Cordell VQM C 15 Call History Server Interface

Cordell VQM C 15 Call History Server Interface for AMA and Call Records

VQM / Call Records: - Graphs - Call Record Filters -- Create New -- Save Filter Parameters -- Use Saved Filter - Filter Results: -- Convert to / download as CSV -- Omit Columns -- Toggle data by column in ascending/descending order - Reports Storage: 1 year Retrieval of Data: - Call History Server - Every 5 minutes - Database updates automatically Notifications – Missed data retrieval: Alarms to NOC, Email

Graphing Examples

Qo. S View as GRAPHS or TABLES: • • • Packet Loss Jitter Round. Trip. Delay MOS Rscore • Drop. Box Link to Live National Webinar • https: //www. dropbox. com/s/xnfed 280 i 4 njcqg/Ken. Woodman see-C 15 Analytics-Webinar. mp 4? dl=0

Filters Filter by DN Group Specify number of records to return Create New Filter Load/Use/Edit Saved Filter any column Set AND/OR conditions

Filter Results Left side of screen Right side of screen Default is all columns Options: - Omit columns - Toggle order by colum ascending/descending - Specify rows per page - Select page - Convert to CSV/Excel - Filter any column Note: DN’s altered

Reports Predefined reports are available Can be scheduled to run automatically Can be modified

Filter Examples Calls to 911 on/after specific date Calls from specific DN on/after specific date

Filter Examples – continued Carrier (two), for specific period, from NPANXX Any Qo. S Measurement value is greater than 0
