CT SYSTEMS presents AUTOMATIC MODULES for BIODIESEL PRODUCTION

CT ® SYSTEMS presents AUTOMATIC MODULES for BIODIESEL PRODUCTION

TWO MODELS BIOTRON-CT 500 LITERS PER HOUR BIOTRON-CT 1000 LITERS PER HOUR BIOTRON-CT

BIOTRON-CT CONSISTS OF THREE MAIN PARTS

SEPARATION SYSTEM 3 1 CAVITATION REACTOR PULSAR-CT 215 B DOSING UNIT PPS-1200 ELECTRIC CABINET WITH 2 PLC “FANUC” and

1 2 3

How It Works

VEGETABLE OIL (OR ANIMAL FAT) THREE INITIAL PRODUCTS PURE METHANOL CATALYST

ALL THREE PRODUCTS GO TO THE DOSING UNIT BIODIESEL AREWEIGHED MIXED THE OIL IS REACTED WITH METHANOL INSIDE THE REACTOR 1 2 THE BIODIESEL UP TWO SENSORS FLOATS CONTROL AND THE SEPARATION PROCESS THE GLYCEROL SETTLES DOWN 3 GLYCEROL THE MIXTURE IS PUMPED OF BIODIESEL AND GLYCEROL TO THEISREACTOR PUMPED TO THE SEPARATION TANK READY PRODUCTS ARE PUMPED INTO STORAGE TANKS GLYCEROL BIODIESEL

THE PROCESS OF BIODIESEL PRODUCTION BY BIOTRONS IS CONTINUOUS PROCESS (NON STOP) AND DOES NOT REQUIRE POST-TREATMENT OF BIODIESEL All mechanisms are certified to ATEX

BIOTRON-CT DELIVERY SET

500 1000 BIOTRON-CT + ELECTRIC CABINET (ATEX) WITH PLC FANUC + PC (WINDOWS 7) WITH LICENSED SOFTWARE

Our address : Ordzhonikidze street, 10, office 1304, Kramatorsk city, Donetsk region, 84313, Ukraine. office@ctsystems. ua www. ctsystems. ua Phone/Fax: +380 6264 77017
