doc. : 15 -18 -0313 -03 -0013 May 2018 IEEE 802. 15 TG 13 Multi-Gbit/s Optical Wireless Communication July 2018 Meeting Slides Date: 2018 -07 -8 Author: Submission Slide 1 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Abstract This presentation contains the IEEE 802. 15 TG 13 Multi. Gbit/s Optical Wireless Communication meeting slides for the July 2018 session in San Diego, CA. Submission Slide 2 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Call for Potentially Essential Patents • If anyone in this meeting is personally aware of the holder of any patent claims that are potentially essential to implementation of the proposed standard(s) under consideration by this group and that are not already the subject of an Accepted Letter of Assurance: – Either speak up now or – Provide the chair of this group with the identity of the holder(s) of any and all such claims as soon as possible or – Cause an LOA to be submitted Submission Slide 3 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Logistics • Attendance recording procedures – – https: //imat. ieee. org/my-site/home Login using your IEEE account also used for registration Must log attendance during each 2 -hour session Attendance counts to achieving/maintaining your voting rights • Documentation – http: //mentor. ieee. org – Use “TG 13” for submission – If you plan to make a submission be sure it does not contain company logos or advertising Submission Slide 4 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Logistics (2) Position(s) Officer(s) Chair Volker Jungnickel Vice Chairs Nikola Serafimovski, Sang-Kyu Lim, Xu Wang Secretary Nikola Serafimovski, Li Qiang (John), Tuncer Baykas TG Technical Editor Li Qiang (John) From 802. 15 Operations Manual Task Group Chair • The TG Chair shall be appointed by the WG Chair and confirmed by a TG majority approval. The TG Chair is required to confirm that the function of secretary is performed for each TG meeting. Task Group Vice-Chair • TG Vice-Chair (an optional position) is appointed by the TG Chair and confirmed by a TG majority. Task Group Secretary • The TG Secretary shall be appointed by the TG Chair, who may also act as Secretary. TG meetings are not allowed to function without a secretary. The minutes of meetings taken by the TG Secretary (or designee) are to be provided to the TG Chair in time to be available to the WG Chair for publication, i. e. within 30 days after the close of the session. Task Group Technical Editor • The TG Technical Editor shall be appointed by the TG Chair and confirmed by a TG majority approval. Submission Slide 5 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Task Group Operating Rules • Anybody can present and contribute to discussions • WG members with voting right can vote and make motions • Participation during Plenary or Interim counts towards voting rights: Please, record your attendance! • See recent IEEE 802. 15 Operations Manual for all rules https: //mentor. ieee. org/802. 15/dcn/10/15 -10 -0235 -18 -0000 -802 -15 operations-manual. docx Submission Slide 6 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 schedule in San Diego AM 1 MON TUE WED THU TGbb #1 TG 13 #1 TGbb #3 TGbb #4 AM 2 TG 13 #2 PM 1 TG 13 #3 TG 13 #4 TG 13 #7 PM 2 TGbb #2 TG 13 #5 TG 13 #8 Submission Slide 7 TG 13 #6 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 activities this week • • • Review and discuss outcome of several phone calls Finalize PM PHY text in doc. 0003/r 7 – results on 48 -bit PM PHY synch preamble doc. 0288/r 0 (HHI, ETRI) – resolve comments/make changes in doc. 0003/r 7 (HHI, ETRI, vlncom) – validation of PM PHY up to 200 MHz bandwidth doc. 0172/r 4 (HHI) Present and discuss LB PHY – present text version of 0267/r 2 (t. b. d. ) Present and discuss HB PHY – present text proposal for High Bandwidth PHY in 0273/r 0 Resolve all comments against D 2 – Combined comments in doc. 0088/r 3 – Prepare D 3 and collect and next steps/telcos needed for D 4 Discuss TG 13 MAC – Text on MAC doc. 270/r 3 (pure. Li. Fi) – Organizing MAC frame formats in 802. 15. 