Diabetic Ketoacidosis Management Heidi Chamberlain Shea MD Endocrine

Diabetic Ketoacidosis Management Heidi Chamberlain Shea, MD Endocrine Associates of Dallas

Goals of Discussion • • • Pathophysiology of DKA Biochemical criteria for DKA Treatment of DKA Prevention of DKA Hyperosmolar Nonketoic Syndrome

Epidemiology • Annual incidence in U. S. – 5 -8 per 1000 diabetic subjects • 2. 8% of all diabetic admissions are due to DKA • Overall mortality rate ranges from 2 -10% – Higher is older patients

DKA Precipitating Factors • Failure to take insulin • Failure to increase insulin – Illness/Infection • Pneumonia • MI • Stroke – Acute stress • Trauma • Emotional • Medical Stress – Counterregulatory hormones • Oppose insulin • Stimulate glucagon release • Hypovolmemia – Increases glucagon and catecholamines • Decreased renal blood flow • Decreases glucagon degradation by the kidney

Diabetic Ketoacidosis Due to: Severe insulin deficiency Excess counterregulatory hormones Glucagon Epinephrine Cortisol Growth hormone

Role of Insulin • Required for transport of glucose into – Muscle – Adipose – Liver • Inhibits lipolysis • Absence of insulin – Glucose accumulates in the blood – Liver • Uses amino acids for gluconeogenesis • Converts fatty acids into ketone bodies – Acetone, Acetoacetate, β-hydroxybutyrate – Increased counterregulatory hormones

Counterregulatory Hormones - DKA Epinephrine Increases insulin resistance Activates glycogenolysis and gluconeogenesis Activates lipolysis Inhibits insulin secretion X X X Glucagon X Cortisol X Growth Hormone X X

Insulin Deficiency Glucose uptake Lipolysis Proteolysis Glycerol Free Fatty Acids Amino Acids Hyperglycemia Osmotic diuresis Gluconeogenesis Glycogenolysis Ketogenesis Dehydration Acidosis

Signs and Symptoms of DKA • Polyuria, polydipsia – Enuresis • Dehydration – Tachycardia – Orthostasis • Abdominal pain – Nausea – Vomiting • Fruity breath – Acetone • Kussmaul breathing • Mental status changes – Combative – Drunk – Coma

Lab Findings • Hyperglycemia • Anion gap acidosis – (Na + K) – (Cl + Bicarb) >12 – Bicarbonate <15 m. Eq/L – p. H <7. 3 • Urine ketones and serum ketones • Hyperosmolarity

Differential Diagnosis Anion Gap Acidosis • • • Alcoholic ketoacidosis Lactic acidosis Renal failure Ethylene glycol or methyl alcohol poisoning Starvation in late pregnancy or lactation (rare)

Atypical Presentations • DKA can be present with BS <300 – Impaired gluconeogenesis • • Liver disease Acute alcohol ingestion Prolonged fasting Insulin-independent glucose is high (pregnancy) – Chronic poor control but taking insulin • Bedside urine ketones false negatives – Measure acetoacetate not β-hydroxybutyrate – Send blood to lab

Treatment of DKA • Initial hospital management – Replace fluid and electrolytes – IV Insulin therapy – Glucose administration – Watch for complications – Disconnect insulin pump • Once resolved – Convert to home insulin regimen – Prevent recurrence

Treatment of DKA Fluids and Electrolytes • Fluid replacement – Restores perfusion of the tissues • Lowers counterregulatory hormones – Average fluid deficit 3 -5 liters • Initial resuscitation – 1 -2 liters of normal saline over the first 2 hours – Slower rates of 500 cc/hr x 4 hrs or 250 cc/hr x 4 hours • When fluid overload is a concern • If hypernatremia develops ½ NS can be used

Treatment of DKA Fluids and Electrolytes • Hyperkalemia initially present – Resolves quickly with insulin drip – Once urine output is present and K<5. 0, add 20 -40 meq KCL per liter. • Normo/Hypokalemia – Malnourished individuals (alcoholics) – Start K replacement and have K > 3. 0 prior to start of insulin – Remember to check magnesium • Phosphate deficit – May want to use Kphos • Bicarbonate not given unless p. H <7 or bicarbonate <5 mmol/L

Treatment of DKA Insulin Therapy • IV bolus of 0. 1 -0. 2 units/kg (~ 10 units) regular insulin • Follow with hourly regular insulin infusion • Glucose levels – Decrease 75 -100 mg/dl hour – Minimize rapid fluid shifts • Continue IV insulin until urine is free of ketones

Treatment of DKA Glucose Administration • Supplemental glucose – Hypoglycemia occurs • Insulin has restored glucose uptake • Suppressed glucagon – Prevents rapid decline in plasma osmolality • Rapid decrease in insulin could lead to cerebral edema • Glucose decreases before ketone levels decrease • Start glucose when plasma glucose <300 mg/dl

Insulin-Glucose Infusion for DKA Blood glucose <70 70 -100 101 -150 Insulin Infusion 0. 5 units/hr 1. 0 2. 0 D 5 W Infusion 150 cc/hr 125 100 151 -200 201 -250 251 -300 301 -350 351 -400 401 -450 451 -500 >500 3. 0 4. 0 6. 0 8. 0 10. 0 12. 0 15. 0 20. 0 100 75 50 0 0

