Diseo Sistema con Micros Enphase IQ 6 PLUS

Diseño Sistema con Micros Enphase IQ 6 PLUS Instructor Enphase

Dimensionamiento Sistema

Ilustración Medición Neta Producción solar Demanda hogar Exportado Contador medición neta Consumo Medición neta factura consumo - exportado 3 | © 2017 Enphase Energy, Inc. Learning and Development |

Micros IQ 6 versus IQ 6 PLUS Especificaciones de Operación Para diseño de circuitos y protección Para capacidad de potencia 4 Micro IQ 6 PLUS Compatibilidad Módulo 60 celdas 60 y 72 celdas Potencia de módulos comúnmente pareados 195 – 300 W + STC 235 – 400 W + STC 230 VA. 96 A a 240 V 280 VA 1. 17 A a 240 VA 290 VA 16 - 48 V 16 - 62 V Potencia de salida continua máxima Potencia de salida pico Rango de voltaje de entrada CC | © 2017 Enphase Energy, Inc. Learning and Development |

Tamaño Apropiado del Módulo a Parear 5 • Razón potencia óptima CC/CA (DC/AC) • Mayor es mejor! • El mejor pareo módulo/inversor es dependiente de las condiciones especificas de cada sistema | © 2017 Enphase Energy, Inc. Learning and Development |

Dimensionando circuito 240/120 Vca monofásico trifilar

El circuito base Enphase Cable Q L 1 -Negro L 2 -Rojo AGREGADOR Q O CAJA EMPALME Circuito Base: 2#12 AWG Cu – Cable Q Enphase TERMINADOR Q INSTALADO AL FINAL DEL CABLE HASTA 16 MICROS IQ 6 ó 13 MICROS IQ 6 PLUS Cuál es el tamaño del disyuntor (breaker) si el Cable Q es #12 AWG Cu? 7 | © 2017 Enphase Energy, Inc. Learning and Development |

El circuito de 20 A es la base de diseño Enphase Cable Q L 1 -Negro L 2 -Rojo AGREGADOR Q O CAJA EMPALME Circuito Base: 2#12 AWG Cu – Cable Q Enphase TERMINADOR Q INSTALADO AL FINAL DEL CABLE HASTA 16 MICROS IQ 6 ó 13 MICROS IQ 6 PLUS Breaker 2 P 20 A 8 | © 2017 Enphase Energy, Inc. Learning and Development |

Pregunta. . . Cuál es el máximo número de micros que se puede poner en un circuito de 20 amperes? 9 | © 2017 Enphase Energy, Inc. Learning and Development |

Cantidad de micros en circuito de 20 A @ 240 V monofásico trifilar Cómputo de corriente por micro • Potencia máxima continua de salida del micro ÷ 240 V = Amperes/micro Cómputo de ampacidad de un circuito de salida de un inversor solar • Amperes/micro * 1. 25 = Ampacidad / micro Cantidad máxima de micros en circuito de 20 A @ 240 V • 20 A ÷ ampacidad/micro Calcular la cantidad máxima de micros IQ por circuito para: • Potencia max continua de salida del IQ 6: 230 VA • Potencia max continua de salida del IQ 6 PLUS: 280 VA 10 | © 2017 Enphase Energy, Inc. Learning and Development |

Cantidad de máxima de micros IQ 6 en circuito de 20 A @ 240 V monofásico trifilar Circuit Current Calculations • Maximum continuous output power = 230 VA • 230 VA ÷ 240 V = . 96 A / micro Over-Current Calculations • 20 A circuit *. 8 A over-current = 16 A Maximum Branch Circuit Size • 16 A ÷. 96 A = 16 micros Conclusión: • Se puede instalar un máximo de 16 micros (3, 680 VA) por circuito monofásico trifilar de 20 A a 240 V 11 | © 2017 Enphase Energy, Inc. Learning and Development |

Pregunta… 1. Para un sistema de 5 k. VA, cuál es la cantidad mínima de circuitos necesarios si lo construimos utilizando el Micro IQ 6? 2. Se puede usar más de un circuito? 12 | © 2017 Enphase Energy, Inc. Learning and Development |

