CONTENTS Corporate Overview Technology Products Technology background Target
CONTENTS • Corporate Overview • Technology & Products • Technology background • Target Market • Value Proposition • Contact point info
General Information Jastec Network Bundang Head office (scantools/telematics) korea Hwaseong Automotive Technology R&D Center Pyeongchon e-Biz, TET (RSD, SI)Division Jastec USA, Inc. Over seas Jastec Beijing Branch Office
Software Know-how & technology in automotive service equipment accumulated over 20 years ASIC System
Telematics Diagnostic Equipment “Myivi” JASTEC Network -PAYD Solution -E-Call / Safety / Thefts Recovery Solution -On-Line Fuel Economy monitoring -On-Line Emission (Co₂, HC, CO, etc) Monitoring -Other Solution and Services My-ivi Korea’s top class wireless diagnostic scantool combines with automotive data-compiling GPS CAR-DOCTOR Portable wireless diagnostic scanner applicable to various types of cars OEM-SCAN TOOL GM Daewoo, Ssang-yong Renaults-Samsung General information - Enhanced I/M System/Chassis Dynamometer/Automotive Gas Analyzer - Opacity Meter/Shock Absorber Tester/Endoscope/ Headlight Tester - Diesel Common Rail Equipment/Remote Sensing Device -Building a system for total management of vehicle emissions data -Project led by. Environmental Management Corp. (EMC) -Carried out by consortium of a leading corporation and JASTEC
Security Motor Vehicle Event Data Recorder Less Fuel cost and Insurance premium
Telematics Service type Telematics Service’s status & prospect ▼ Traffic Data : Navigation, parking guide, congestion info Security : Stolen Vehicle Assistance, Tracking System, Remote Vehicle door lock/unlock Safety : Hazard warning of driving, Emergency help, Remote notification for car accidents Vehicle Management : Vehicle status history, repair data, Insurance Real-time News : Local Info, Events & Shopping center Info Communication : e-mail, Video call, Entertainment : DMB, MP 3, PMP, Web searching, Game, Remote Training Secretary : Private data management, Voice memo, Call record U. S. A W. EUROPE JAPAN KOREA LEADING – BUSINESS AUTOMOTIVE INDUSTRY + MOBILE COMMUNICATION MAIN SERVICE SECURITY TRAFFIC DATA, NAVIGATION FEATURE Single Market Diversity of each country Regional Centralization STRENGTH -Advanced Car Culture -Demand of Security Service -Related Platform Service -Single Mobile Radio Communication - Development of Automotive Tech -Government`s extensive Support -High-class Infrastructure level - Development of Automotive Technology -World-class Wireless Infrastructure level -Early Adopters’ use turn -Excellent contents development WEAK POINTS -variety standards of Mobile Network -low level of Geography and traffic data integration Rising competition caused by large number of Providers Inferior International cooperation for platform standard ON STAR(GM) Navitech (VOLVO) Assist (BMW, JAGURE) G-Book(TOYOTA) Internavi(HONDA) Carwing(NISSAN) Natedrive (SKT) Mozen(HYUNDAI) K-ways(KTF) REPRESENT SERVICE
- High speed 32 bit CPU Remote diagnostic Service and alarming service Wireless connection with Bluetooth/LAN or Mobile (GSM/GPRS or CDMA) Vehicle Location Tracking service (Stolen Vehicle Tracking) Remote Immobilization /Lock/Unlock Expansible software programs for various telematics usages CPU 32 -BIT 72 MHz(ARM Cortex-M 3) /FLASH: 258 KB/SRAM: 48 KB MEMORY F-RAM: Basic 32 kb External Memory Card: micro SD Card WIRELESS Bluetooth: Version 2. 0 -2. 4 GHz, Class 1(Open Field: Max. 100 m) / Internal Chip Antenna / Baudrate Wireless LAN - Standard IEEE 802. 