DCM300 Modem Hardware Options and Installation Product Tour
- Slides: 124
DCM-300 Modem Hardware Options and Installation
Product Tour § Internal Components – GPS receiver – Cell modem – Wi-Fi Card Rugged Aluminum Housing SIM card - Interchangeable External GPS Antenna External Wi-Fi Antenna Single JAE Data connector External Cellular Antenna
Featured Application § Provides complete Connected Farm solution – – – Corrections by cell (VRS and RTX) Office Sync (data transfer) Vehicle Manager (asset tracking) Vehicle Sync Remote Assistant
Features § VRS/RTX corrections – RTK corrections – Corrections by cell via VRSNow or other non-Trimble NTRIP based networks – Requires purchase of data package • Trimble offers Verizon(CDMA), AT&T(GSM) (USA only) • GSM Global data packages sourced separately – Network IP address and Port ID – Username and Password – Data stream or mount point • CMR or CMR+ – Receive Center. Point RTX worldwide via cell – Purchase VRSNow subscription at http: //vrsnow. us/
Features § Office Sync – annual subscription – Enabled in Farm Works software – Send and receive data between office and the field via Wi-Fi or cellular transmission – Eliminate need to transfer data via USB thumb drives. – Specific to Connected Farm single sign-on – Specific to modem serial number – Use Wi-Fi or purchase cellular data package to transfer data
Features § Vehicle Manager – annual subscription – – – Asset tracking, geofence and curfew alerts Service enabled at www. connectedfarm. com Specific to modem serial number No Fm. X/FM 1000 or CFX/FM 750 display required Two power modes for DCM-300 affect reporting status 1. Engine running § Full power mode § Checks position and updates server every 15 minutes 2. Engine stopped § Low power mode § Checks position every 6 hours
Features § Vehicle Sync - one time passcode § Real time wireless data transmission between multiple vehicles § Only works with Fm. X/FM 1000 display § Share: Ø guidance lines Ø coverage logging Ø point/area/line features Ø vehicle icons of other operating units Ø Harvest data and Field-IQ as-applied data, tank levels § Connect via DCM-300 with Wi-Fi antenna
Versions of Modems § Two cellular network models available Check faceplate on modem to verify type DCM-300 G GSM Network DCM-300 C X CDMA Network X Vehicle Manager X X Office Sync X X RTK Corrections X X
DCM-300 G Version § SIM Card installation required – GSM only
Data Plan Selection § Choosing a cellular carrier – – – Provides access to the internet Voice has priority over data DCM-300 has higher power than cell phone CDMA designed for data Trimble offers data plans for Verizon (CDMA) or AT&T (GSM) (USA only) – Outside of USA, users source data plan directly with appropriate GSM carrier
Compatibility § Will the modem work with non-Trimble networks? – CORS: Yes, requires CMR or CMR+ format – DOT (state): Yes, requires CMR or CMR+ format • Contact network provider for instructions – Competitive networks • Color blind • Topcon Top. Net, Leica Spider. Net, Geo++, My. Way. RTK, Freedom Plus, Raven Slingshot • Requires CMR or CMR+ format
DCM-300 Installation
Considerations Before Install § What is modem going to be used for? § This impacts decisions for: Ø Power connection Ø Modem location/visibility
DCM-300 LED Lights Green LED: Power & Telematics GPS Status Amber LED: Cellular & Wi -Fi Status
DCM-300 LED Status § Blink is 1 second on/1 second off § Slow blink is 3 seconds on / 3 seconds off § Fast blink is 200 milliseconds on / 200 milliseconds off § Note – The amber light will blink if modem has not been activated with cellular service; display will report wireless signal strength if cellular service is available.
Power Connection Options Two options for connecting modem to power: 1. Harnessing to connect to a Trimble power bus. 2. Harnessing to connect to battery power and key switch power. Note: if modem is to be used with Connected Farm Vehicle Manager/asset tracking, power option 2 is recommended for constant vehicle tracking.
