Developing Cement Mortar for Advanced Applications ET 493 Instructor: Mohammad Saadeh Advisor: Mohamed Zeidan

Developing Cement Mortar for Advanced Applications ET 493 Instructor: Mohammad Saadeh Advisor: Mohamed Zeidan Valcour Langlois & Brennen Reed May 8, 2020

What is Mortar? Sand = + + Water Mortar Cement

What is Mortar? Sand = + + Water Mortar Cement

Significance of Rapid Setting Mortar Decreased Set Time Less Time on Job Cost Efficiency

Significance of Rapid Setting Mortar Decreased Set Time Less Time on Job Cost Efficiency

Superplasticizers BASF MASTERGLENIUM 7500 Superplasticizers help increase the flow ability of the mortar while

Superplasticizers BASF MASTERGLENIUM 7500 Superplasticizers help increase the flow ability of the mortar while sustaining compressive strength and set time SIKA VISCOCRETE EUCLID CHEMICAL EUCON 1035 SIKAMENT

Procedures Design Mortar Mix Each Sample Test Each Sample Compare Results

Procedures Design Mortar Mix Each Sample Test Each Sample Compare Results

Flow Table Test • • • Fill mold halfway and tamp 25 times Continue

Flow Table Test • • • Fill mold halfway and tamp 25 times Continue to fill mold completely and tamp 25 more times Remove mold and turn handle to drop table 25 times in 15 seconds Take average of 4 diameters Flow= (100)*(Avg. Diameter- Inner base of mold diameter)/ Inner Base of Mold Diameter

Compression Test Surface Area= Average of 3 widths multiplied by the average of the

Compression Test Surface Area= Average of 3 widths multiplied by the average of the 3 height measurements Compressive Strength= Max Load/Surface Area

Vicat Needle Test • Mold mortar paste in conical ring • Find the initial

Vicat Needle Test • Mold mortar paste in conical ring • Find the initial and Final Setting Time • Initial Time= Elapsed time from when the water touches the mortar until the needle penetrates 25 mm or less • Final Time= Elapsed time from when the water touches the mortar until the needle no longer penetrates

Mix Design- Fall Semester Mix Cement Sand Water Silica SP W/C Control 1180 g

Mix Design- Fall Semester Mix Cement Sand Water Silica SP W/C Control 1180 g 3409 g 543 g 117. 5 g 0 m. L 0. 49 SM-. 5 m. L 1180 g 3409 g 543 g 117. 5 g . 5 m. L 0. 49 SM-3 m. L 1180 g 3409 g 543 g 117. 5 g 3 m. L 0. 49 VC-2 m. L 1180 g 3409 g 543 g 117. 5 g 2 m. L 0. 49 VC-5 m. L 1180 g 3409 g 543 g 117. 5 g 5 m. L 0. 49 Legend: SP: Superplasticizer Used W/C: Water to Cement Ratio SM: Sika Concrete Sikament Superplasticizer VC: Sika Viscocrete Superplasticizer

Mix Design-Spring Semester Mix Cement Sand Water Silica SP W/C Control 1180 g 3409

Mix Design-Spring Semester Mix Cement Sand Water Silica SP W/C Control 1180 g 3409 g 543 g 117. 5 g 0 m. L 0. 49 MG-2 ml 1180 g 3409 g 543 g 117. 5 g 2 m. L 0. 49 MG-3 m. L 1180 g 3409 g 543 g 117. 5 g 3 m. L 0. 49 EU-2 m. L 1180 g 3409 g 543 g 117. 5 g 2 m. L 0. 49 EU-3 m. L 1180 g 3409 g 543 g 117. 5 g 3 m. L 0. 49 Legend: SP: Superplasticizer Used W/C: Water to Cement Ratio MG: BASF Master. Glenium Superplasticizer EU: Euclid Eucon 1035 Superplasticizer