11 b/g-2. 4 GHz, Up to 54 Mbps INTERFACE Vehicle Interface : CAN 2. 0 B/CAN line(CAN_H, CAN_L) of ISO 15765 -4 / High/ Middle Speed can(Up to 1 Mbps) / Supported Single Wire CAN(GMLAN) / 2 x K line of ISO 9141 -2 and ISO 14230 -4 / 1 x L line of ISO 9141 -2 and ISO 14230 -4 / 1 x PWM and VPWM of SAE J 1850 Host Interface : 1 x USB 2. 0 Full-Speed 12 Mbps / USB Vitual COM Port(Supported USB Storage) O/S: Windows 98 SE/2000/XP/Vista SIZE 67(W) x 107(H) x 27(T)mm GPS U-Blox - L 1(1572. 42 MHz), 20 channel - External Antenna(Option) MOBILE GSM/GPRS: Frequency Band Quad-band EGSM 850/900/1800/1900 MHz Data Service / Sim card access / Internal Antenna CDMA 2000 : 1 x Frequency Band - Receive: 869 ~ 894 MHz / Transmit: 824 ~ 849 MHz Data Service / Max 153. 6 Kbps Full-Duplex / Internal Antenna CONNECTOR OBD-2 16 P Connector of SEA J 1962 Telematics On-board Display Device diagnostic Module [Detail Image]
CPU 32 -BIT 72 MHz(ARM Cortex-M 3) /FLASH: 258 KB/SRAM: 48 KB MEMORY F-RAM: Basic 32 kb External Memory Card: micro SD Card WIRELESS (A) Bluetooth : Version 2. 0 -2. 4 GHz, Class 1(Open Field: Max. 100 m) (B) Internal Chip Antenna / Baudrate (B) Wireless LAN - Standard IEEE 802. 11 b/g-2. 4 GHz, Up to 54 Mbps INTERFACE Vehicle : CAN 2. 0 B/CAN line(CAN_H, CAN_L)of ISO 15765 -4 High/Middle Speed can(Up to 1 Mbps) Supported Single Wire CAN(GMLAN) 2 x K line of ISO 9141 -2 and ISO 14230 -4 1 x L line of ISO 9141 -2 and ISO 14230 -4 1 x PWM and VPWM of SAE J 1850 Host : 1 x USB 2. 0 Full-Speed 12 Mbps /USB Vitual COM Port (Supported USB Storage) O/S: Windows 98 SE/2000/XP/Vista SIZE 67(W) x 107(H) x 27(T)mm CONNECTO R OBD-2 16 P Connector of SEA J 1962 § Top-notch and highly stable Windows CE 5. 0 OS § Enhanced Graphic functions which has various indications with graphic form § Extensive coverage of communication protocol (Asian/European/American Vehicles) § Support for new communication protocol by wireless diagnostic module with a built-in CPU § Mess storage of a diagnostic program card (Enlargement of memory, 128 MB is feasible. ) § Support USB 2. 0 to communication with PC § Various self diagnostic adapters and system control menu § Snapshot function
DEFECTS DIAGNOSIS VEHICLE MANAGEMENT • Exchange Auto Parts • Individual Vehicle Status • Driving habit Analysis of a driver (kilometers driven, type of roads used, average length of the trips, time of the day, average speed, and percentage of night hours • • Vehicle Performance Defect Diagnosis & Data Check Back up external memory data Analyzes the stored data
Leading Company in Telematics Business Running Items Automotive Diagnostic Scan-tool Telematics Device Q 1 Q 2 Q 3 Q 4 SCAN-100/200/I, MR-TECH, MET-5000 CAR-DOCTOR [Wireless scanner) My-i. VI PC-Type [Wireless Diagnostic Scantool] My-i. VI On-Board Telematics Device My-i. VI Hand-Held Type [Wireless Diagnostic Scantool]
My- i. VI Diagnostic Scantools Chassis Dynamometer CGA-6000 HN, HE SCAN-100/200/I, MR-TECH (for Daewoo/Ssangyong/Renault Samsung) CCD HD 500 WC-240 MET-5000(Aftermarket Scanner) Telematics Device & Diagnostic Scantool CAR-DOCTOR (Wireless scanner) Headlight Tester Automotive Gas Analyzer Common Rail Test Bency CCD HD ASM-P Opacity Meter CCD HD 4000 K, F (ASM / Lugdown 15 -ton dynamometer) Shock Absorber Tester CSM-2500 CSM-3000 Endoscope Video Image Guide Scope TEC-100 Touch Controller & Chip Set BD-960 Exhaust Gas Analyzer System SEMTECH-DS PM Measuring Equipment MPM 4 Safety Tester MDT (Micro Dilution Tunnel)
Thank you.