Máxima Cantidad de Micros IQ por Circuito 20 A @ 240 V Monofásico Trifilar 13 IQ 6 PLUS Compatibilidad Módulo 60 celdas 60 y 72 celdas Potencia de módulos comúnmente pareados 195 – 300 W + STC 235 – 400 W + STC Potencia de salida continua máxima 230 VA. 96 A a 240 V 280 VA 1. 17 A a 240 V Voltaje CA nominal y rango 240 V 211 -264 V Cantidad Máxima de Micros 16 13 | © 2017 Enphase Energy, Inc. Learning and Development |

Subida de Voltaje

Pregunta. . . Qué es subida (caída) de voltaje? • Al diseñar circuitos eléctricos, comúnmente calculamos la caída de voltaje (Vdrop) para mantener la calidad de voltaje y reducir la pérdida de energía en los cables. • Como los sistemas fotovoltaicos de inversor interconectado a la red son generadores de corriente que toman su referencia de voltaje del punto de conexión, el voltaje tiende a subir en el generador según la corriente viaja hacia el punto de conexión. Por esta razón este adiestramiento tratará el tema de la Subida de Voltaje (Vrise). 15 | © 2017 Enphase Energy, Inc. Learning and Development |

Entendiendo la Subida de Voltaje (Vrise) La resistencia de los cables hará que el voltaje en el micro aumente cuando la corriente viaja hacia el punto de conexión. Vrise Alimentador Agregador Q Cable Q Vrise <= 2% 16 | © 2017 Enphase Energy, Inc. Learning and Development |

Entendiendo la Subida de Voltaje (Vrise) • • Sistema de 10 módulos fotovoltaicos con micros IQ 6 montados en orientación vertical (portrait) Alimentador 25 pies en #10 AWG CU del punto de conexión al Agregador Q Cable Q 25 pies, #10 AWG CU Vrise <= 2% 17 | © 2017 Enphase Energy, Inc. Learning and Development |

Subida de Voltaje en el Cable Q 18 | © 2017 Enphase Energy, Inc. Learning and Development |

Subida de Voltaje (Vrise) en Cable Q Para diez (10) micros IQ 6 montados en orientación vertical (portrait) Micros IQ 6 por circuito (Módulo Vertical (Portrait)), 240 V 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Vrise (V) 0. 02 0. 05 0. 10 0. 16 0. 24 0. 34 0. 45 0. 58 0. 73 0. 89 1. 07 1. 26 1. 47 1. 70 1. 94 2. 20 Vrise (%) 0. 01 0. 02 0. 04 0. 07 0. 10 0. 14 0. 19 0. 24 0. 30 0. 37 0. 45 0. 53 0. 61 0. 71 0. 81 0. 92 Corriente(A) 0. 96 1. 92 2. 88 3. 83 4. 79 5. 75 6. 71 7. 67 8. 63 9. 58 10. 54 11. 50 12. 46 13. 42 14. 38 15. 33 Micros IQ 6 por Circuito (Módulo Horizontal (landscape) 60 celdas), 240 V 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Vrise (V) 0. 02 0. 07 0. 15 0. 25 0. 37 0. 52 0. 70 0. 90 1. 12 1. 37 1. 64 1. 94 2. 27 2. 61 2. 99 3. 39 Vrise (%) 0. 01 0. 03 0. 06 0. 10 0. 16 0. 22 0. 29 0. 37 0. 47 0. 57 0. 68 0. 81 0. 94 1. 09 1. 25 1. 41 Corriente(A) 0. 96 1. 92 2. 88 3. 83 4. 79 5. 75 6. 71 7. 67 8. 63 9. 58 10. 54 11. 50 12. 46 13. 42 14. 38 15. 33 19 | © 2017 Enphase Energy, Inc. Learning and Development |

Subida de Voltaje (Vrise) en Cable Q . 37% Vrise 20 | © 2017 Enphase Energy, Inc. Learning and Development |

Entendiendo la Subida de Voltaje (Vrise) 25 pies en #10 AWG CU Cuánto Vrise aquí? Cable Q. 37% Vrise <= 2% 21 | © 2017 Enphase Energy, Inc. Learning and Development |

Calculating for Upstream Voltage Rises Or - use any voltage drop calculator available on the web . 25% 22 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise not to exceed 2% Q Cable. 37%. 25% 23 | © 2017 Enphase Energy, Inc. Learning and Development |

Adding Up the Voltage rises 1) Internal Vrise for Q Cable=. 37% 2) 25 foot run w/ 10 AWG between Q Aggregator and load center =. 25% 3) Total =. 62% Questions: Is this OK? 24 | © 2017 Enphase Energy, Inc. Learning and Development |