DCM-300 Power Installation Options R Terminal Connection CAN Connection Switch Power Direct to Battery Power Bus Connection
Power Bus Connection Install 1. 2. 3. 4. 5. Very easy to hook up. No need to route cables outside the cab. Modem is only on when the display is on. Good solution for VRS/NTRIP connections. Incomplete tracking abilities for Vehicle Manager since modem doesn’t have access to constant power.
Direct to Battery / Switch Power Install 1. Route power harness direct to battery. 2. Connect switch power wire to 12 V power source. Ø If switch power wire is not attached, modem will power on for 15 minutes and then go into low power mode and only report every 6 hours. It will not go back into full power mode without a signal from a switch input. If this is not done, the system will not operate correctly. Ø Likewise, if the switch power wire is run to the battery, modem will remain in full power mode at all times and ultimately drain the battery.
R Terminal Connection Hookup 1. Connect the R Terminal to alternator for accurate count of engine hours with Vehicle Manager. Ø Option not necessary if machine is using CAN connection that reports engine hours
Modem Applications Different ways modem can be used: § Vehicle Manager only § VRS/RTX/Office Sync/Vehicle Manager/Remote Assistant or any combination
Installation Kit Vehicle Manager/Asset Tracking ONLY § Covert installations § Kit includes: – GPS/Cell combo antenna – Antenna label must be installed face up – Check connection status with LED GPS Port Cell Port Label Side Up
DCM-300 Vehicle Manager Layout Asset Tracking Only Install R Terminal Connection Switch Power Bus Connection Direct to Battery
Installation Kit Vehicle Manager/Asset Tracking § Vehicle CAN Adapter Harness
Installation Kit Office Sync/Vehicle Manager/VRS/RTX § Fm. X and CFX-750 layout is identical § Components – DCM-300 modem – GPS/cell combo antenna (for Vehicle Manager/asset tracking) – High gain cellular antenna – Fm. X ~ CFX-750 cable assembly § Connection to power § CAN connection with Vehicle CAN adapter cable § Optional connection to R terminal on alternator if engine hours are not available on the CAN USB Hub
Fm. X / DCM-300 Installation Layout USB Hub must be installed
CFX-750 / DCM-300 Installation Layout
USB Hub Install § Damage to the USB hub can occur if the main connector (1) is connected after power (2) and USB (3) have already been connected. § You must connect the main connector (1) before connecting the power and USB. 3 1 2
Office Sync/Vehicle Manager/VRS/RTX § Fm. X/FM 1000 or CFX/FM 750 installations
Office Sync/Vehicle Manager/VRS/RTX § Fm. X/FM 1000 or CFX/FM 750 installations USB/Display Fuse Power CAN Modem
Office Sync/Vehicle Manager/VRS/RTX § Fm. X/FM 1000 or CFX/FM 750 installations – High gain cell antenna – Magnetic mount – 20’ of coaxial cable
Office Sync/Vehicle Manager/VRS/RTX § Fm. X/FM 1000 or CFX/FM 750 installations – GPS/cell combo antenna (Only required for Vehicle Manager) – Install with proper side facing up – Disconnect cell side when used with high gain cell antenna for VRS/File Transfer
Installation Kit Vehicle Manager/VRS/RTX § Ag. GPS 262/372 antenna § Components – – DCM-300 modem GPS/Cell combo antenna (for asset tracking) High gain cellular antenna Ag. GPS 262/372 cable assembly § Connection to power § CAN connection with Vehicle CAN adapter cable § Optional connection to R terminal on alternator if engine hours are not available on the CAN
DCM-300 to Ag. GPS 372 Install Layout
Install Kit – Vehicle Manager/VRS/RTX § 262/372 Receiver installations
Install Kit – Vehicle Manager/VRS/RTX § 262/372 Receiver installations – Uses same protocol as Ag 3000 modem – No firmware update required on Pro 600 displays 262 Receiver CAN Modem Fuse Power
DCM-300 Ordering and Activation Procedure
Purchasing DCM-300 Hardware § Modem components ala carte – order pieces that you need. Ø Changed from 2012 bundle arrays 1. Purchase DCM-300 modem 2. Purchase additional hardware as needed Ø Centerpoint VRS/Data Transfer antenna kit Ø Vehicle Sync components Ø Cable Assy, DCM to display, receiver or asset tracking only 3. Purchase DCM-300 data plan and Connected Farm services as needed
Tips for Successful Modem Operation § Modem requires service plan to operate. § Purchase services on Trimble Store under Information Management >Connected Farm & DCM 300 Modem and Data Plans. § Services must be activated. § Activation of services requires knowing modem serial number.
