DC l l l Servo Motors Stepper Motors

סוגי מנועים DC l l l Servo Motors Stepper Motors Linear Motors Brushed DC Motors Brushless DC Motors

כותרות - הנעה חשמלית במטוסים l l DC motors meet aircraft weight and power demands (9 July 2001): Powertec Industrial Motors has received an order for the first prototype of a 100 hp brushless DC motor and drive for a high-volume compressor to be used in C-130 aircraft Brushless motors to serve on new aircraft carrier: The newest aircraft carrier now being constructed will have warping winches powered by large brushless motors made by Powertec Industrial Motors.

Powertec Motors Model Number HP RPM Weight [kg] F 182 5 1750 35. 4 F 184 7. 5 1750 57. 2 F 184 10 1750 57. 2 F 215 15 1750 94. 3 F 254 20 1750 115 F 256 25 1750 153 F 256 30 1750 153 F 259 40 1750 194 F 287 50 1750 168 F 287 60 1750 168 F 288 75 1750 214 F 28 A 100 1750 261 F 28 C 125 1750 309 F 328 150 1750 315 F 32 B 200 1750 382 F 32 D 250 1750 442 F 32 D 300 1750 442

RELIANCE Frame HP RPM Voltage Weight[kg] GK 1303 21. 32225 1690 460/310 142 GK 1305 23. 60199 1775 460/310 154 GK 1305 21. 45635 1368 460/310 154 GK 1307 33. 12325 1685 460/310 167 GK 1309 42. 7786 1945 460/310 179 GK 1309 28. 83197 1215 460/310 179 GK 1311 56. 85934 1985 460/310 204 GK 1311 49. 48372 1675 460/310 204 GK 1606 64. 23496 1905 460/310 263 GK 1606 42. 5104 1190 460/310 263 GK 1608 80. 86363 1725 460/310 302 GK 1608 65. 71008 1365 460/310 302 GK 1608 55. 38421 1135 460/310 302 GK 1610 108. 4887 1805 460/310 352 GK 1610 80. 05902 1250 460/310 352

GE name HP RPM VDC 505 G 134 1750 250 505 AY 134 1750 250 584 AY 134 1200 250 584 134 1200 250 504 AS 114 1750 250 CD 1345 Y 100. 5 1800 125/330 1269 Y 100. 5 250 125 445 87 1750 125 368 AT 87 1750 500 506 AT 80. 5 1200 75 CD 1139 Y 67 1800 125/330 405 G 67 1750 250