Caso 1: Calcular Subida de Voltaje tota con el IQ 6 PLUS • (10) IQ 6+ branch circuit proposed in landscape with 72 cell modules • 25 -foot run w/ 10 AWG between Q Aggregator and load center Questions: 1. What is the total voltage rise percentage? 2. Will this be within the 2%? 25 | © 2017 Enphase Energy, Inc. Learning and Development |

Calculating for Q Cable Voltage Rise For (10) IQ 6+ Micros mounted in landscape orientation Vrise (V) Vrise (%) Current (A) 26 IQ 6+ Micros per Branch (Portrait) 3 4 5 6 7 8 9 10 11 12 13 0. 12 0. 20 0. 30 0. 41 0. 55 0. 71 0. 89 1. 08 1. 30 1. 54 1. 79 0. 05 0. 08 0. 12 0. 17 0. 23 0. 30 0. 37 0. 45 0. 54 0. 64 0. 75 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 02 0. 01 1. 17 2 0. 06 0. 02 2. 33 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 60 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 09 0. 18 0. 30 0. 45 0. 64 0. 85 1. 09 1. 36 1. 67 2. 00 2. 36 2. 76 0. 04 0. 08 0. 13 0. 19 0. 27 0. 35 0. 45 0. 57 0. 69 0. 83 0. 99 1. 15 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 72 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 10 0. 21 0. 35 0. 52 0. 73 0. 98 1. 26 1. 57 1. 92 2. 30 2. 72 3. 17 0. 04 0. 09 0. 15 0. 22 0. 31 0. 41 0. 52 0. 65 0. 80 0. 96 1. 13 1. 32 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 | © 2017 Enphase Energy, Inc. Learning and Development |

Calculating for Upstream Voltage Rises Or - use any voltage drop calculator available on the web . 30% 27 | © 2017 Enphase Energy, Inc. Learning and Development |

Adding Up the Voltage Drops 1) Internal Vdrop for Q Cable=. 80% 2) 25 foot run w/ 10 AWG between Q Aggregator and load center =. 30% 3) Total = 1. 10 % Questions: Is this OK? 28 | © 2017 Enphase Energy, Inc. Learning and Development |

Example 2 - Calculate Voltage Rise • Three fully-loaded (13) IQ 6+ branch with 60 cell modules in portrait • 75 ft runs w/ 10 AWG from j-boxes to IQ Combiner 40 -foot run w/ 6 AWG between AC Combiner and PCC • Questions: 1. What is the total Voltage Drop Percentage? 2. Will this be OK? 29 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise 75 ft w/ 10 AWG not to exceed 2% 39 micros IQ 6 PLUS 40 ft w/ 6 AWG 30 | © 2017 Enphase Energy, Inc. Learning and Development | 13 micros IQ 6 PLUS 1

Calculating for Q Cable Voltage Rise For (13) IQ 6+ Micros mounted in portrait orientation Vrise (V) Vrise (%) Current (A) 31 IQ 6+ Micros per Branch (Portrait) 3 4 5 6 7 8 9 10 11 12 13 0. 12 0. 20 0. 30 0. 41 0. 55 0. 71 0. 89 1. 08 1. 30 1. 54 1. 79 0. 05 0. 08 0. 12 0. 17 0. 23 0. 30 0. 37 0. 45 0. 54 0. 64 0. 75 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 02 0. 01 1. 17 2 0. 06 0. 02 2. 33 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 60 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 09 0. 18 0. 30 0. 45 0. 64 0. 85 1. 09 1. 36 1. 67 2. 00 2. 36 2. 76 0. 04 0. 08 0. 13 0. 19 0. 27 0. 35 0. 45 0. 57 0. 69 0. 83 0. 99 1. 15 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 72 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 10 0. 21 0. 35 0. 52 0. 73 0. 98 1. 26 1. 57 1. 92 2. 30 2. 72 3. 17 0. 04 0. 09 0. 15 0. 22 0. 31 0. 41 0. 52 0. 65 0. 80 0. 96 1. 13 1. 32 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise not to exceed 1 2 75 ft w/ 10 AWG . 75% I=15. 17 A Ix 1. 25=19. 0 A 2% . 75% 40 ft w/ 6 AWG. 75% 32 | © 2017 Enphase Energy, Inc. Learning and Development | 39 IQ 6+ Micros