Complications of DKA • Infection • Cerebral Edema – Precipitates DKA – Fever – Leukocytosis can be secondary to acidosis • Shock – If not improving with fluids MI r/o • Vascular thrombosis – Severe dehydration – Cerebral vessels – Occurs hours to days after DKA • Pulmonary Edema – Result of aggressive fluid resuscitation – – First 24 hours Mental status changes Tx: Mannitol May require intubation with hyperventilation

Once DKA Resolved Treatment • Most patients require 0. 5 -0. 6 units/kg/day • Pubertal or highly insulin resistant patients – 0. 8 -1. 0 units/kg/day • Long acting insulin – 1/2 -2/3 daily requirement – NPH, Levemir or Lantus • Short acting insulin – 1/3 -1/2 given at meals – Regular, Humalog, Novolog or Apidra

Once DKA Resolved Treatment • Give SQ insulin at least 2 hours prior to stopping insulin infusion. • Lantus or Levemir – Steady state at 2 -4 hrs • Short acting analogs for meal times • If transitioning to the pump – Restart the pump and after 30 minutes stop insulin infusion • May still be more insulin resistant so will need more than usual dose • Check blood sugars in 2 hrs – Offer supplemental

I

Insulin Types and Action

Prevention of DKA Sick Day Rules • Never omit insulin – Cut long acting in half • Prevent dehydration and hypoglycemia • Monitor blood sugars frequently • Monitor for ketosis • Provide supplemental fast acting insulin • Treat underlying triggers • Maintain contact with medical team

Preventing DKA • Education – Sick days or NPO • • Do not stop insulin but adjust Continue basal insulin NPH insulin- decrease by 30 -50% Use short acting – Q 2 -3 hrs with Novolog, Humalog and Apidra – Q 4 hrs with regular insulin – Hyperglycemia • If > 300 mg/dl, then check urine ketones • If ketones positive – Increase fluids – Take supplemental insulin Q 2 hrs – Insulin temperature sensitive • • • < 77 degrees Teenagers, homeless, pen and pump users Do not store insulin in the car Traveling and summer outdoor activities May need to replace more frequently

Pump patients • If blood sugars are increasing (>200 mg/dl) – Bolus – Check 2 hrs later, if climbing – Give SQ correction – Change site – Make sure pump is working – Change insulin • Pump patients need long acting back up at home and when traveling

Pump patients • If in DKA – Disconnect the pump • Transitioning back to pump – Start pump with basal x 2 hrs, then stop insulin drip – Check blood sugars every 2 hrs to make sure they are in range

Clinical Trials • Immune modulating studies – www. jdrf. org – www. Clinical. Trials. gov • Anti CD 3 - monoclonal AB – Phase 3 trials – Newly diagnosed Type 1 Diabetes • Call Research Institute of Dallas 214 -363 -5535 • Immune modulating vaccines • Stem cell and pancreas transplants

Goals of Discussion • • • Pathophysiology of DKA Biochemical criteria for DKA Treatment of DKA Prevention of DKA Hyperosmolar Nonketoic Syndrome

Hyperosmolar Nonketotic Syndrome • Extreme hyperglycemia and dehydration – Unable to excrete glucose as quickly as it enters the extracellular space – Maximum hepatic glucose output results in a plateau of plasma glucose no higher than 300500 mg/dl – When sum of glucose excretion plus metabolism is less than the rate which glucose enters extracellular space.

Hyperosmolar Nonketotic Syndrome • Extreme hyperglycemia and hyperosmolarity • High mortality (12 -46%) • At risk – Older patients with intercurrent illness – Impaired ability to ingest fluids • Urine volume falls – Decreased glucose excretion • Elevated glucose causes CNS dysfunction and fluid intake impaired • No ketones – Some insulin may be present – Extreme hyperglycemia inhibits lipolysis

Hyperosmolar Nonketotic Syndrome Presentation • • Extreme dehydration Supine or orthostatic hypotension Confusion coma Neurological findings – Seizures – Transient hemiparesis – Hyperreflexia – Generalized areflexia

Hyperosmolar Nonketotic Syndrome Presentation • Glucose >600 mg/dl • Sodium – Normal, elevated or low • Potassium – Normal or elevated • Bicarbonate >15 m. Eq/L • Osmolality >320 m. Osm/L

Hyperosmolar Nonketotic Syndrome Treatment • Fluid repletion – NS 2 -3 liters rapidly – Total deficit = 10 liters • Replete ½ in first 6 hours • Insulin – Make sure perfusion is adequate – Insulin drip 0. 1 U/kg/hr • Treat underlying precipitating illness

Clinical Errors • Fluid shift and shock – Giving insulin without sufficient fluids – Using hypertonic glucose solutions • Hyperkalemia – Premature potassium administration before insulin has begun to act • Hypokalemia – Failure to administer potassium once levels falling • Recurrent ketoacidosis – Premature discontinuation of insulin and fluids when ketones still present • Hypoglycemia – Insufficient glucose administration

Conclusion • Successful management requires – Judicious use of fluids • Establish good perfusion – Insulin drip • Steady decline • Complete resolution of ketosis – Electrolyte replacement – Frequent neurological evaluations – High suspicion for complications • Determine etiology to avoid recurrent episodes