Information Management on the Store
DCM-300 Modems on the Store
DCM-300 Modems on the Store
Base Modem Bundle § DCM-300 modem § External covert GPS & cellular antenna
VRS/Cellular Data and Vehicle Sync § Purchase VRS Upgrade kit to add VRS and/or Office Sync data transfer transmission capabilities. Ø VRS subscription and Office Sync service purchased separately. § Purchase Vehicle Sync Wi-Fi Antenna and Passcode to enable functionality
Centerpoint VRS/Data Transfer Service To Activate Modem for VRS/Data Transfer Service: 1. Order Centerpoint Upgrade and Antenna Hardware Kit 2. Activate Centerpoint VRS/Data Transfer service 1. From Partner Store Home page select Service Activation 2. Find Service Order Number a) Enter DCM-300 Modem serial number and customer Connected Farm account email b) Click ‘Apply’ or ‘Apply and Email Results’ c) After Clicking ‘Apply and Email results’, enter Dealer email d) Service has been activated when you see: 1) ‘Email sent to message. . ’ 2) Activation status changed from ‘Not Activated’ to ‘Activated 20 -Sep-2012 e) Activation Acknowledgement Email sent to End Customer
DCM-300 Cables § Purchase DCM-300 to Display cable to use modem with Fm. X or CFX-750 display § Purchase DCM-300 to Receiver cable to use modem with AG-372 or 262 receiver § Purchase DCM-300 Asset Tracking cable to use modem without a display or receiver.
Vehicle Interface Cables § Purchase cables to interface with: Ø R-Terminal connection to track engine hours from alternator connection Ø Vehicle CAN adapter harnesses to interface with ISO CAN capable vehicles to read data on public CAN
Purchase Data Plans on Trimble Store § Cellular data plans – – – Used to provide cellular internet connection Receive VRS correction signals Send/receive data with Office Sync Perform Remote Assistant One data plan sufficient for both VRS and Office Sync functionality
Connected Farm Services § § § Remote Assistant – annual service Ø Activate service with Fm. X display s/n and customer single sign-on email address Vehicle Manager - annual service Ø Activate service with modem s/n and customer single sign-on email address Office Sync - annual service Ø Activate service with customer single sign-on email address Ø Email pdf form on store to activate service
Remote Assistant Setup 1. Activate Remote Assistant service on Trimble Store Ø Order number, Fm. X display s/n and customer Connected Farm email address are required Ø Unlock will be generated on store. 2. Reseller will be emailed Remote Assistant login credentials and a link to the web site 3. Reply to the email with the DCM s/n in order for Trimble to upgrade DCM firmware over the air 4. Enter unlock code on Fm. X display 5. Enable Remote Assistant on Fm. X display to start a session
Activate Remote Assistant Service § Remote Assistant must be activated § Service activation on the store generates unlock code required to be input on the Fm. X display
Service Activation Screen § Need Fm. X display serial number and customer Connected Farm account email address § Activation will generate unlock code in Service Activation column
Vehicle Manager Ordering § Refer to instructions to complete Service Activation when modem is received.