Calculate for Junction Box to Load Center 1. 1 % 33 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise 2 75 ft w/ 10 AWG 1. 1% not to exceed . 75% 2% . 75% 40 ft w/ 6 AWG 3 . 75% I=45. 5 A Ix 1. 25=56. 9 A 34 | © 2017 Enphase Energy, Inc. Learning and Development | 39 IQ 6+ Micros

Ecuación de caída de voltaje Vn: 240 Vac, 1 PH VR% = (I x 2 x L x R )/ Vn x 100 I= current L=distance R= ohms/distance Vn=nominal voltage . 74 % VR% = (45. 5 A x 2 x 40’ x 0. 00049 ohm/pie )/ 240 V x 100 = 0. 743% 35 | © 2017 Enphase Energy, Inc. Learning and Development |

Adding Up the Voltage Rises 1) Internal Vrise for Q Cable =. 75% 2) 75 -foot run w/ 10 AWG between Q Aggregator and load center = 1. 1% 3) 40 -foot run w/ 6 AWG between load center and PCC =. 74% 4) Total = 2. 59% Questions: 1. What is the total voltage rise percentage? 2. Will this be ok? 36 | © 2017 Enphase Energy, Inc. Learning and Development |

Question. . What happens if the rise is too much? 37 | © 2017 Enphase Energy, Inc. Learning and Development |

How Can I Reduce My Vrise? Total = 2. 59% Different ways to design for lower Vrise 1. Larger gauge wire 2. Reduce branch circuit size 3. “Center Feed” – “split” branches 38 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise not to exceed 75 ft w/ 10 AWG 1. 1 % 2% 40 ft w/ 6 AWG. 74% Best Practice Alert – Enphase recommends that you always design with centerfed branch circuits 39 | © 2017 Enphase Energy, Inc. Learning and Development |

Calculating for Q Cable Voltage Rise For (10) IQ 6+ Micros mounted in portrait orientation Vrise (V) Vrise (%) Current (A) 40 IQ 6+ Micros per Branch (Portrait) 3 4 5 6 7 8 9 10 11 12 13 0. 12 0. 20 0. 30 0. 41 0. 55 0. 71 0. 89 1. 08 1. 30 1. 54 1. 79 0. 05 0. 08 0. 12 0. 17 0. 23 0. 30 0. 37 0. 45 0. 54 0. 64 0. 75 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 02 0. 01 1. 17 2 0. 06 0. 02 2. 33 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 60 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 09 0. 18 0. 30 0. 45 0. 64 0. 85 1. 09 1. 36 1. 67 2. 00 2. 36 2. 76 0. 04 0. 08 0. 13 0. 19 0. 27 0. 35 0. 45 0. 57 0. 69 0. 83 0. 99 1. 15 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 72 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 10 0. 21 0. 35 0. 52 0. 73 0. 98 1. 26 1. 57 1. 92 2. 30 2. 72 3. 17 0. 04 0. 09 0. 15 0. 22 0. 31 0. 41 0. 52 0. 65 0. 80 0. 96 1. 13 1. 32 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise not to exceed 75 ft w/ 10 AWG 1. 1 %. 23% 2% 40 ft w/ 6 AWG. 74% Best Practice Alert – Enphase recommends that you always design with centerfed branch circuits 41 | © 2017 Enphase Energy, Inc. Learning and Development |

Adding Up the Voltage Rises 1) Internal Vrise for Q Cable =. 23% 2) 40 -foot run w/ 10 AWG between Q Aggregator and load center = 1. 1% 3) 80 -foot run w/ 8 AWG between load center and PCC =. 74% 4) Total = 2. 07% Questions: 1. What is the total voltage rise percentage? 2. Will this be ok? 42 | © 2017 Enphase Energy, Inc. Learning and Development |

Caso 2. Subida de Voltaje con el Agregador Q Total of all voltage rise not to exceed 2 75 ft w/ 6 AWG 45. 5 A 2% 1. 23% 40 ft w/ 6 AWG 3 43 | © 2017 Enphase Energy, Inc. Learning and Development | 39 IQ 6+ Micros

