Data & Cloud Storage Hybrid Azure Storage with Stor. Simple Rod Kruetzfeld Data Center Technical Strategist Microsoft Canada

Enterprise storage is transforming Microsoft Azure

Cloud storage concerns Can I secure my data in transit & at rest? How do I comply with industry regulations? Microsoft Azure 70% Can other customers access my data? Cloud Trend: of CIOs will embrace a cloud -first strategy in 2016 (IDC CIO Agenda webinar) Where will my missioncritical data reside? How can I get my data back from the cloud? How can I get my data to the cloud?

Microsoft storage Next-gen on-premises storage Microsoft Azure Hybrid cloud Storage: Stor. Simple Azure storage

Public cloud storage with Azure SUPPORT FOR HYBRID CLOUD Diversity • Blobs, Disks, Tables, Files, queues and SQL Azure Database Microsoft Azure Data Protection • Enterprise-grade • Simplified compliance Disaster Recovery • Local and Geo-Redundant Storage • Azure Site Recovery

7 Reasons you should consider Azure for storage Microsoft Azure

1 Simplified hybrid design Keep mission-critical, on-premises workloads local Customer Data Center Hybrid Microsoft Azure Scalability for data in the cloud Trusted Microsoft environment to manage heterogeneous systems Leverage existing on-prem IT investments Microsoft Azure “By using hybrid cloud resources from Microsoft, we can offer even more consistent capabilities and services to our customers without adding storage capacity to our data centers worldwide. ” – Bardo Werum, Lufthansa

Consistent platform across multiple environments & clouds Archival storage Disk based backup storage Primary storage Tape infrastructure & management Offsite DR & geo-resiliency Microsoft Azure On-premises Microsoft Azure Hybrid Cloud

Stor. Simple: Hybrid cloud storage Connect Windows, Linux, and VMware servers to Azure Storage in minutes with no application modification SVA Enterprise SAN storage Microsoft Azure Inline de-dupe, compression & automatic tiering Customer Data Center Stor. Simple Manager Automated offsite data protection using cloud snapshots Highly efficient, location-independent disaster recovery Access to enterprise data with Stor. Simple Virtual Appliance Microsoft Azure

How customers benefit Cloud HDD Unstructured data growing 40% Yo. Y Working data set stays fairly constant Hybrid storage array performance for working set Inactive data is tiered to the cloud Access SSD Time Stor. Simple provides enterprise storage with cloud economics Microsoft Azure

Economics – Traditional vs Hybrid Cloud Storage Illustrative cost comparison for 50 TB of primary data Function Primary and Archival Storage Backup and Disaster Recovery Traditional Storage Products Storage Array with Associated Software $75, 000 Backup Media Server and Software $25, 000 Disk Backup with Deduplication Licenses $100, 000 Offsite Tape Storage $50, 000 Replication for Disaster Recovery Time Objective (RTO) of 1 Week or Less $75, 000 Capital Cost for the Customer $325, 000 Support Cost $175, 000 Cloud Storage Cost Microsoft Azure Traditional Storage Cost $0 3 -Year Customer Cost $500, 000 Additional Customer Benefits None

Application and workload focus Azure workloads DR* Cloud Apps* Dev/ test* On-premises workloads Fileshares Microsoft Azure Archives Virtual Machines Share. Point SQL Server* * Only available with Stor. Simple 8000 series

Simplify offsite data protection Stor. Simple Virtual Appliance Microsoft Azure Cloud Snapshots Production Datacenter-1 Periodic VSS consistent cloud snapshots Microsoft Azure of production data Production Datacenter-2 Location independent recovery from cloud snapshot

Traditional Storage vs Hybrid Storage Traditional TB Local (raw) Capacity Auto-tiering Backup Data DRP Microsoft Azure Hybrid TB

TCO: 3 -year lifespan in Real Life! ONPREM VS HYBRID STORAGE (w/o Indirect On. Prem costs) Series 1 Series 2 $ 1, 400, 000. 00 $ 1, 200, 000. 00 Let’s Examine YOUR numbers! $ 1, 000. 00 $ 800, 000. 00 $ 600, 000. 00 $ 400, 000. 00 $ 200, 000. 00 $- Microsoft Azure 1 2 3 16