Vehicle Manager Service To Activate Vehicle Manager Service: 1. Order Vehicle Manager Service 2. Activate Vehicle Manager Service 1. From Partner Store Home page select Service Activation 2. Find Service Order Number a) Enter DCM-300 Modem serial number and customer Connected Farm account email b) Click ‘Apply’ or ‘Apply and Email Results’ c) After Clicking ‘Apply and Email results’, enter Dealer email d) Service has been activated when you see: 1) ‘Email sent to message. . ’ 2) Activation status changed from ‘Not Activated’ to ‘Activated 20 -Sep-2012 e) Activation Acknowledgement Email sent to End Customer
Service Activations § To activate Vehicle Manager service and/or Centerpoint VRS/Data Transfer, choose the Service Activations category
Service Activation Screen § § Fill in form on Store Specify customer email address they wish to use for sync.
Customer Service Activation Email
Office Sync Ordering § Order Office Sync service on Trimble Store
Follow Activation Instructions Office Sync Device Connection P/N 81014 -16 To Activate Office Sync 1. Enter order in the store as usual for Office Sync - please note the Sales Order number 2. Complete PDF form - fill in all blanks. 3. Email to cf@TRIMBLE. COM 4. An email notification will be sent when the service is activated. 5. Office Sync runs for 12 months from purchase 6. To renew Office Sync begin again by entering an order for this service on the store, completing form and emailing form as previously done. 7. If renewal is not received - Office Sync will be inactive until a new service is purchased. Questions: - Please direct all Office Sync activation questions to the email address cf@TRIMBLE. COM Office Sync Activation Form (Click Here)
Office Sync Activation Form § Fill out and email service activation form § Specify customer email address they wish to use for sync.
DCM-300 Updates Over The Air
How To Get The Update § Update delivered wirelessly over the air (OTA) to DCM 300 using a cellular or wireless connection. § Request update by filling out and submitting request form available on Trimble store under Information Management > DCM-300 Modem & Data Plans. § Trimble will respond to update requests within 24 hours, Monday through Friday. § Resellers will receive email confirmation when update is processed. § Update will begin the next time modem is powered up.
Update Request Form § Complete form. § Email to cf@trimble. com § After confirmation, alert customer to turn modem on, at convenient time, to receive update.
How Long Will It Take to Update? § Modem must be powered on and connected to the Internet for the update to begin. 1. Download § § § Time to download will depend on cellular signal strength anywhere from 15 -40 minutes. Download will suspend and continue with power cycle. Modem will continue to operate normally while update is downloaded in the background. 2. Installation § § § Modem will be inoperable while installation occurs. Average install time is less than 15 minutes. If power is cycled during an install, installation will start over with power cycle. § To prevent update and reboot from interrupting VRS connection and Autoguidance, turn modem on outside work hours and allow it to update.
How Will I Know If The Update is Working? § Modems with version 4. 0 firmware will give this message:
DCM-300 Unlocks
Verifying DCM-300 Unlock in Fm. X With the DCM-300 connected and powered on, go to the Fm. X home screen and select Unlocks. If DCM is connected correctly, it will be unlocked and ready to use.
Verifying DCM-300 Unlock In Fm. X § In Fm. X unlocks screen, the DCM-300 will appear in list § Note green checkmark indicating DCM is unlocked
Verifying DCM-300 Unlock In CFX-750 To navigate to unlock status go to: Wrench > Status > Upgrade Options
VRS CONFIGURATION AND DIAGNOSTICS Fm. X / FM 1000
Setting up VRS Correction Service § If necessary, unlock DCM-300 modem using passcode for File Transfer, VRS, Internet, and Wi-Fi (only for modems purchased prior to 12/2011). § Required NTRIP information provided by VRS correction service provider: – – Server name / Address (IP address or URL) Server port number Mount point (case sensitive) User name and password
Using Non-Trimble Data Plan § Trimble recommends a data plan of at least 500 MB per month. § DCM-300 G modem (P/N 83500 -xx). – You must purchase a data plan and a new SIM card from your preferred provider and replace the factory SIM card in the DCM 300 G modem with the new SIM card purchased from the provider. § DCM-300 C modem Verizon (P/N 83400 -xx). If you go directly to Verizon, you must provide Verizon with 8 -digit ESN number shown on back of the DCM-300 modem. – Note – No configuration tool is required to activate the Verizon modem.