Compression Test Results Mix 7 Day 14 Day 28 Day Control 2986. 9 psi

Compression Test Results Mix 7 Day 14 Day 28 Day Control 2986. 9 psi 4813. 9 psi 5907. 3 psi Sikament-. 5 m. L 4697. 2 psi 5134. 9 psi 5247 psi Sikament-3 m. L 4957. 7 psi 5957. 3 psi 6045 psi Viscocrete-2 m. L 4700 psi 5735. 2 psi 5760. 9 psi Viscocrete-5 m. L 5494. 9 psi 6254. 9 psi 6601. 3 psi Master. Glenium-2 m. L 3284. 6 psi 6998. 2 psi 7729. 4 psi Master. Glenium-3 m. L 5186. 1 psi 5740. 5 psi 6146. 2 psi Eucon-2 m. L 4418. 1 psi 5347. 4 psi 7390. 1 psi Eucon-3 m. L 5009. 6 psi 6906. 7 psi 7072. 2 psi

Vicat Needle Test Results 335 275 Set Time in Minutres 264 250 235 255

Vicat Needle Test Results 335 275 Set Time in Minutres 264 250 235 255 247 225 220 179 167 142 122 Control 152 110 SM-. 5 m. L SM-3 m. L VC-2 m. L VC-5 m. L Mortar Mixes Initial Time Finial Time MG-2 m. L MG-3 m. L EU-2 m. L EU-3 m. L

Flowability Flow Ability 135% Percent Flowability 115% 112% 111% 104% 90% 80% 60% Control

Flowability Flow Ability 135% Percent Flowability 115% 112% 111% 104% 90% 80% 60% Control SM-. 5 m. L SM-3 m. L Control SM-. 5 m. L VC-2 m. L SM-3 m. L VC-5 m. L Mortar Mixes VC-2 m. L VC-5 m. L MG-2 m. L MG-3 m. L EU-2 m. L EU-3 m. L

Set Time in Minutres Vicat Needle Test Compared To Flowability 335 264 235 220

Set Time in Minutres Vicat Needle Test Compared To Flowability 335 264 235 220 179 Control SM-. 5 m. L 265 247 130 SM-3 m. L VC-2 m. L VC-5 m. L Mortar Mixes Initial Time 225 142 110 MG-2 m. L 275 255 167 142 122 250 MG-3 m. L EU-2 m. L 152 EU-3 m. L Finial Time Percent Flowability Flow Ability 135% 104% 115% 112% 111% 90% 80% 60% Control SM-. 5 m. L SM-3 m. L Control SM-. 5 m. L VC-2 m. L SM-3 m. L VC-5 m. L Mortar Mixes VC-2 m. L VC-5 m. L MG-2 m. L MG-3 m. L EU-2 m. L EU-3 m. L

Conclusion • Eucon 2 ml has an optimal flowability, set time, and compressive strength.

Conclusion • Eucon 2 ml has an optimal flowability, set time, and compressive strength. • Most of the other superplaciticizers has a retarding effect on the mortar. • Future research may include printing methods or manipulating proportions to make a more efficient mix.

Deliverables • Continue mixing different mixes using the different chemicals • Analyze the finalized

Deliverables • Continue mixing different mixes using the different chemicals • Analyze the finalized data to find best mix • Use the optimal mix to use the mortar gun for 3 D printing • Prepare and finalize publication

Month January February Week 3 4 1 2 3 4 March April Timeline Task

Month January February Week 3 4 1 2 3 4 March April Timeline Task Order Materials T 9 Mix T 9 Compression Test T 10 Mix, Flow Table Test, and Vicat Needle Test T 9, T 10 Compression Test T 11 Mix, Flow Table Test, and Vicat Needle Test T 9, T 10, T 11 Compression Test T 12 Mix, Flow Table Test, and Vicat Needle Test 1 T 9, T 10, T 11, T 12 Compression Test T 13 Mix, Flow Table Test, and Vicat Needle Test 2 T 10, T 11, T 12, T 13 Compression Test T 14 Mix, Flow Table Test, and Vicat Needle Test 3 T 11, T 12, T 13, T 14 Compression Test T 15 Mix, Flow Table Test, and Vicat Needle Test 4 T 12, T 13, T 14, T 15 Compression Test T 16 Mix, Flow Table Test, and Vicat Needle Test 1 T 13, T 15, T 16 Compression Test Mortar Gun Testing 2 T 14, T 16 Compression Test Mortar Gun Testing T 15 Compression Test Mortar Gun Testing T 16 Compression Test Mortar Gun Testing 3 4