13 doc. 579/r 2 Submission Slide 8 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #1 Tuesday AM 1, July 10, 2018 Item Time MEETING CALLED TO ORDER 3 Welcome, Who is Who 10 Check attendance / patent policy 5 Review and approve last meeting minutes 0216/r 0 10 Review and approve phone call minutes 0276/r 0, 0277/r 1, 0278/r 1, 0312/r 1 30 Discussion and approval of new agenda in 0313/r 1 10 Results on 48 -bit PM PHY synch preamble doc. 0288/r 0 (HHI, ETRI) 50 Recess 2 Submission Slide 9 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 Motion #14 The PM PHY will use the preamble structure with 48 samples and 6 repetitions for the basic modes. Moved by Volker Seconded by Chong 2/0/0 Submission Slide 10 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #2 Tuesday AM 2, July 10, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Validation of PM PHY up to 200 MHz bandwidth doc. 0172/r 4 (HHI) 40 Present and discuss text proposal for LB PHY 0267/r 2 60 Recess 2 Submission Slide 11 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #3 Tuesday PM 1, July 10, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Present and discuss text proposal for HB PHY in 0273/r 0 110 Recess 2 Submission Slide 12 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #4 Wednesday PM 1, July 11, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Review and update Agenda in 15 -18 -0313 -03 10 Finalize HB PHY presentation 30 Motion to include PHYs into D 3 10 Recess 2 Submission Slide 13 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 Motion #15 The Technical Editor shall make necessary arrangements to update PM PHY (docs. 15 -18/0003 r 8), LB PHY (1518/0267 r 4) texts and add them to D 3. Moved by Nikola Seconded by John 5/0/0 Submission Slide 14 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Call for evaluation results TG 13 calls for further performance evaluation results for Synch, Header and Payload. Follow the evaluation framework of TG 13 and use the comprehensive scheme introduced in 0190/r 0 over the agreed-upon channel models. Upload any results before the Kona meeting. Submission Slide 15 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 Evaluation framework 1) Preamble • Detection probability (for false alarm rate = 0. 1%) vs. SNR (cf. doc. 15 -180106/r 0) and required SNR where prob. of misdetection (timing error) <0. 1% 2) Header • BER vs. SNR for the header incl. 8 B 10 B and RS(36, 24) coding assuming random data for the header information 3) Payload • BER vs. SNR for the payload incl. 8 B 10 B or HCM and RS(255, 248) coding assuming random data for the payload Results are expected for AWGN, D 3 in scenario 3 and D 7 in scenario 4 (Fig. 25) where LED 1 -6 are used together from https: //mentor. ieee. org/802. 15/dcn/15/15 -15 -0746 -01 -007 a-tg 7 r 1 -channel-model-document-for-high-rate-pdcommunications. pdf. CIRs: https: //mentor. ieee. org/802. 15/dcn/15/15 -15 -0747 -00007 a-tg 7 r 1 -cirs-channel-model-document-for-high-rate-pd-communications. zip a companion file In case of questions, use TG 13 email reflector. Submission Slide 16 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #5 Wednesday, PM 2, July 11, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Call for further evaluation results 5 Comment resolution against D 2 30 Recess 2 Submission Slide 17 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #6 Thursday AM 2, July 12, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Finish comment resolution 40 Writing style for TG 13 MAC procedures 30 Text proposal for general MAC format doc. 15 -18/0270 r 4 30 Discussion on the timeline 20 Recess 2 Submission Slide 18 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 Motion #16 Motion to approve 60 technical comments as resolved in doc. 0088/r 5 and update TG 13 draft accordingly. The technical Editor is granted the right to work in editorial comments. D 3 will be made available until August 18. Moved by John Seconded by Nikola 7/0/0 Comments against D 3 are due before Sept. 2. Submission Slide 19 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Call for Proposals on TG 13 MAC TG 13 requests proposals for MAC, in the agreed-upon writing style • Doc. XXXX/r. Y Proposals shall be submitted until September 2 and will be discussed at the next two meetings in San Diego and Kona. Proposals can be submitted as slides or text being accompanied by a slide set. Submission Slide 20 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #7 Thursday PM 1, July 12, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Tentative Agenda for September meeting in Kona 10 Recess 2 Submission Slide 21 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 Meeting Slot #8 Thursday PM 2, July 12, 2018 Item Time MEETING CALLED TO ORDER 3 Check attendance / patent policy 5 Any other business 10 Adjourn 2 Submission Slide 22 Volker Jungnickel (Fraunhofer HHI)

doc. : 15 -18 -0313 -03 -0013 May 2018 TG 13 Plans for September • • Finalize LB PHY and HB PHY evaluation and text Discuss incoming MAC proposals and TBDs Resolve comments against D 3 Prepare D 4 for WG Letter Ballot Submission Slide 23 Volker Jungnickel (Fraunhofer HHI)