Fm. X Setup § Add the VRS Plugin
VRS Plug-in Setup § With VRS plug in added, click Setup
Fm. X GPS Configuration For VRS § Under Settings, set Corrections to Trimble VRS in order to use internet corrections
DCM-300 VRS Configuration § Set VRS device type to DCM 300
DCM-300 VRS Configuration § VRS Server Setup – enter NTRIP settings from VRS provider
DCM-300 VRS Configuration § For DCM-300 G Modem only - enter SIM card data where necessary Note: not all carriers require this info to be used
SIM Card Setup (GSM only) § Note – This tab is available only for DCM-300 G modems and is only needed if cellular SIM card was obtained from a third party. § Required information provided by SIM card provider: – – APN (case sensitive) User name Password SIM PIN § Note – After entering or editing any of the four SIM card settings, modem automatically reboots to apply changes. The modem will be offline for approximately three minutes while rebooting.
VRS Diagnostics Screen § Diagnostics screen shows wireless signal strength as well as VRS service status
CONNECTED FARM SETUP AND DIAGNOSTICS Fm. X / FM 1000
Fm. X Setup § Add Office Sync Plugin
Connected Farm Plug-in Setup § With Office Sync plug in added, click Setup
Connected Farm Setup – in this case the modem is plugged in and powered – it takes 2 or more minutes to connect to display
Enter SIM Card Info If Needed § For DCM-300 G only - the SIM Card settings can be entered
• Enter device name (what you want the device to show up as in Farmworks Office) Hit Account Setup
Connected Farm Diagnostics § Connected Farm diagnostics show the Wireless link status, signal strength, and activity § Useful for both VRS and Connected Farm
Connected Farm Inbox
Questions?
VRS CONFIGURATION AND DIAGNOSTICS CFX-750 / FM 750
Setup Screens
GPS Setup
Set Correction Source to RTK
Correction Delivery Selection
VRS Modem Selection
VRS Settings
DCM-300 G Modem SIM Settings This setup is only needed for DCM-300 G units where the customer has supplied their own SIM card. CDMA modem’s do not need to edit any Wireless settings
Entering SIM Settings § Modem setup is only required for DCM-300 G units where the customer supplies their own SIM card. Settings should be obtained by contacting your SIM card supplier.
DCM-300 VRS Server Setup
VRS Server Address
VRS Port Number Entry
VRS Mount Point Entry
VRS User Name Entry
VRS Status Entry
VRS Status § § Screen shows summary of NTRIP settings and DCM-300 status items Connection status shows when modem is connected to a VRS service
Takeaway Points § Cabling that connects the DCM-300 modem to an Fm. X / CFX-750 display is the same for both VRS corrections and Connected Farm Office Sync. § The GPS patch antenna (included) is recommended but not required for the modem unless you are using Vehicle Manager asset tracking service. § The modem has 3 different unlock codes that are stored on the modem itself, not on the display. They are: – File transfer, VRS corrections, Internet, and Wi-Fi – Ag Bus vehicle bus config (for Telematics) – Cellular parameter modification (This unlock enables you to enter and edit SIM card settings if you need to activate the DCM-300 G modem for a third-party cellular provider. )
Takeaway Points § Note – If the DCM-300 modem is not unlocked for File Transfer, VRS, Internet, and Wi-Fi, the modem will not connect to a Ag. GPS 262/372 receiver. – The Ag. GPS 262 receiver must have version 2. 0 firmware or higher and use the same setup option as an Ag 3000 modem in the RTK Configuration settings. § The Fm. X / CFX-750 display does not need to be unlocked for RTK if you are only using Connected Farm Office Sync service. § The Fm. X / CFX-750 display must be unlocked to RTK level if you are using the modem for VRS corrections.