Calculating for Q Cable Voltage Rise For (10) IQ 6+ Micros mounted in portrait orientation Vrise (V) Vrise (%) Current (A) 44 IQ 6+ Micros per Branch (Portrait) 3 4 5 6 7 8 9 10 11 12 13 0. 12 0. 20 0. 30 0. 41 0. 55 0. 71 0. 89 1. 08 1. 30 1. 54 1. 79 0. 05 0. 08 0. 12 0. 17 0. 23 0. 30 0. 37 0. 45 0. 54 0. 64 0. 75 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 02 0. 01 1. 17 2 0. 06 0. 02 2. 33 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 60 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 09 0. 18 0. 30 0. 45 0. 64 0. 85 1. 09 1. 36 1. 67 2. 00 2. 36 2. 76 0. 04 0. 08 0. 13 0. 19 0. 27 0. 35 0. 45 0. 57 0. 69 0. 83 0. 99 1. 15 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 1 0. 03 0. 01 1. 17 IQ 6+ Micros per Branch (Landscape 72 -cell) 2 3 4 5 6 7 8 9 10 11 12 13 0. 10 0. 21 0. 35 0. 52 0. 73 0. 98 1. 26 1. 57 1. 92 2. 30 2. 72 3. 17 0. 04 0. 09 0. 15 0. 22 0. 31 0. 41 0. 52 0. 65 0. 80 0. 96 1. 13 1. 32 2. 33 3. 50 4. 67 5. 83 7. 00 8. 17 9. 33 10. 50 11. 67 12. 83 14. 00 15. 17 | © 2017 Enphase Energy, Inc. Learning and Development |

Understanding Voltage Rise Total of all voltage rise not to exceed 2% 75 ft w/ 6 AWG 1. 4% 45. 5 A . 23% 40 ft w/ 6 AWG. 74% 45 | © 2017 Enphase Energy, Inc. Learning and Development | 39 IQ 6+ Micros

Adding Up the Voltage Rises 1) Internal Vrise for Q Cable =. 23% 2) 40 -foot run w/ 10 AWG between Q Aggregator and load center = 1. 4 % 3) 80 -foot run w/ 8 AWG between load center and PCC =. 74% 4) Total = 2. 37% Questions: 1. What is the total voltage rise percentage? 2. Will this be ok? 3. Qué habría que hacer para reducer la subida de voltaje? 46 | © 2017 Enphase Energy, Inc. Learning and Development |

Prueba Corta

Learning Check What is the maximum number of IQ 6, IQ 6+ Micros you can put on a 240 V single phase circuit? a) 16 and 17 respectively b) 16 inverters for both c) 16 and 13 respectively d) 17 inverters for both 48 | © 2017 Enphase Energy, Inc. Learning and Development |

Learning Check To ensure you design circuits to avoid AC voltage high problems, you must … a) Calculate for total ampacity of all micros and ensure it does not exceed 20 Amps per circuit b) Ensure that total voltage of the circuit does not exceed 264 VAC c) Ensure that voltage rise percentage of the wiring to the utility pole is no more than 2% d) Ensure that voltage rise percentage of the circuit wire does not exceed more than 2% 49 | © 2017 Enphase Energy, Inc. Learning and Development |

Learning Check Is it ok to install a 15 A breaker instead of a 20 A breaker? a) No, nunca b) Yes, but you will have to limit the number of micros per circuit c) Yes but the conductors from the micros to main panel have to be sized down to match the 15 Amp limit d) Yes, when the Q Cable supports a larger 10 AWG wire 50 | © 2017 Enphase Energy, Inc. Learning and Development |

Conclusion Diseñar un sistema Enphase envuelve: 51 • Calcular la cantidad de micros necesarios para entregar la energía necesaria • Planifique la cantidad de micros por circuito (No exceda el máximo) • Calcule la subida de voltaje para cada circuito. Diseñe para una caida menor de 2% desde el punto de conexión hasta ultimo micro del circuito. | © 2017 Enphase Energy, Inc. Learning and Development |

Recursos

Recursos Herramienta compatibildad con módulo • https: //enphase. com/en-us/support/module-compatibility Subida de Voltaje • Voltage Rise App Note Para empezar • www. enphase. com/gettingstarted 53 | © 2017 Enphase Energy, Inc. Learning and Development |

Preguntas

Apoyo Técnico (Customer Support) México: +1 866 715 -5534 C. América y Caribe: +1 800 821 1487 soporte_latinoamerica@enphaseenergy. com
