Customer Loyalty through Client Satisfaction Pipeliners Club of

Customer Loyalty through Client Satisfaction Pipeliners Club of Atlanta Presentation

Customer Loyalty through Client Satisfaction Pipeliners Club of Atlanta Presentation Kevin Hanna PLS - Director Laser Scanning/Survey Matt Shinsky - Energy Market Manager, Principal Associate

MASER CONSULTING § Over 900 employees § 30 Offices § ENR’s Top 500 Design Firms § Zweig White Hot Firm § NJBIZ 50 Fastest Growing Pipeliners Club of Atlanta| Maser Consulting

MASER CONSULTING P. A. Offices in 11 States § § § New Jersey § 7 Offices § Red Bank, Clinton, Hamilton, Marmora, Mt. Arlington, Mt. Laurel, Montvale New York § 4 Offices § Albany, Newburg, Westchester, Goshen § § Pennsylvania § 4 Offices § Lehigh Valley, Exton, Philadelphia, Pittsburg § Virginia § 2 Offices § Norfolk, Sterling § Florida § 4 Offices § Tampa, Miami, Orlando, Jacksonville New Mexico § § 1 Office § Albuquerque Maryland § 1 Office § Columbia North Carolina § 2 Offices § Charlotte § Raleigh South Carolina § 1 Office § Charleston Georgia § 1 Office § Atlanta Tennessee 1 Office § Nashville Pipeliners Club of Atlanta | Maser Consulting

MASER CONSULTING P. A. § Bridge Engineering § Landscape Architecture Services § Civil/Site Engineering § Municipal Services § Construction Inspection & Administration § Planning Services § Construction Quality Control Services § Recreational/Sports Services § Cultural Resource Services § Storm water Management Services § Dam Engineering § Structural Engineering § Ecological Services § Survey & Geospatial Services § Energy Services § Telecommunication Services § Electrical Engineering § Transportation/Traffic Engineering § Environmental Services § Waterfront Engineering § Geotechnical Engineering § Water/Wastewater Engineering § GIS/Asset Management Services § Grants & Funding Services § Hydrogeologic Services Pipeliners Club of Atlanta | Maser Consulting

Maser Consulting Competencies § Survey § 3 D Laser Scanning § Mobil Mapping § Unmanned Aerial Systems § Civil / Site Engineering § Subsurface Utility Engineering § Electrical Engineering Pipeliners Club of Atlanta | Maser Consulting

SURVEYING SERVICES § Right of way (ROW) mapping § Pipeline & utility right of way mapping § Topographic surveys § Tax mapping § Construction stakeout § 60 survey crews Pipeliners Club of Atlanta | Maser Consulting

WHAT IS 3 D LASER SCANNING ? It’s Like a 3 D Camera ! Also known as. . . Li. DAR = Light Detection And Ranging Laser Scanning Terrestrial Li. DAR 3 D Scanning High Definition Surveying Pipeliners Club of Atlanta | Maser Consulting

WHAT IS 3 D LASER SCANNING ? Has a 360° Hz. & 270° Vt. field of view. 50, 000 to 2 million measurements per second ! Accuracy Range = 1/8” -1/4” Color Photography may also be recorded. Typical scan time = 1 to 10 minutes Range 10 ft. - to 300 ft. depending on application. Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING – SAFE DATA CAPTURE q Natural Gas Explosion Boston MA. q Requirement to Document & asbuilt Natural Gas Installations. Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING – SAFE DATA CAPTURE q Safer data capture q Unobtrusive - non tactile (no tapes !) q Better quality results –more accurate & complete q Elimination of costly "return visits" to the site q Added Value with photography q Faster results q Daylight not required Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING - MECHANICAL MODELS Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING APPLICATIONS § Regulator Stations - 3 d models § Structural as-built surveys § Situational awareness (3 d photography) § Topographic surveys Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING EQUIPMENT INVENTORY Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING SOFTWARE INVENTORY Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING - MECHANICAL MODELS Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING - PIPING 3 D MODELS Pipeliners Club of Atlanta | Maser Consulting

3 D LASER SCANNING - SUBSTATIONS Pipeliners Club of Atlanta | Maser Consulting

SUB SURFACE UTILITY ENGINEERING § Risk Envelope For Utilities § Utility Designation § Tone Outs & GPR Surveys § Vacuum Truck/Test Holes § 3 D Utility Modeling § Utility Research Pipeliners Club of Atlanta | Maser Consulting

THANK YOU FOR YOUR TIME QUESTIONS Pipeliners Club of Atlanta | Maser Consulting

Customer Loyalty through Client Satisfaction Kevin Hanna, PLS - 3 d Laser Scanning/Survey Director Matt Shinsky - Energy Market Manager, Principal