Takeaway Points § The DCM-300 modem saves some settings internally and can be set up for VRS corrections through one display and later transferred for use with another display. § The modem holds its configuration and transfers it to the second display on power up as long as the second display is unlocked for RTK. § If there is no communication between the modem and the display, try the following: – Make sure that the display can “see” the DCM-300 modem from the Unlock screen three minutes after startup. If the DCM-300 option appears in the Unlock screen the display is communicating successfully with the DCM-300 modem. – Make sure the Fm. X integrated display is connected to the modem using the supplied USB hub and that the green LED light on the USB Hub is solid.
Takeaway Points – The CFX-750 display does not require a USB hub but it is recommended. – Make sure that the USB port on the Fm. X/CFX display is working correctly. – To check this, insert a USB drive into the back of the display—if the display recognizes the USB drive or allows you to load firmware into the display the USB port is working correctly. – Note – The USB port will either work for everything or not work for anything. – Check power connections to the DCM-300 modem. The power lead must be connected to a constant 12 V source and the ignition lead must be connected to a switched 12 V source for operation. – Make sure that cable P/N 82033 (connecting the USB hub to the modem) has no faults or breaks.
DCM-300 SETUP FOR Ag. GPS 262/372 RECEIVER
DCM-300 Setup for Ag 262/372 Note – The DCM-300 uses the Ag 3000 radio type setting 5. Press Right arrow to highlight radio type and then Up or Down arrow to change radio type to Ag 3000 VRS Radio.
DCM-300 Setup for Ag 262/372 § To configure NTRIP parameters, press Down arrow. § Enter NTRIP ID address provided by service provider. Service provider may be a Trimble VRS Now™ service operator, or a third-party network RTK provider. § Note – User name, password, and mount points are case sensitive. Make sure you use correct capitalization when entering these values.
DCM-300 Setup for Ag 262/372 § Set NTRIP server port number
DCM-300 Setup for Ag 262/372 § Set server mount point
DCM-300 Setup for Ag 262/372 § Set server user name
DCM-300 Setup for Ag 262/372 § Set Server password
DCM-300 Status for Ag 262/372 § When DCM-300 modem is connected to network and obtaining RTK Fixed corrections, the following status messages may appear in main screen:
DCM-300 Status for Ag 262/372 § When DCM-300 modem is connecting to network, the following status messages may appear in the main screen:
DCM-300 Status for Ag 262/372 § If there are network problems or bad mount points, the following status messages may appear in the main screen:
VRS Pro 600 User Interface § This Setup Page is for credentials that relate to the Correction Provider. Information to enter here will be provided by Trimble VRS Now, another 3 rd Party Cellular Network Provider or a Governmental Provider. All fields may not need to be filled based on provider and location
VRS User Interface Status Page § Trimble VRS Now information will vary based on location and Sim Card Provider (EU). Trimble VRS Now will provide this information § Other VRS Networks: § All information from Sim provider
DCM-300 Setup for Ag 262/372 § Communication between the DCM-300 modem and an Ag. GPS 262/372 receiver § Make sure that the following is correct: – The Ag. GPS 262/372 receiver has version 2. 0 firmware or higher, is unlocked for RTK, and has been configured for communication to an AG 3000 modem. – Cable P/N 82133 from the DCM-300 modem is connected to port B on the Ag. GPS 262/ AG-372 receiver. – Port B is configured for RTKLINK 38400 for both input and output. – Constant power is connected to the machine battery and the ignition lead is connected to a switched 12 V source.
DCM-300 Setup for Ag 262/372 § If the Ag. Remote display shows a message No AG 3000 found, the receiver is not communicating with the modem. Check the following: – Make sure the DCM-300 modem is unlocked for VRS operation. If the modem is not unlocked for VRS operation, the receiver will not communicate with the modem. – Check the cabling connection between the modem and port B of the receiver. If cable P/N 82133 is damaged, the receiver will not communicate with the modem. – Check power connections to the DCM-300 modem. The power lead must be connected to a constant 12 V source and the ignition lead must be connected to a switched 12 V source for operation.