2 Lift & shift apps with Azure storage Microsoft Azure SMB offers high-performance connectivity to a highly available file share Share data stored in Azure Files among Azure VMs via SMB Azure Storage Blobs SMB Local storage Hyper-V VMs Microsoft Azure On-premises SMB Tables Queues REST API Files Cloud

3 Enhanced security & governance Use your existing governance policies & procedures Manage access to data and applications Choose where to keep your data with global availability Major datacenter Comply with industry standards & regulations CDN node Microsoft Azure “In the healthcare space, attribute-based access to applications and data is particularly critical. ” – Lucas Adams, Mc. Kesson

Azure compliance audits and certifications Global United States Regional Coming soon ISO/IEC 27001 SOC 2 PCI DSS L 1 version 3 Cloud Security Alliance Cloud Security Matrix Fed. RAMP HIPAA (Healthcare) FIPS 140 -2 Life Sciences Gx. P Family Educational Rights & Privacy Act European Union Model Clause United Kingdom G-Cloud China Multi Layer Protection Scheme China CCCPPF Singapore Multi-Tier Cloud Security Australian Signals Directorate I-RAP Assessment Sarbanes Oxley Criminal Justice Information System Defense Information Systems Agency L 2 ITAR Defense Information Systems Agency L 3 -5 ISO / IEC 27018 Microsoft Azure

4 Simple & reliable backup Protect important data off-site with automated backup to Azure Consistent tools in Windows Server, SQL Server and DPM for backup & recovery to local disk or Azure storage Microsoft Azure “We’ve eliminated the need to send, receive, track, and recycle tapes, which consumed 20 percent of our highly skilled engineers’ days. ” – Kai Sookwongse, Mazda

5 Resilient disaster recovery Simple recovery protection using your own second site or Azure Restore an entire site in the event of an outage with orchestrated recovery Cloud-based business continuity solutions Microsoft Azure “We can’t afford any service outages, so it was important to pick the right high availability and disaster recovery solution: resilient, flexible, easy-to-use, and cost-effective. ” – Richard Wilson, United Airlines

Automate recovery with Azure Site Recovery Communication Channel Communication and Replication channel: Hyper-V Replica Primary Site Recovery Site Windows Server Microsoft Azure Orchestrate disaster recovery to a second site…. Primary Site Windows Server …Or to Azure

Multiple levels of redundant storage Level Definition Locally redundant storage multiple replicas of data within a single region Zone-redundant storage replication between two to three facilities within one or more regions Geo-redundant storage replication between two regions hundreds of miles apart within a geo Read-access geo-redundant storage GRS + read-only access to storage in secondary region Microsoft Azure

Enable a SQL Server continuity strategy Direct URL backup to Azure Storage Restore in Azure Virtual Machine SQL Server. Management Studio SQL Server Studio Backup and restore SQL Server database to the cloud Achieve greater reliability with off-site data backup of SQL images Easily restore databases using VM Microsoft Azure

6 Fast, flexible, & secure data transfer Azure Import/Export Stor. Simple Microsoft Azure Multiple options for secure data transfer Transfer large amounts of data to Azure quickly with Stor. Simple Customer Microsoft Azure MS Regional Data center Ship data in hard disk drives through Fed. Ex to our data centers “[We are] using Stor. Simple to create policies that archives data to Azure storage if it hasn’t been accessed in 12 months. ” – Richard Proud, Director at Risual, for Paul Smith

Express. Route: dedicated, secure connections Exchange Provider Network Service Provider Microsoft Azure Public Internet WAN Express. Route location Multiple customer sites Customer site Connecting at Express. Route Location (Exchange Provider facility) Microsoft Azure 26 Connecting from a WAN (e. g. MPLS VPN) provided by network services providers

7 Developer Experience Storage platform grounded in strong consistency simplifies development of concurrent apps Rich client libraries simplify development in. NET, Java, C++, Node. Js, Android, PHP, Ruby and Python Visual Studio integration provides productivity and simplicity. NET developers expect from Microsoft MSDN subscriptions and storage emulator simplifies dev and test Microsoft Azure "With Microsoft Azure, we instantly have a scalable video encoding platform. We can spin up hundreds of encoding servers when needed and let them go when the job is done. ” – Jon Robinson, blinkbox
