Differential Diagnosis of Hydrocephalus By NourEldin Mohammed Ref

Differential Diagnosis of Hydrocephalus By: Nour-Eldin Mohammed Ref : Radiological Differential Diagnosis : Stephen Chapman, 2003

The Normal CSF Flow

Hydrocephalus Abnormal dilatation of the cerebral ventricular system Hydrocephalus should be differentiated from disorders producing ventricular enlargement secondary to cerebral atrophy. Classified into : 1. Communicating Hydrocephalus 2. Non communicating Hydrocephalus

Characterisics of Hydrocephalus Ventricular enlargement disproportionate to the degree of sulcal widening Enlagement of temporal horne Periventricular fluid 2 ry to transependymal CSF permeation Enlarged 3 rd ventricle with large suprapineal and chiasmatic receses In children < 2 years the head circumference is often the best distinguishing feature between hydrocephalus and atrophy.

Hydrocephalic Brain Normal CT Brain

Subependymal CSF permeation

Non-Communicating Hydrocephalus (Intraventricular obstruction) Ventricular dilatation caused by intraventricular obstruction at or above the outlet foramina of the 4 th ventricle Causes: 1. Lateral ventricle 2. Foramen of Monro 3. 3 rd ventricle 4. Aqueduct of sylvius 5. 4 th ventricle

Lateral Ventriclar causes: Intrinsic tumor: ependymoma 2. Ventriculitis: due to intraventricular adhesions 3. Extraventricular Tumour: mass effect from large parenchymal mass 1.

Ventriculitis case 1 Ventriculitis case 2

Neuroepithelial Cyst

Obstruction of Foramen of Monro: Tumour : colloid cyst , subependymal giant cell astrocytoma 2. Ventriculitis 3. Haemorrhage : fresh clot , or adhesive arachnoiditis 4. Cerebral swelling with subfalcine herniation 1.

Subependymal Giant cell astrocytoma

Subependymal giant cell astrocytoma

Central Neuocytoma

Colloid cyst

Subfalcine Herniation :

Causes of Thid Ventricle Obstruction: Intraventricular Tumor 2. Extraventricular tumour : Pituitary adenoma , craniopharyngioma, arachnoid cyst. 1.

Pituitary Adenoma

Craniopharyngioma :

Causes of Cerebral Aqueduct of Sylvius Obstruction: 1. 2. 3. 4. 5. Developmental aqueduct stenosis Intraventricular tumour: epndymal seedling Extraventricular Tumour : Pineal Body tumour Ventriculitis Haemorrhage

Aqueduct Stenosis

Pineal Body Tumours:

Pineal Body Tumour:

4 th Ventricle obstruction : Intraventricular Tumour: Ependymoma, metastases 2. Extraventricular Tumours: medulloblastoma, haemangioblastoma, cerebellopontine angle tumours (acoutic neuroma) , meningioma 3. Outflow obstrction: infection (TB), SAH, leptomeningeal malignancy 1.

Ependymoma

Medulloblastoma :

Cerebellar Haemangioblastoma

Intraventricular Haemorrhage:

Acoustic Neuroma:

Communicating Hydrocephalus: There is free flow throughout the ventricular system. Impaired CSF resorption by the arachnoid granulation accounts for majority of cases 1. SAH 2. Infectious meningitis 3. Malignant meningitis 4. Granulomatous mningitis : TB , sarcoidosis 5. Altered venous Dynamics : Vein of Galen malformation, venous obstruction

TB Meningitis :

Vein of Galen :

Vein of

Thank you
