Content of the Presentation n Wrtsil an Introduction

Content of the Presentation n Wärtsilä - an Introduction n Power Plants - minimising carbon emissions n Bio-Power

Vision Wärtsilä - Power on Land at Sea We strive to lead the ship power and distributed power generation markets by providing the most competitive, reliable and environmentally sound solutions. Our world-wide network of professionals translates these solutions into maximum customer satisfaction and value.

The Ship power supplier Wärtsilä supplies ship machinery, propulsion and manoeuvring solutions and maintenance services for all types of marine vessels and offshore applications.

Power for a changing world Wärtsilä delivers power plant solutions from 1 to 300 MW. These power plants are used for baseload, peak load, CHP, gas compression and pumping applications. The range covers gas- and oil fired plants as well as patented combustion technology for renewable energy. Deliveries include turnkey construction and long-term maintenance and operation.

Decentralised Power Generation Cogeneration & baseload 8 gas and bio fuels 8 oil and advanced emulsified fuels

Cogeneration Applications Primary Energy Conversion Fuel Generator Engine Exhaust Gases Energy Distribution Energy Consumption Secondary electricity production Electricity consumer Electricity Cooling circuits Steam PROCESSES - drying - heating - after burning - etc. Hot Water PROCESSES Heating Cooling - process heating - absorption - district heating chiller - drying - desalination -etc. Heat

Typical Diesel Power Plant Heat Balance Recoverable Cooling Water Heat 16 - 20 % Recoverable Lubricating Oil Heat 4 -6% Recoverable Exhaust Gas Heat 12 - 16 % Non-Recoverable Heat Energy 20 - 25 % Up to 80 % Total Efficiency is Possible Electrical Power 40 - 45 %

Total efficiency 18 V 34 SG DISTRICT HEATING DENMARK ( = 90%) DISTRICT HEATING FINLAND ( = 80%) CHILLERS or DESALINATION ( = 75%)

Energy from bio mass Wärtsilä Bio Power • Strong growth potential • Acquisition of Sermet with - patented rotating Bio. Grate product - bio fuel expertise Decentralised bio boilers and power plants.

Wärtsilä Bio. Power Products n Wärtsilä’s Bio. Power products are based upon patented rotating Bio. Grate combustion technology, specially suitable for wet biomass such as wood residuals, wood chips, bark and sawdust. n The patented Bio. Grate technology used in Wärtsilä’s Bio. Power and Bio. Energy plants ensures a highly efficient combustion process with many bio fuels, with flue gas emissions below the most stringent limits. The Bio. Grate technology is especially designed for very wet fuels (up to 65 % moisture) and reliably burns most bio fuels with moisture content above 15 %. n

Wärtsilä Biopower Wärtsilä - Bio. Grate. TM Combustion Technology: n Rotating conical grate n Several ( 4 - 10 ) combustion zones n Zone controlled primary air inlet under the grate for complete combustion n Fuel feeding from centre bottom which don’t disturb combustion process n Under grate wet ash removal n Designed for wet fuels up to 65%-w ì ì Long lifetime Reliable operation High efficiency combustion Low emissions TM

Wärtsilä Biopower Today’s Products Bio. Grate - Combustion technology: n Patented combustion system Bio. Energy Thermal Plants: n Hot water or / and low pressure steam n Bio. Energy Thermal 3 and 5 MWth Compact n Bio. Energy Thermal 7, 10, 12, 15, 20 MWth Bio. Power Plants: n Bio. Power CHP 2 and 5 n Bio. Power Condense 2 and 5

Bio. Power CHP Plant n n Combined heat and power (CHP) plant increases energy independency and minimises emissions due to the high total efficiency, which may exceed 90%. Electricity is produced in a steam Rankine cycle, which is optimized for generating electricity and thermal energy. Steam Turbines Generator Condenser Fuel District Heating Bio. Grate Feedwater Fuel Bio. Grate Feedwater Process Consumer

Bio. Power Condense Plant Steam Turbines Generator Fuel Condenser Bio. Grate Feedwater Main Performance data

Bio. Power and Bio. Energy plants Power plant building l l Standard steel structure building - very fast to construct. Meets normal western noise requirements inside and outside. Fire protection is according to local norms. A high level of automation enables unmanned operation. Delivery l l l high degree of prefabrication large modules Supervision of installation, a functioning plant process or a complete turn-key installation. - fast, reliable and competitive

Bio. Power 2 Layout

Website: www. wartsila. com contact: pv. krishna@wartsila. com
