Cook Stove for Haiti Stove Construction Project 11461

Cook Stove for Haiti Stove Construction Project 11461 Jordan Hunter Rob Reid Mike Lagos Brian Knight

Functioning Stove Design Annulus Pot & Water Air Flow Fan Combustion Packed Bed of Charcoal Orifices Dia. Stove Dia. Combustion Chamber # of Holes in Chamber Height of Stove w/o annulus m m # m m 0. 2794 0. 1778 22 0. 1778 Volume of Chamber m 3 0. 004735492 Volume of Stove-Chamber Fan Power Dia. Of Pot m 3 W m 1 0. 2921 Area of fan Height of Annulus Width of Annulus m 2 m m 0. 005026548 0. 2032 0. 01 Area of single Hole in Chamber Radius of single hole m 2 m 0. 000126677 0. 00635

Layout of Parts on Flat Drum

Assembly Notes • Grind paint off of all edges that are to be welded. • Drill Orifice holes 2. 54 cm up from bottom of combustion chamber. • Annulus gap around pot is. 5 cm wide. • Bottom of stove is welded 1. 27 cm deep into base. • Cut 8. 89 cm deep by 10. 16 cm long rectangle out of Base and outside chamber. Example shown in drum layout on previous page. • Handles are to be cut from top ring of drum that is holding the cover on. • Air inlet to stove should be fabricated to fit after outer chamber and base are welded. This ensures pieces will fit correctly.

Stove Assembly
