DK-128 메인보드 – 연산, 제어 Serial port 확장보드 - 입출력 Parallel port high low

DK-128 메인보드 – 연산, 제어 Serial port 확장보드 - 입출력 Parallel port high low FND low high LED ATmega 4 K EEPROM & Sensor Tact Switch EEPROM Power 1: TWI clock, 2: TWI data, 상위5~8: Infrared sensor

DK-128의 결선 8 line 1 j 19 1 + red black 2 j 15

DK-128의 결선 8 line 1 j 19 1 + red black 2 j 15 61 25 1 1 j 18 j 16 54 35 + 42 8 line

ATmega 128 USART �Full Duplex 동작 �직렬 송수신 버퍼가 독립적 �비 동기(Asynchronous)와 동기 모두

ATmega 128 USART �Full Duplex 동작 �직렬 송수신 버퍼가 독립적 �비 동기(Asynchronous)와 동기 모두 동작 �두 개의 USART를 제공 – USART 0, USART 1 �DK 128은 USART 1만 사용하도록 제작됨 �UDR 1 (USART 1 I/O Data Register) �UCSR 1 A (USART Control and Status Register A) �UCSR 1 B (USART Control and Status Register B) �UCSR 1 C (USART Control and Status Register C) �UBRR 1 H/L (USART Baud Rate Registers)
