Auto. Repair加入到服务器notes. ini中的server. Task 列表中 ▪ Auto. Repair 用来�找 missing files Copyright © 2018 HCL Technologies Limited | www. hcltech. com

如何知道哪些文件是需要修复的？ � 唯一由cldbdir. nsf 确定 ▪ Cldbdir 任� 必�运行 ▪ Cldbdir. nsf 必�

Repair list files 和 Repair list missing � 查看服务器监控的文件修复列表: � 列出服务器缺失的文件： Copyright © 2018

损坏数据库修复 � damaged 损坏的数据库，而不是missing 丢失的数据库 � 启用: Copyright © 2018 HCL Technologies Limited |

数据库损坏指的是数据库无法被正常打开 � 打开数据库时会出现如下的报错，而且无法通过fixup进行修复: • File is not a database • Database is corrupt -- Cannot allocate space • Database is damaged and can't be repaired (UNID index) • Database is damaged and can't be repaired (RRV buckets bad) • The Notes database file header is corrupted • Database is damaged and can't be repaired (BDB) • RRV bucket is corrupt. • Allocation bitmap is corrupt. • Non-bucketized response object is corrupt, perhaps partially written • Non-bucketized nonsummary data is corrupt, perhaps partially written • Access control list is corrupted • Invalid PNO vector - position == 0 • File truncated - file may have been damaged Copyright © 2018 HCL Technologies Limited | www. hcltech. com These files cannot be corrected by Fixup, so Repair to the rescue!

Repair – 控制台指令列表 REPAIR LIST SERVERS FILES MISSING ENABLED DISABLED FILE <dbname> ALL REPLHIST <dbname> ENABLE <dbname> DISABLE <dbname> SHOW CONFIG JOBS Copyright © 2018 HCL Technologies Limited | www. hcltech. com Cluster Repair commands List available donor servers List all files being monitored for repair. List all missing databases List all files being monitored for repair. List all monitored files where repair is disabled. Repair a single database Repair all missing databases List histories for database - options [-all | -clear ] Enable Repair for all replicas of a single database Displays the current configuration settings for repair engine. Displays the jobs currently awaiting repair.

q 安全方面的改进: 1. ID vault的改进 2. SAML及其他的改� Copyright © 2018 HCL Technologies Limited |

IDVault 可用性 � Qvault 具也可以针对一个指定用户进行更新，运行: “load qvault –x <vaultname> -u <username>” � 也可以通过admin管理客户端中更新某个用户的保险库的信息: 57

IDVault 可用性 � Qvault 具启用参数： IDV_ENABLE_VAULT_SCAN=1 ▪ 可以�置 IDV_ENABLE_VAULT_SCAN=0 来禁用�个功能（缺省） � Qvault 具调试参数：DEBUG_IDV_QVAULT=1

SAML及其他改进 � Domino 10支持更多的IDP种类: ▪ 之前的Domino 支持 ADFS 2. 0/3. 0，V 10开始完全支持 ADFS 4. 0 ▪ Domino 10 可以和任何 SAML 2. 0 兼容的IDP一同作 � SAML 配置过程简化: ▪ 很多配置�可以从 IDP Federation metadata自� 生成: - Protocol version, Federation Product, IDP URL, Encryption and Signing certificates ▪ 一些�置会在�入后自�校�，以避免之后的更多�� 在服务器文档中设置TLS 1. 2 加密算法 59 Copyright © 2018 HCL Technologies Limited | www. hcltech. com

q 服务器管理的改进: �布 Domino的��信息到�控系� Copyright © 2018 HCL Technologies Limited | www. hcltech. com

Domino 统计发布 � Domino的统计是通过一个New Relic的插件Domino. Stats来报告的，统计每分钟发布一次，数据保留 24小时。 � 配置过程： -1. 在New Relic官网注册一个账号：www. newrelic. com. -2. 登录账号 -3. 右上方选择账号设置：Account Settings. Copyright © 2018 HCL Technologies Limited | www. hcltech. com

Domino 统计发布 -4. 找到并拷贝License key -5. 在domino服务器上，将如下的参数加入到Notes. ini配置文件中： NEWRELIC_LICENSE_KEY=<key> NEWRELIC_LICENSE_KEY=6451 bc 8 c 7 a 4 fa 455 c 8475 dc 75 e 81 c 27 f 58 xxxxxx Copyright © 2018 HCL Technologies Limited | www. hcltech. com

Domino 统计发布 -6. 等待初始数据发布后，在New Relic网站，点击PLUGINS: -7. 选择Domino. Stats: Copyright © 2018 HCL Technologies Limited

定制发布的统计信息 � 另外，Domino也支持将统计发布到除了New Relic之外的其它服务来进行监控： � 下面是几种经过测试的HTTP API: -New Relic: https: //docs. newrelic. com/docs/plugin-developer-resources/developer-reference/work-directly-plugin-api -Hosted Graphite: https: //www. hostedgraphite. com/docs/index. html#sending-metrics-to-hosted-graphite -Datadog: https: //docs. datadoghq. com/api/? lang=bash#post-timeseries-points -Influx. DB: https: //www. docs. influxdata. com/influxdb/v 1. 6/guides/writing_data/ Copyright © 2018 HCL Technologies Limited | www. hcltech. com

参考资料: � Domino V 10下载链接： https: //www. ibm. com/software/passportadvantage/ � Domino 10. 0 产品手册: https: //www. ibm. com/support/knowledgecenter/zh/SSKTMJ_10. 0. 0/welcome/domino_welcome. html � IBM Domino 10. 0 系统需求： http: //www 01. ibm. com/support/docview. wss? mhq=Domino%20 system%20 requirements&mhsrc=ibmsearch_a&uid=ibm 1073 3629 Copyright © 2018 HCL Technologies Limited | www. hcltech. com
